Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 700 × 750 × 1180 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight (reference) | 28 kg | |
|---|---|---|
| Maximum static user weight capacity | 180 kg | |
| Cushion foam density | 45 kg/m³ | |
| Gas lift height adjustment stroke | 100 mm | |
| Caster rolling durability cycles | 50000 | |
| Seat static load test capacity | 136 kg | |
| Tilt mechanism lock positions | 3 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat/back/headrest upholstery | 0.8mm thick matte PU faux leather | |
|---|---|---|
| Seat/back cushion fill | High-density polyurethane foam | |
| Five-star base | 1.5mm thick chrome-plated polished steel | |
| Armrest frame | Chrome-plated steel with padded PU top | |
| Casters | 50mm diameter dual-wheel polyurethane casters | |
| Gas lift | Class 3 steel gas lift | |
| Tilt/recline mechanism | 2.5mm thick stamped steel chassis | |
| Retractable footrest | Steel support frame with padded PU top | |
| Lower side panel trim | Textured dark grey mesh fabric panel | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 360-degree swivel rotation | Unrestricted 360-degree rotation enabled by central gas lift and base | |
|---|---|---|
| Pneumatic seat height adjustment | 100mm vertical adjustment via right-side gas lift lever | |
| Multi-position backrest recline | Reclines up to 160 degrees from vertical with 3 lockable positions | |
| Retractable sliding footrest | Pull-out footrest extends from under seat for leg support when reclined | |
| Smooth rolling mobility | 5 dual-wheel casters allow movement on hard and carpeted office floors | |
| Fixed padded armrests | Soft padded fixed armrests provide forearm support at work and rest height | |
| Integrated contoured headrest | Attached raised headrest supports neck and head in upright and reclined positions | |
| Reclined backrest maximum angle from vertical | 160 degrees | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Provides comfortable upright support for desk work and recline rest for managers | |
|---|---|---|
| Home office workspace | Reclining function and footrest support extended work and rest at home | |
| Meeting room for senior management | Padded comfort supports long meetings and discussion sessions | |
| Manager reception area | Professional appearance and guest comfort for visitor meetings | |
| Daily work for users 160-190cm tall | Adjustable height and contoured padding fit a wide range of adult body sizes | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair dimensional and safety requirements for work seating | |
|---|---|---|
| EN 1335-2:2018 | Applies to office chair mechanical performance and stability requirements | |
| EN 1021-1:2014 | Applies to upholstered furniture ignitability resistance to smouldering cigarettes |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general purpose office chair strength, durability and stability |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office chair dimensional measurement and tolerance requirements | |
|---|---|---|
| GB/T 10357.3-2013 | Applies to office chair mechanical strength and stability testing | |
| GB 18584-2001 | Applies to limit of harmful substances in wooden and upholstered furniture |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office chair dimensional measurement and tolerance requirements; 2. GB/T 10357.3-2013: Applies to office chair mechanical strength and stability testing; 3. GB 18584-2001: Applies to limit of harmful substances in wooden and upholstered furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
