Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 690 x 710 x 1320 mm | |
|---|---|---|
| Seat width | 550 mm | |
| Seat depth | 500 mm | |
| Seat height adjustment range | 560 mm | |
| Backrest height | 850 mm | |
| Backrest width | 530 mm | |
| Armrest height above seat | 220 mm | |
| Five-star base diameter | 700 mm | |
| Extended footrest length | 380 mm | |
| Caster diameter | 50 mm | |
| Seat cushion thickness | 120 mm | |
| Lumbar support pad thickness | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended user weight capacity | 180 kg | |
|---|---|---|
| Net weight | 22 kg | |
| Swivel rotation | 360 degrees | |
| Maximum recline angle | 155 degrees | |
| Gas lift stroke length | 100 mm | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Warranty period | 60 months | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick PU leather, stitch-sewn with 8mm seam pitch | |
|---|---|---|
| Seat cushion core | High-density molded polyurethane foam | |
| Backrest padding | Layered high-density foam with integrated lumbar pillow | |
| Armrest structure | Padded PU-wrapped with chrome trim strip and brown accent panel | |
| Five-star base | 1.5mm thick chrome-plated polished steel | |
| Caster wheels | Dual-wheel black PU casters with chrome accent ring | |
| Internal support frame | 2.0mm thick welded steel tube frame | |
| Recline mechanism chassis | 3.0mm thick steel plate with tension adjustment | |
| Retractable footrest | Chrome-finished steel frame with padded PU top | |
| Gas lift cylinder | Class 3 chrome-plated steel pneumatic cylinder | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Pneumatic seat height adjustment | 140mm height travel via right-side lever, locks at desired position | |
|---|---|---|
| Recline function with tension control | Side knob adjusts tilt tension, locks backrest at any angle up to 155 degrees | |
| 360-degree swivel rotation | Smooth full rotation around central gas lift axis for workstation access | |
| Retractable pull-out footrest | Slides out from under seat to support legs during reclined rest positions | |
| Fixed padded armrests | Stationary upholstered arms provide consistent upper body support | |
| Integrated lumbar support | Contoured padded section aligns with lower back to reduce sitting strain | |
| Smooth-rolling casters | Dual wheels roll freely on hard and soft flooring without scratching | |
| Upright position lock | Mechanism locks backrest fully upright for focused desk work | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive office use | Suitable for private manager/executive offices for long-duration desk work and short rest | |
|---|---|---|
| Home office workspace | Ideal for premium home office setups requiring professional comfort and styling | |
| Conference room leadership seating | Appropriate for boardroom or high-level meeting room principal seating | |
| Private study room use | Suitable for home study spaces supporting both work and reclined relaxation | |
| Reception executive area | Can be used in VIP reception areas to accommodate senior visitors | |
| Recommended floor surface | Suitable for use on hard tile, wood, and low-pile carpet flooring | |
| Target user group | Designed for adult office workers requiring lumbar support and recline function | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair dimensional and safety requirement benchmarks | |
|---|---|---|
| EN 1335-2:2018 | Applies to office chair structural strength and durability test methods | |
| EN 1335-3:2018 | Applies to office chair stability and safety performance verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general-purpose office chair strength, durability, and stability standards | |
|---|---|---|
| ANSI/BIFMA X5.11-2015 | Applies to heavy-duty office chair load capacity and performance benchmarks | |
| Caster rolling durability | 40000 cycles | |
| Base static load rating | 1136 kg |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office chair dimensional accuracy and stability testing requirements | |
|---|---|---|
| GB/T 3324-2017 | Applies to general technical requirements for wooden and upholstered furniture | |
| GB 28007-2011 | Applies to strength and durability testing for office swivel chairs |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office chair dimensional accuracy and stability testing requirements; 2. GB/T 3324-2017: Applies to general technical requirements for wooden and upholstered furniture; 3. GB 28007-2011: Applies to strength and durability testing for office swivel chairs; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
