Walnut Wood Grain Sliding Door Low Profile TV Console with Dual-Tier Open Central Media Shelves and Stepped Plinth Base (model TVC-PLINTH-SLD-1800-WAL) is listed under Pantry Cabinet. Dimensions: 2000 × 400 × 600 mm. Materials: 13mm MDF core with walnut wood grain thermally fused laminate surface. Load capacity: 160 kg. Product Features: modern,style,low,profile,media,storage,sliding,door,construction,fixed,open,shelving,plinth,base. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | GUANGLI | Model | TVC-PLINTH-SLD-1800-WAL |
| Overall dimensions (W × D × H) | 2000 × 400 × 600 mm | Top panel thickness | 13 mm |
| Plinth base floor clearance | 140 mm | Central open bay width | 680 mm |
| Upper central open shelf height | 230 mm | Lower central open shelf height | 230 mm |
| Sliding door panel thickness | 18 mm | Fixed central divider shelf thickness | 18 mm |
| Carcass side panel thickness | 18 mm | Back panel thickness | 5 mm |
| Carcass Panel Thickness | 25 mm | Door / Drawer Front Thickness | 22 mm |
| Shelf Thickness | 25 mm | Total top surface static load capacity | 160 kg |
| Maximum supported TV screen size | 85 in | Product net weight | 43 kg |
| Sliding door hardware cycle rating | 20000 open/close cycles | Finish abrasion resistance rating | 2000 cycles |
| Shelf Distributed Load | 30 kg/shelf | Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
| Hinge Opening Angle / Life | 165°; 80000 cycles | Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years | Top panel | 13mm MDF core with walnut wood grain thermally fused laminate surface |
| Sliding door panels | 18mm particleboard core with matching vertical grain walnut laminate covering | Carcass side and bottom panels | 18mm MDF core with matching walnut laminate exterior and dark laminate interior |
| Fixed central divider shelf | 18mm MDF core with matching dark laminate interior finish | Plinth base and integrated feet | 18mm engineered wood frame with walnut laminate finish and shaped corner cutouts |
| Back panel | 5mm hardboard with dark brown finish, secured with staples to carcass rear | Sliding door track hardware | Powder-coated cold-rolled steel upper and lower tracks with nylon glides |
| Rear cable management grommets | 60mm diameter PVC grommets aligned with central open shelves | Floor protection pads | Non-marking EVA foam pads affixed to bottom of plinth feet |
| Edge Band Thickness | 2 mm | Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
| Reference Finish / Color Count | Recommended 6finish options | Left and right sliding door storage access | Horizontal sliding doors glide on steel tracks to conceal side storage compartments, full access to side bays when fully open |
| Fixed dual-tier central open storage | Two equal-height fixed open shelves sized to hold AV receivers, set-top boxes, and media players without door obstruction | Rear cable routing system | Two rear cable grommets aligned to each central shelf for routing power and AV cords between devices and wall outlets |
| Side compartment internal adjustability | Two position-adjustable shelves inside each door-enclosed side bay for flexible storage of media accessories and items | Floor standing installation | Fully assembled plinth base sits directly on finished flooring with no wall anchoring required for standard use |
| Ventilation for electronic devices | Open front bays and rear cable openings provide passive air circulation to prevent heat buildup on powered AV equipment | Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | Reference Packaged Gross Weight | 100 kg/set in 3 cartons |
| Reference Packaging Volume | 0.65 m³/set | Residential living room installation | Positioned against a wall beneath wall-mounted or freestanding televisions for media equipment and accessory storage |
| Home theater and media room use | Provides open storage for AV electronics and concealed storage for media collections, remotes, and accessories | Apartment and condo small space layout | Low profile depth and height fits compact living spaces without blocking wall outlets or sightlines to the screen |
| Modern and mid-century modern interior schemes | Walnut wood grain finish and clean minimalist lines coordinate with contemporary and retro-modern furniture styles | Primary display surface for TVs up to 85 inches | Full-length flat top supports large screen televisions with proper weight distribution and overhang clearance |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2000 × 400 × 600 mm | |
|---|---|---|
| Top panel thickness | 13 mm | |
| Plinth base floor clearance | 140 mm | |
| Central open bay width | 680 mm | |
| Upper central open shelf height | 230 mm | |
| Lower central open shelf height | 230 mm | |
| Sliding door panel thickness | 18 mm | |
| Fixed central divider shelf thickness | 18 mm | |
| Carcass side panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total top surface static load capacity | 160 kg | |
|---|---|---|
| Maximum supported TV screen size | 85 in | |
| Product net weight | 43 kg | |
| Sliding door hardware cycle rating | 20000 open/close cycles | |
| Finish abrasion resistance rating | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | 13mm MDF core with walnut wood grain thermally fused laminate surface | |
|---|---|---|
| Sliding door panels | 18mm particleboard core with matching vertical grain walnut laminate covering | |
| Carcass side and bottom panels | 18mm MDF core with matching walnut laminate exterior and dark laminate interior | |
| Fixed central divider shelf | 18mm MDF core with matching dark laminate interior finish | |
| Plinth base and integrated feet | 18mm engineered wood frame with walnut laminate finish and shaped corner cutouts | |
| Back panel | 5mm hardboard with dark brown finish, secured with staples to carcass rear | |
| Sliding door track hardware | Powder-coated cold-rolled steel upper and lower tracks with nylon glides | |
| Rear cable management grommets | 60mm diameter PVC grommets aligned with central open shelves | |
| Floor protection pads | Non-marking EVA foam pads affixed to bottom of plinth feet | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Left and right sliding door storage access | Horizontal sliding doors glide on steel tracks to conceal side storage compartments, full access to side bays when fully open | |
|---|---|---|
| Fixed dual-tier central open storage | Two equal-height fixed open shelves sized to hold AV receivers, set-top boxes, and media players without door obstruction | |
| Rear cable routing system | Two rear cable grommets aligned to each central shelf for routing power and AV cords between devices and wall outlets | |
| Side compartment internal adjustability | Two position-adjustable shelves inside each door-enclosed side bay for flexible storage of media accessories and items | |
| Floor standing installation | Fully assembled plinth base sits directly on finished flooring with no wall anchoring required for standard use | |
| Ventilation for electronic devices | Open front bays and rear cable openings provide passive air circulation to prevent heat buildup on powered AV equipment | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room installation | Positioned against a wall beneath wall-mounted or freestanding televisions for media equipment and accessory storage | |
|---|---|---|
| Home theater and media room use | Provides open storage for AV electronics and concealed storage for media collections, remotes, and accessories | |
| Apartment and condo small space layout | Low profile depth and height fits compact living spaces without blocking wall outlets or sightlines to the screen | |
| Modern and mid-century modern interior schemes | Walnut wood grain finish and clean minimalist lines coordinate with contemporary and retro-modern furniture styles | |
| Primary display surface for TVs up to 85 inches | Full-length flat top supports large screen televisions with proper weight distribution and overhang clearance |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Furniture - storage units for domestic and contract use - safety requirements and test methods, applicable for structural safety | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety - requirements for domestic tables, applicable for top surface load verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional stability and panel strength verification | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood based furniture, applicable for formaldehyde emission verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional stability and panel strength verification; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood based furniture, applicable for formaldehyde emission verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
