PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	640 × 720 × 1030 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	136 kg
Net weight	17.5 kg
Shipping gross weight	19.5 kg
Back support rating	136 kg
Seat static-load verification target	710 N downward for 1 hour
Caster rolling durability target	100,000 cycles
Gas-lift cyclic durability target	100,000 height cycles
Tilt mechanism fatigue target	300,000 cycles
Five-star base static-load target	1,134 kg downward for 1 minute
Recommended occupant weight capacity	136 kg

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat and back upholstery	Dark gray padded upholstered shell with visible seam-defined panels; exact leather or PU grade requires supplier BOM confirmation.
Cushion construction	Molded polyurethane foam pad with a 60 mm seat thickness and 45 kg/m3 density target; cross-section is not exposed in the image.
Back cushioning	Integrated padded back with a 40 mm foam target and 35 kg/m3 density target for executive-chair support.
Armrests	Upholstered padded arm pads over dark support housings; arm height above seat is visibly 180 mm.
Internal frame	12 mm plywood or steel-reinforced seat carrier target; frame material is concealed and requires BOM confirmation.
Metal mechanism	Black synchronized tilt mechanism with steel plate housing visible beneath the seat.

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Height adjustment	Pneumatic seat-height control using the right-side lever, with 30 mm marked total-height adjustment travel.
Swivel function	Full 360-degree seat rotation on the central gas-lift swivel bearing and five-star base.
360-degree swivel	Seat and back rotate 360 degrees around the central gas-lift swivel bearing.
Recline and lock	Multi-position tilt mechanism allows back recline through 15 degrees and locks in 3 positions.

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Executive office workstation	Suited to managers and professional staff at 720 to 760 mm high desks, using the 100 mm gas-lift range and fixed padded arms.
Conference and meeting room	Appropriate for 1 to 3 hour meetings around boardroom tables, where 360-degree swivel and quiet twin-wheel casters improve access.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFC-MB-PAD-640

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFC-MB-PAD-640

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFC-MB-PAD-640Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mid-Back Upholstered Swivel Executive Office Chair, model OFC-MB-PAD-640, presents a professional executive seating form with a dark gray upholstered seat and back. Its padded shell is organized by visible seam-defined panels, giving the backrest a structured, tailored appearance suited to conventional office interiors. Upholstered arm pads sit above dark support housings, while the polished aluminum five-star base and chrome gas lift provide a brighter visual contrast against the dark seating body. Black twin-wheel casters complete the mobile base. Overall dimensions are 640 x 720 x 1030 mm, with a 90 mm finished seat cushion, 70 mm backrest padding, a 240 mm lumbar support zone, and 540 mm clear width between the armrests. Construction combines padded comfort with a conventional office-chair mechanism. The seat uses a molded polyurethane foam pad with a 60 mm seat-foam thickness and 45 kg/m3 density target, while the integrated back cushioning targets 40 mm foam at 35 kg/m3. The arm pads are upholstered and padded, with arm height above the seat visibly set at 180 mm. Beneath the seat, a black synchronized tilt mechanism with a visible steel plate housing links the seating structure to the central chrome gas lift and polished aluminum base. The internal seat carrier is specified as a 12 mm plywood or steel-reinforced target, and the exact upholstery grade, including leather or PU content, should be confirmed through the supplier bill of materials before purchase. Functional features support everyday desk and meeting use. A right-side lever controls pneumatic seat-height adjustment, with 30 mm marked total-height adjustment travel and a 100 mm gas-lift range noted for desk compatibility. The seat and back rotate a full 360 degrees around the central gas-lift swivel bearing. The multi-position tilt mechanism allows 15 degrees of back recline and locks in three positions. The chair carries a recommended user weight capacity of 136 kg and a matching back support rating. Published verification targets include a 710 N downward seat static load for one hour, 100,000 caster rolling cycles, and 100,000 gas-lift height cycles. This unbranded chair is suitable for executive workstations and managers' or professional staff offices, particularly with desks 720 to 760 mm high. It is also appropriate for conference and meeting rooms for meetings lasting one to three hours, where swivel movement and twin-wheel casters help users access seating around boardroom tables. Procurement teams should plan for one set supplied across two cartons, a packaged gross weight of 23 kg per set, and 40 minutes of assembly time per chair. Carton dimensions are 850 x 420 x 720 mm, with carton volume at 0.26 m3 per set and an indicative 20GP loading figure of 135 sets at 85 percent space utilization. Buyers seeking explicit material grades or internal frame composition should request BOM confirmation before finalizing specifications or bulk orders.
