Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 740 × 680 × 1270 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Suggested user weight capacity | 150 kg | |
|---|---|---|
| Net weight range | 21 kg | |
| Static base verification load | 70 kg | |
| Seat impact acceptance cycles | 100000 cycles | |
| Caster rolling durability | 100000 cycles | |
| Gas-lift vertical travel | 40 mm | |
| Recommended daily user duration | 8 hours | |
| Color options | 1 visible color | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Beige padded leather-look surface with segmented horizontal stitching | |
|---|---|---|
| Back cushioning | Molded high-resilience foam pad, 85 mm visible outer thickness | |
| Seat cushioning | Thick contoured foam cushion with rounded front edge | |
| Armrest assemblies | Padded top with dark wood-finish side panels and solid support brackets | |
| Center support and base | Chromed metal gas-lift column and five-star caster base | |
| Casters | Twin-wheel swivel casters with dark tire and hub housing |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Pneumatic gas-lift lever raises and lowers the seat within a 40 mm total chair-height interval | |
|---|---|---|
| Swivel movement | 360-degree swivel around the central gas-lift column | |
| Recline function | Multi-position tilt mechanism with rear recline and tension control | |
| Mobility | Five-point base with twin-wheel casters supports rolling movement across office floors |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packed carton size | 800 x 700 x 680 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Recommended Matching Desk Size | 2.4 m executive desk | |
|---|---|---|
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.1 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
