PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	680 × 730 × 1050 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Chair net weight	16 kg
Rated occupant load	120 kg
Static proof load for seat	880 kg equivalent
Backrest static test force	90 kgf
Armrest downward load	55 kgf per arm
Cantilever cyclic durability	120,000 cycles
Floor glide contact load	4 POM contact points
Seating capacity	1 person
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Upholstery	Orange upholstered outer cover with visible edge stitching; material grade requires supplier BOM confirmation.
Seat cushion	Padded cushion of 70 mm visible side thickness, using high-resilience polyurethane foam as procurement target.
Back cushion	Contoured upholstered back pad over a rigid load-bearing inner shell.
Arm pads	Integrated upholstered arm and side pads, 80 mm wide, connected to the seat-back shell.
Inner support shell	Molded board or composite support shell with 12 mm target thickness.
Cantilever frame	Chrome-plated welded steel tube, 25 mm diameter target, formed as a continuous sled base.

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Fixed high-back support	The 650 mm back above the seat provides upper-back and shoulder-area support without recline adjustment.
Cantilever flex seating	The continuous chrome sled frame allows controlled flex under the occupant while maintaining a fixed seat height.
Integrated arm support	Fixed padded arms provide a 620 mm floor-to-arm resting height and 80 mm contact width.
Floor protection and stacking restriction	Four polymer glides protect flooring; the fixed high-back frame is not designed as a stackable chair.

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Reception and meeting areas	Use for visitor seating in corporate lobbies, meeting rooms, and executive reception zones because of the high back and fixed sled base.
Professional consultation spaces	Suitable for banks, clinics, showrooms, and hotel business areas where a 120 kg-rated, easy-to-clean upholstered guest chair is required.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture seating strength	EN 16139
Formaldehyde emissions	EN 16516

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Commercial seating evaluation	Recommended references: ANSI/BIFMA X5.4
Furniture VOC emissions	Recommended references: ANSI/BIFMA e3

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Furniture mechanical safety	GB/T 10357.2, GB/T 10357.3, and GB/T 10357.6
Furniture general safety	GB 28007

Standardized tender description text

This product must meet the following technical requirements:
1. Furniture mechanical safety: GB/T 10357.2, GB/T 10357.3, and GB/T 10357.6;
2. Furniture general safety: GB 28007;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · FG-1786C

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · FG-1786C

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · FG-1786COpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Upholstered High-Back Visitor Chair with Chrome Cantilever Sled Base, model FG-1786C, presents a polished guest-seating solution defined by its vibrant orange upholstery, tall structured backrest, and reflective chrome frame. Its visual character balances soft, padded surfaces with the clean linear geometry of a continuous cantilever sled base. The seat, back, arm pads, and side pads are coordinated in the same upholstered finish, with visible edge stitching adding definition to the cushioned forms. Integrated armrests connect visually and structurally to the seat-back assembly, while four black polymer glides complete the tailored, commercial appearance. Overall dimensions are 680 millimeters wide, 730 millimeters deep, and 1050 millimeters high, with a 540-millimeter clear width between the arms. Construction centers on a contoured upholstered back pad mounted over a rigid load-bearing inner shell. The target inner support is a molded board or composite shell with a 12-millimeter thickness. The seat uses a padded cushion with a 90-millimeter finished cushion thickness and a 70-millimeter visible side thickness; high-resilience polyurethane foam is identified as the procurement target. The backrest padding is 70 millimeters thick and includes a 240-millimeter lumbar support zone. The frame is a chrome-plated, welded steel tube cantilever formed as a continuous sled base, with a 25-millimeter tube diameter specified as the target. Padded arm pads provide an 80-millimeter contact width, and the floor-contacting system uses four POM glide points. Functionally, the chair offers fixed high-back support rather than recline adjustment. The back rises 650 millimeters above the seat to support the upper back and shoulder area. The cantilever frame permits controlled flex while retaining a fixed seat height, giving the chair a responsive feel without the complexity of moving mechanisms. The fixed padded arms provide resting support at 620 millimeters from the floor. Polymer glides help protect flooring, and the chair is not intended for stacking. Its rated occupant load is 120 kilograms, and the cantilever structure is listed for 120,000 cyclic durability cycles. This model is well suited to corporate lobbies, meeting rooms, executive reception areas, banks, clinics, showrooms, and hotel business spaces. The high-back silhouette conveys a more formal reception character, while the upholstered surfaces suit professional consultation and visitor settings. It can also serve refined residential workspaces or statement seating in a residential study where a fixed, supportive guest chair is preferred. Procurement planning should account for unbranded supply, supplier confirmation of upholstery grade through the bill of materials, and verification of target foam and frame specifications before order release. Each set ships in two cartons, with a packaged gross weight of 23 kilograms, 0.26 cubic meters of carton volume, and a reference assembly time of 40 minutes. The indicated 20GP loading is 135 sets at 85 percent space utilization.

Upholstered High-Back Visitor Chair with Chrome Cantilever Sled Base Specifications
