Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (upright) | 701 x 760 x 1213 mm | |
|---|---|---|
| Seat width | 627 mm | |
| Seat depth | 500 mm | |
| Seat height (adjustable range maximum) | 460 mm | |
| Backrest total height | 760 mm | |
| Armrest height above seat | 200 mm | |
| Five-star base spread diameter | 680 mm | |
| Retractable footrest extension length | 420 mm | |
| Caster wheel diameter | 60 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest padding thickness | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Maximum user weight capacity | 181 kg | |
|---|---|---|
| Net product weight | 23 kg | |
| Recline maximum locked angle | 155° | |
| Gas lift rated static load | 125 kg | |
| Five-star base static load capacity | 1136 kg | |
| Caster rolling durability rating | 100000 cycles | |
| Recommended daily usage duration | 8 hours | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick matte PU faux leather, taupe/light khaki color | |
|---|---|---|
| Seat cushion core | 40kg/m³ high-density cold-cure polyurethane foam | |
| Backrest padding core | 32kg/m³ high-resilience polyurethane foam | |
| Internal support frame | 1.5mm thick steel tube frame reinforced with 12mm plywood | |
| Five-star base | 1.2mm thick chrome-plated polished steel five-prong base | |
| Caster wheels | 60mm diameter dual-wheel PU casters with chrome trim rings | |
| Armrest construction | Padded PU armrests with dark wood-grain accent supports and chrome end caps | |
| Recline mechanism chassis | 2.5mm thick steel plate tilt-lock mechanism | |
| Retractable footrest surface | PU-padded steel sliding footrest with chrome trim | |
| Seam stitching | 20 stitches per 100mm even matching-thread stitching | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full 360° horizontal swivel supported by central gas lift pivot | |
|---|---|---|
| Pneumatic seat height adjustment | 120mm vertical height travel via Class 4 gas lift, side lever operation | |
| Lockable recline function | Recline locks at any position up to 155° via side-mounted control lever | |
| Recline tension adjustment | Tension knob adjusts backward tilt resistance to match user weight | |
| Retractable sliding footrest | 420mm pull-out extension from under seat for leg support during recline | |
| Smooth rolling mobility | Dual-wheel PU casters roll on hard floors and low-pile carpet without scratching | |
| Fixed padded armrests | Curved padded armrests provide fixed stable forearm support at desk height | |
| Integrated head and neck support | Contoured tall backrest includes built-in padded headrest section | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive private office | Suitable for manager/executive private offices for daily desk work and short rests | |
|---|---|---|
| Conference room seating | Appropriate for boardroom or high-end conference room seating for senior personnel | |
| Home office workspace | Ideal for dedicated home office spaces requiring comfort for extended work sessions | |
| Reception/management waiting area | Suitable for premium reception areas for high-level visitor seating | |
| Commercial office project fit-out | Recommended for bulk commercial office projects seeking premium manager seating | |
| Height-adjustable desk compatibility | Works with standard 760 mm height office desks via gas lift adjustment | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair ergonomic and dimensional performance requirements | |
|---|---|---|
| EN 1022:2018 | Applies to seating stability testing for domestic and contract use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general-purpose office chair durability, safety and performance |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office chair dimensional and structural stability requirements | |
|---|---|---|
| GB/T 35607-2017 | Applies to upholstered furniture VOC and harmful substance emission limits |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office chair dimensional and structural stability requirements; 2. GB/T 35607-2017: Applies to upholstered furniture VOC and harmful substance emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
