Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 740 × 760 × 1080 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 24 kg | |
|---|---|---|
| Recommended user weight | 160 kg | |
| Static seat load verification target | 240 kg | |
| Backrest static load verification target | 120 kg | |
| Seating capacity | 1 person | |
| Swivel bearing design target | 100,000 cycles | |
| Arm downward load target | 680 N per arm | |
| Floor contact points | 4 glides | |
| Warranty target | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Black full-grain appearance leather or corrected-grain leather cover, 1.4 mm thickness | |
|---|---|---|
| Alternative upholstery option | Black polyurethane leather, 1.2 mm thickness, 50,000-cycle abrasion target | |
| Seat foam | Molded polyurethane cushion, 90 mm thickness and 45 kg/m3 density | |
| Back foam | Molded polyurethane back padding, 40 mm thickness and 35 kg/m3 density | |
| Foam resilience target | 35 percent ball rebound | |
| Internal back shell | 12 mm molded plywood or 8 mm reinforced polymer panel | |
| Arm pads | Black upholstered padding over rigid arm form with tailored edge stitching | |
| Arm supports | Polished die-cast aluminum or chrome-plated steel brackets, 3 mm wall target | |
| Swivel column | Polished chrome-plated steel tube, 50 mm diameter and 2.0 mm wall target | |
| Four-prong base | Polished aluminum or chrome-plated steel cantilever base, 700 mm footprint | |
| Floor glides | Four non-marking polymer glides with black wear pads, 35 mm diameter | |
| Seam construction | Tailored stitched upholstery with 8stitches per 50 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 360-degree swivel | Central column rotates the seat and back through 360 degrees for conversational positioning | |
|---|---|---|
| Stationary base | Four-prong glide base provides fixed placement without casters for executive lounge use | |
| High-back support | 680 mm high back provides shoulder and upper-back support for upright-relaxed seating | |
| Integrated arm support | Padded fixed armrests at 220 mm above seat support forearm resting during meetings | |
| Floor protection | Four 35 mm polymer glides distribute load and reduce floor scratching on hard surfaces | |
| Manual positioning | Glide base allows limited repositioning by lifting or sliding, with no gas-height control visible | |
| Posture type | Fixed lounge posture with 100-degree back angle for executive reception seating | |
| Color option count | 1 standard black upholstery finish with polished metal base | |
| Cleaning access | Smooth upholstered faces and open four-prong base permit vacuuming and floor cleaning beneath the seat | |
| Swivel column diameter | 50 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Placed behind or beside a management desk for high-back visitor or relaxed executive seating | |
|---|---|---|
| Meeting room | Used around conference or negotiation tables where swivel access and stationary placement are preferred | |
| Reception lounge | Suitable for premium reception seating with a compact 740 mm footprint and glide-protected floor contact | |
| Boardroom lounge zone | Pairs with sofas or side tables in breakout and pre-meeting areas for single-person support | |
| Hotel executive lounge | Suitable for hotel business lounges requiring tailored black upholstery and durable metal construction | |
| Private study | Fits residential studies or home executive rooms as a fixed-position desk-side or reading chair | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Seating strength and durability | EN 16139, applicable to non-domestic seating strength and durability requirements | |
|---|---|---|
| Upholstered furniture burning behavior | EN 1021and EN 1021applicable to ignition by smouldering cigarette and match flame | |
| Office chair dimensions | EN 1335applicable to dimensional terminology and office-chair measurement methods | |
| Office chair safety and stability | EN 16139 or EN 1335applicable according to final task-chair or lounge-chair classification |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture flammability consideration | GB 17927, applicable to combustion behavior requirements for upholstered furniture and mattresses | |
|---|---|---|
| Formaldehyde emission consideration | GB/T 39600, applicable to formaldehyde emission classification for wood-based panels in furniture structures | |
| Furniture mechanical test consideration | GB/T 10357, applicable to strength, durability, and stability test methods for seating furniture |
This product must meet the following technical requirements: 1. Upholstered furniture flammability consideration: GB 17927, applicable to combustion behavior requirements for upholstered furniture and mattresses; 2. Formaldehyde emission consideration: GB/T 39600, applicable to formaldehyde emission classification for wood-based panels in furniture structures; 3. Furniture mechanical test consideration: GB/T 10357, applicable to strength, durability, and stability test methods for seating furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
