PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	575 × 445 × 850 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	150 kg
Product net weight	6 kg
Maximum stacking quantity	15 units
Seat foam density	40 kg/m³
Seat upholstery abrasion resistance	30000 cycles
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles
Five-star Base Static Load Reference	Acceptance target ≥120 kg; chair reference load 150 kg
Caster Rolling Durability Reference	Acceptance target 30000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest	Injection-molded polypropylene with vertical ventilation slits
Seat cushion core	High-resilience polyurethane foam
Seat upholstery	Black woven fabric surface
Frame and legs	1.5mm thick powder-coated matte black steel tube
Leg feet	Injection-molded non-slip polypropylene caps
Seat to frame connectors	Reinforced steel bracket hardware
Armrest rests	Integrated molded PP top on front frame supports
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel
Five-star Base Material Thickness	Metal base wall 3.5 mm; diameter 700 mm

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Stackable storage design	Legs nest vertically when stacked to 15 unit height
Backrest ventilation	Vertical slotted openings provide airflow for extended sitting
Fixed seating position	Non-reclining fixed seat and back angle for upright conference use
Floor protection	Non-marking plastic feet prevent scuffing on hard floor surfaces
Integrated arm support	Front frame extensions form fixed armrests at seated elbow height
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference room use	Suitable for fixed meeting room seating in offices and training facilities
Training classroom use	Ideal for temporary training sessions requiring rapid setup and storage
Visitor waiting area use	Appropriate for public waiting zones and reception areas
Event venue seating	Suitable for temporary event seating in exhibition and community spaces
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office chair strength reference	EN 16139
Office chair stability reference	EN 1728

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Stability test reference	GB/T 10357.2
Strength and durability reference	GB/T 10357.3

Standardized tender description text

This product must meet the following technical requirements:
1. Stability test reference: GB/T 10357.2;
2. Strength and durability reference: GB/T 10357.3;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · STK-PL-047

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · STK-PL-047

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · STK-PL-047Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Unbranded STK-PL-047 Stackable Ventilated Plastic Meeting Chair is a purpose-built office conference chair designed to balance functional durability, space efficiency, and user comfort for a wide range of public and commercial seating applications. Visually, the chair features a streamlined armless form defined by clean, angular lines, with a matte black powder-coated steel frame, structured ventilated backrest, and black woven fabric seat that coordinates seamlessly with neutral commercial interiors. Its fixed non-reclining seat and back angle supports upright seated posture tailored for focused group settings, with integrated molded PP armrests formed directly on front frame supports at a natural seated elbow height. The chair’s overall dimensions measure 575 x 445 x 850 mm, with a 540 mm clear width between armrests and a 240 mm tall lumbar support zone aligned to the lower back for extended sitting comfort. Built for consistent high-use environments, the chair combines robust, thoughtfully selected materials: an injection-molded polypropylene backrest with vertical ventilation slits to promote continuous airflow, a 90 mm thick upholstered padded seat with a high-resilience polyurethane foam core set over a 14 mm bent plywood internal support board, and a 1.5 mm thick matte black powder-coated steel tube frame reinforced with steel bracket hardware connecting the seat to the frame. The 70 mm thick backrest includes a 14 mm bent plywood or composite reinforced internal frame for structural stability, while legs are fitted with non-slip, non-marking injection-molded polypropylene caps to protect hard floor surfaces from scuffs. The seat upholstery delivers 30,000 cycles of abrasion resistance, and the chair supports a maximum user weight of 150 kg, with high-resilience seat foam providing 65% rebound for long-session comfort. Key practical features center on flexible, space-conscious deployment: the stackable design allows legs to nest vertically to hold a maximum of 15 units per stack, enabling fast, compact storage when seating is not in use. The non-reclining fixed angle maintains consistent posture appropriate for group events and formal meetings, while integrated ventilation prevents heat buildup during multi-hour sessions. The chair is suited for multiple commercial and public spaces: permanent conference room seating in offices and training facilities, temporary training classroom setups that require rapid deployment and breakdown, public visitor waiting and reception areas, and temporary event seating for exhibition halls and community gathering spaces. It is recommended for daily use of up to 8 hours, subject to independent ergonomic validation, and pairs appropriately with 2.4 m executive desks for formal meeting configurations. For procurement planning, note that each chair ships in two cartons with a total packaged gross weight of 23 kg and total carton volume of 0.26 m³, requiring 40 minutes of assembly per unit. At 85% space utilization, a 20GP shipping container can hold 135 sets, supporting scalable bulk orders for large venue fit-outs or multi-site deployments.

Stackable Ventilated Plastic Meeting Chair with Padded Seat Specifications
