Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 701 x 759 x 1190 mm | |
|---|---|---|
| seat width | 627 mm | |
| seat depth | 546 mm | |
| seat height adjustment range | 570 mm | |
| five-star base diameter | 700 mm | |
| caster diameter | 50 mm | |
| backrest height | 780 mm | |
| armrest height from seat | 220 mm | |
| footrest extension length | 420 mm | |
| lumbar cushion thickness | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| net weight | 28 kg | |
|---|---|---|
| maximum static load capacity | 181 kg | |
| gas lift cycle rating | 120000 cycles | |
| recline mechanism lock positions | 4 positions | |
| upholstery abrasion resistance | 50000 double rubs | |
| seat foam density | 50 kg/m³ | |
| back foam density | 35 kg/m³ | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| seat and back upholstery | 1.2mm thick khaki faux leather with dark accent stripe | |
|---|---|---|
| seat cushion core | High-density polyurethane foam with contoured shaping | |
| backrest padding | Dual-layer foam with attached matching lumbar pillow | |
| armrest structure | Padded faux leather top with polished dark resin end caps | |
| internal support frame | 12mm thick plywood reinforced with 1.5mm steel tubing | |
| five-star base | 1.8mm thick chrome-plated polished steel | |
| gas lift cylinder | Class 4 chrome-plated steel, 50mm outer diameter | |
| dual-wheel casters | Black polypropylene housing with polyurethane tread | |
| recline lever hardware | Chrome-plated steel control switch mounted on left seat side | |
| retractable footrest frame | Chrome-plated steel support with padded faux leather top | |
| upholstery stitching | 8 stitches per inch matching khaki thread | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full rotation enabled by central gas lift and five-star base | |
|---|---|---|
| pneumatic seat height adjustment | 120mm vertical travel via side-activated gas lift | |
| multi-position back recline | 170-degree maximum recline angle with tension control | |
| retractable under-seat footrest | 420mm pull-out extension for reclined leg support | |
| fixed padded armrests | Ergonomic curved support for forearm rest during seated work | |
| recline tension adjustment | Knob-controlled resistance to match user body weight | |
| smooth rolling mobility | Dual-wheel casters suitable for hard tile and wood floors | |
| integrated lumbar support | Attached padded pillow provides lower back alignment | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| shipping carton dimensions | 900 x 450 x 600 mm | |
|---|---|---|
| gross shipping weight | 28 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive private office | Suitable for manager/executive workstations requiring long-sitting comfort | |
|---|---|---|
| Home office study | Fits residential workspace with recline function for short breaks during work | |
| Conference reception room | Provides premium guest seating for formal business meeting spaces | |
| Executive lounge area | Supports relaxed posture for casual discussions or short rest periods | |
| Recommended users | Suits adult users 190 cm tall requiring ergonomic back and leg support | |
| Recommended flooring | Performs on hard tile, wood and low-pile carpeted office surfaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair dimensional, safety and strength requirements | |
|---|---|---|
| EN 1335-2:2018 | Applies to office chair mechanical stability and structural performance testing | |
| EN 1335-3:2009 | Applies to office chair test methods for structural and safety verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general-purpose office chair safety and durability performance standards | |
|---|---|---|
| ANSI/BIFMA X5.4-2021 | Applies to lounge and executive seating additional strength requirements | |
| caster rolling durability | 40000 cycles |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office furniture chair dimensional accuracy and stability testing | |
|---|---|---|
| GB/T 27717-2011 | Applies to upholstered office chair mechanical safety and durability requirements | |
| GB 18584-2001 | Applies to furniture formaldehyde and heavy metal emission limits for interior use |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office furniture chair dimensional accuracy and stability testing; 2. GB/T 27717-2011: Applies to upholstered office chair mechanical safety and durability requirements; 3. GB 18584-2001: Applies to furniture formaldehyde and heavy metal emission limits for interior use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
