Brown Upholstered Cantilever Visitor Chair with Chrome Sled Frame and Fixed Arms (model VC-CB570-BRN) is listed under Executive Boss Chair. Dimensions: 640 × 630 × 1040 mm. Materials: Brown leather-look surface, 1.2 mm nominal facing thickness, sewn over padded cushioning. Load capacity: 160 kg. Product Features: fixed-arm,visitor,chair,cantilever,sled,base,padded,upholstery,chrome,metal,frame,brown,finish. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | FENGGUAN | Model | VC-CB570-BRN |
| Overall dimensions (W × D × H) | 640 × 630 × 1040 mm | Finished Seat Cushion Thickness | 90 mm |
| Backrest Padding Thickness | 70 mm | Lumbar Support Zone Height | 240 mm |
| Clear Width Between Armrests | 540 mm | Net weight | 14.8 kg |
| Rated static load | 160 kg | Recommended user weight | 120 kg |
| Cantilever flex test target | 100000 cycles | Back strength test target | 100 kg horizontal load |
| Arm downward load target | 75 kg per arm | Floor glide compressive rating | 100 kg per glide |
| Seat occupancy | 1 person | Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
| Back Foam Density Reference | 38 kg/m³ | Seat and back upholstery | Brown leather-look surface, 1.2 mm nominal facing thickness, sewn over padded cushioning |
| Seat foam | High-resilience polyurethane foam, 80 mm cushion thickness and 45 kg/m3 density target | Back padding | Molded polyurethane padding, 50 mm lumbar thickness and 40 kg/m3 density target |
| Support frame | Polished chrome-plated steel cantilever tube, 32 mm diameter and 1.5 mm wall target | Arm pads | Padded brown upholstered pads on chromed steel supports, 35 mm visible pad thickness |
| Floor protection | Black non-marking polymer glides fitted at four sled-frame contact ends | Fixed cantilever support | Continuous chrome sled frame provides controlled sprung flex without casters, tilt mechanism, or height adjustment |
| Fixed armrest support | Integrated padded arms support forearms at 220 mm above the seat and connect directly to the side frame | Contoured sitting posture | Padded seat at 450 mm and 12-degree fixed back angle support upright meeting-room posture |
| Floor placement and stacking | Four polymer glides allow direct placement on hard floors; the chair is designed as a non-stacking fixed-leg model | Gross weight per carton | 17.5 kg |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Carton Dimensions | 850× 420× 720 mm | Reference Packaged Gross Weight | 23 kg/set |
| Reference Carton Volume | 0.26 m³/set | Meeting and conference rooms | Fixed 450 mm seat height and padded arms suit conference tables, visitor seating, and boardroom discussion areas |
| Reception and executive visitor areas | Brown upholstery and polished sled frame provide a formal appearance for reception rooms, offices, and consultation spaces | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 640 × 630 × 1040 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 14.8 kg | |
|---|---|---|
| Rated static load | 160 kg | |
| Recommended user weight | 120 kg | |
| Cantilever flex test target | 100000 cycles | |
| Back strength test target | 100 kg horizontal load | |
| Arm downward load target | 75 kg per arm | |
| Floor glide compressive rating | 100 kg per glide | |
| Seat occupancy | 1 person | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Brown leather-look surface, 1.2 mm nominal facing thickness, sewn over padded cushioning | |
|---|---|---|
| Seat foam | High-resilience polyurethane foam, 80 mm cushion thickness and 45 kg/m3 density target | |
| Back padding | Molded polyurethane padding, 50 mm lumbar thickness and 40 kg/m3 density target | |
| Support frame | Polished chrome-plated steel cantilever tube, 32 mm diameter and 1.5 mm wall target | |
| Arm pads | Padded brown upholstered pads on chromed steel supports, 35 mm visible pad thickness | |
| Floor protection | Black non-marking polymer glides fitted at four sled-frame contact ends |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed cantilever support | Continuous chrome sled frame provides controlled sprung flex without casters, tilt mechanism, or height adjustment | |
|---|---|---|
| Fixed armrest support | Integrated padded arms support forearms at 220 mm above the seat and connect directly to the side frame | |
| Contoured sitting posture | Padded seat at 450 mm and 12-degree fixed back angle support upright meeting-room posture | |
| Floor placement and stacking | Four polymer glides allow direct placement on hard floors; the chair is designed as a non-stacking fixed-leg model |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Gross weight per carton | 17.5 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Meeting and conference rooms | Fixed 450 mm seat height and padded arms suit conference tables, visitor seating, and boardroom discussion areas | |
|---|---|---|
| Reception and executive visitor areas | Brown upholstery and polished sled frame provide a formal appearance for reception rooms, offices, and consultation spaces |
EU Market Access Requirements* EN Standards
| EN 16139 non-domestic seating | Applicable strength, durability, and safety reference for contract-area visitor chairs | |
|---|---|---|
| EN 1022 seating stability | Applicable stability test reference for the fixed four-contact sled base | |
| EN 14465 upholstery abrasion | Applicable upholstery fabric/coated-material performance reference for wear disclosure |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4 lounge and public seating | Applicable reference for static load, back force, leg strength, and stability in public seating | |
|---|---|---|
| ANSI/BIFMA e3 furniture sustainability | Optional multi-attribute sustainability declaration for material, energy, and social impacts |
Standards applicable to China-market projects
| GB/T 10357.2 furniture mechanical test | Applicable test reference for backrest strength and durability of this fixed seating product | |
|---|---|---|
| GB/T 10357.3 furniture mechanical test | Applicable test reference for seat front-edge static and fatigue loading | |
| GB/T 27924 laboratory furniture seating | Useful reference for industrial and commercial seating safety requirements when used in workplace meeting areas |
This product must meet the following technical requirements: 1. GB/T 10357.2 furniture mechanical test: Applicable test reference for backrest strength and durability of this fixed seating product; 2. GB/T 10357.3 furniture mechanical test: Applicable test reference for seat front-edge static and fatigue loading; 3. GB/T 27924 laboratory furniture seating: Useful reference for industrial and commercial seating safety requirements when used in workplace meeting areas; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
