PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	680 × 650 × 1000 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight	16 kg
Maximum user weight	160 kg
Cantilever static proof load	1100 N
Seat cushion fatigue cycles	100000 cycles
Backrest cyclic load cycles	80000 cycles
Seating capacity	1 person
Stacking quantity	0 units
Floor glide load per foot	40 kg
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat and back upholstery	Light beige leather-look upholstery over padded panels
Rear and side accent panel	Camel brown upholstered rear/side panel with stitched edge
Cushion padding	Molded polyurethane foam pad with an 80 mm seat thickness and 45 mm back thickness target
Arm construction	Integrated upholstered arm and side panel over a rigid internal board
Support frame	Chrome-plated bent steel cantilever tube with a 25 mm diameter and 1.5 mm wall target
Floor contacts	Four polymer or rubber glide pads attached to the sled feet

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating mechanism	Fixed non-swivel, non-tilting visitor seat on a rigid cantilever frame
Arm support	Fixed padded armrests integrated with the side panels at a 220 mm height above the seat
Back support	High fixed back with an integrated lumbar curve and 10-degree rearward rake
Floor protection	Four stationary glide pads distribute load and reduce direct metal contact

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton dimensions	720 x 620 x 590 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Reception and executive visitor areas	Single fixed guest chair suited to reception desks, executive offices, and manager meetings due to its upright padded back and formal arm support.
Conference and meeting rooms	Cantilever design provides quiet, non-rolling seating for boardrooms, visitor seating rows, and formal consultation spaces.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office seating safety reference	EN 16139
Upholstered furniture flammability reference	EN 1021and EN 1021
Furniture structural strength reference	EN 1730

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Commercial seating performance reference	ANSI/BIFMA X5.4
Upholstery durability reference	ANSI/BIFMA e3, Section 7.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Furniture mechanical safety reference	GB/T 10357.2, GB/T 10357.3, and GB/T 10357.6
Formaldehyde emission reference	GB 18580
Upholstered furniture safety reference	GB/T 27923

Standardized tender description text

This product must meet the following technical requirements:
1. Furniture mechanical safety reference: GB/T 10357.2, GB/T 10357.3, and GB/T 10357.6;
2. Formaldehyde emission reference: GB 18580;
3. Upholstered furniture safety reference: GB/T 27923;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · VC-SLED-680-1000-TT

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · VC-SLED-680-1000-TT

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · VC-SLED-680-1000-TTOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Tone Upholstered Visitor Chair with Chrome Cantilever Sled Base is a formal guest seating solution with a structured high-back silhouette, fixed upholstered arms, and a polished metallic frame. Model VC-SLED-1000-TT is offered as an unbranded visitor chair for settings where a neat, professional appearance is preferred. Its visual character comes from the two-tone upholstery treatment: the seat and inner back use light beige leather-look material over padded panels, while the rear and side accent panels are finished in camel brown upholstery with a stitched edge. The high fixed back includes an integrated lumbar curve and a rearward rake, giving the chair a supportive, upright profile. Integrated arms and side panels create a continuous upholstered surround, while the chrome-plated bent steel cantilever sled frame adds a bright, linear contrast beneath the seating body. Overall dimensions are 680 by 650 by 1000 millimetres, with 540 millimetres of clear width between the armrests. Construction combines padded comfort with a rigid support structure. The seat and back use molded polyurethane foam pads, with a finished seat cushion thickness of 90 millimetres and backrest padding thickness of 70 millimetres. The arm and side assembly is upholstered over a rigid internal board, and the arm support sits 220 millimetres above the seat. The cantilever frame is produced from chrome-plated bent steel tube, with polymer or rubber glide pads fitted to the four sled feet to reduce direct metal contact with the floor. The chair is fixed, non-swivel, and non-tilting, providing stable single-person seating with a net weight of 16 kilograms and a stated maximum user weight of 160 kilograms. This model is well suited to reception desks, executive offices, manager meeting areas, boardrooms, consultation rooms, and formal visitor rows. Its non-rolling sled base makes it a quiet, orderly choice for conference and meeting spaces, while the padded back and arms support prolonged guest use in professional environments. It can also work in refined residential workspaces or private study areas that call for an office-style visitor chair. Procurement planning should note that the chair is not designed for stacking and is supplied as one set across two cartons, with a packaged gross weight of 23 kilograms and an assembly time of 40 minutes per set. Buyers should allow space for delivery, handling, and installation, and should review the upholstery finish, glide type, and floor surface compatibility before ordering. The chair is intended for single-seat placement or fixed-layout visitor arrangements rather than flexible, rolling, or stackable seating schemes.

Two-Tone Upholstered Visitor Chair with Chrome Cantilever Sled Base Specifications
