Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1140 x 700 x 820 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended maximum user weight | 150 kg | |
|---|---|---|
| Net weight | 26 kg | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Foam rebound rate | 55% | |
| Caster rolling durability cycles | 100000 | |
| Gas lift lift cycles | 120000 | |
| Seam stitch pitch | 8 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick grey PU leather | |
|---|---|---|
| Seat padding | 100mm thick high-density polyurethane foam | |
| Back padding | 80mm thick high-density polyurethane foam | |
| Armrest construction | PU leather wrapped padding over rigid inner frame | |
| Internal support frame | 1.5mm thick welded steel tube frame | |
| Five-star base | 1.2mm thick chrome-plated polished steel | |
| Casters | Nylon dual-wheel casters with chrome trim ring | |
| Retractable footrest | PU leather padded top over steel slide rail | |
| Lumbar support pillow | Grey PU leather cover with 80mm foam fill | |
| Recline mechanism hardware | Cold-rolled steel plate lever and locking assembly | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full rotation enabled by central gas lift swivel joint | |
|---|---|---|
| Pneumatic seat height adjustment | 100mm vertical travel via Class 3 gas lift | |
| Backrest recline function | 135-degree maximum recline angle with infinite position lock | |
| Recline tension adjustment | Adjustable tilt tension knob under seat to match user weight | |
| Retractable footrest | Slide-out under-seat leg rest locks in fully extended position | |
| Smooth rolling mobility | Dual-wheel casters suitable for hard floors and low-pile carpet | |
| Fixed armrest support | Padded fixed armrests provide stable forearm support at desk height | |
| Integrated lumbar support | Attached padded pillow aligns with natural lower back curve | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive office use | Suitable for private executive offices, providing professional appearance and recline rest function | |
|---|---|---|
| Home office setup | Appropriate for dedicated home workspaces, enabling short rest breaks during long work sessions | |
| Managerial workstations | Ideal for middle and senior manager desk positions, combining formal styling and comfort | |
| Conference room seating | Suitable for high-end conference rooms requiring premium, comfortable executive seating | |
| Commercial reception areas | Usable in VIP reception spaces for guest seating during formal meetings | |
| Long-duration desk work | Supports 6+ hours of daily seated work with lumbar support and padding | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office furniture office chairs safety | EN 1335:2020 | |
|---|---|---|
| Upholstered furniture abrasion resistance | EN 14465:2004 | |
| Furniture mechanical stability | EN 1022:2018 |
US and Canada office-furniture standards
| Office chair general purpose | ANSI/BIFMA X2017 | |
|---|---|---|
| Gas lift performance requirement | ANSI/BIFMA X5.1 Clause 8 |
Standards applicable to China-market projects
| Office chair strength and durability | GB/T 3324 | |
|---|---|---|
| Upholstered furniture safety | GB 20400 | |
| Office chair ergonomic requirement | GB/T 39223 |
This product must meet the following technical requirements: 1. Office chair strength and durability: GB/T 3324; 2. Upholstered furniture safety: GB 20400; 3. Office chair ergonomic requirement: GB/T 39223; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
