Name: Cantilever Mesh Back Office Conference Chair
Brand: YUXIANG
SKU: 2200AN

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	545 × 560 × 985 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Suggested user weight capacity	120 kg
Net product weight	8 kg
Recommended daily usage duration	8 hours
Cantilever frame static load rating	5000 N
Seat cushion foam density	45 kg/m³
Backrest mesh tensile strength	300 N/50mm
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles
Five-star Base Static Load Reference	Acceptance target ≥120 kg; chair reference load 150 kg

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Cantilever frame	22mm diameter chrome-plated cold-rolled steel tubing
Backrest central panel	Tensioned breathable woven polyester mesh
Backrest outer frame	Black molded polypropylene structural support
Seat cushion core	High-resilience molded polyurethane foam
Seat upholstery	Black abrasion-resistant woven polyester fabric
Armrests	Black PP molded arm pads fixed to steel frame
Frame floor glides	Non-marking nylon anti-slip foot caps
Frame weld points	TIG welded chrome-finished steel joints
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating support	Fixed cantilever sled base provides gentle flex without tilt or swivel
Back support	Contoured lumbar curve built into lower backrest panel
Arm support	Fixed height integrated armrests aligned for standard desk height use
Stacking capability	Supports vertical stacking up to 4 chairs for compact storage
Floor protection	Integrated nylon glides prevent scratching hard floor surfaces
Ventilation	Mesh back panel allows continuous air flow for extended sitting comfort
Movement restriction	No rotating, height adjustment or recline mechanism for stable visitor seating
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference room seating	Suitable for meeting rooms as fixed guest seating at standard 750mm height tables
Reception and waiting areas	Appropriate for lobbies and reception zones for short-term visitor use
Open office visitor seating	Usable at workstations for guest seating adjacent to employee desks
Training room seating	Suitable for training classrooms where lightweight, movable seating is required
Executive office guest configuration	Place two units in front of executive desks for formal visitor seating
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture safety recommendation	EN 1335:2018
Office furniture strength recommendation	EN 1728:2012

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Lounge/visitor seating durability recommendation	ANSI/BIFMA X2017

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office chair structural safety recommendation	GB/T 3326
Upholstered furniture durability recommendation	GB/T 10357.3

Standardized tender description text

This product must meet the following technical requirements:
1. Office chair structural safety recommendation: GB/T 3326;
2. Upholstered furniture durability recommendation: GB/T 10357.3;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OC-CM-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OC-CM-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OC-CM-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The YUXIANG OC-CM-01 Cantilever Mesh Back Office Conference Chair balances streamlined professional aesthetics, durable construction, and user-centric functionality for flexible seating across commercial and select residential settings. Visually, the chair features a clean, linear profile anchored by a continuous cantilever sled frame, paired with a black molded polypropylene backrest frame and breathable woven mesh central panel. The black upholstered seat and matching fixed armrests offer a cohesive, understated look that complements modern office design palettes, while the open mesh back maintains a light, uncluttered visual presence suitable for shared spaces. Built for consistent long-term use, the chair’s frame is constructed from 22mm diameter chrome-plated cold-rolled steel tubing with TIG welded, chrome-finished joints for structural integrity, finished with non-marking nylon anti-slip foot caps at the base. The seat uses a high-resilience molded polyurethane foam core with 45 kg/m³ density and 65% rebound reference, supported by a bent plywood internal board, and upholstered in black abrasion-resistant woven polyester fabric. The tensioned breathable mesh back panel delivers 300 N/50mm tensile strength, paired with a built-in contoured lumbar curve in the lower support zone, and features fixed black PP molded armrests mounted directly to the steel frame. Functionally, the fixed cantilever sled base delivers gentle, controlled flex without tilt, swivel, height adjustment or recline mechanisms for stable, distraction-free visitor seating. The mesh back enables continuous air flow to reduce heat buildup during extended sitting, while the integrated nylon glides prevent scratching on hard floor surfaces. The chair supports vertical stacking of up to 4 units to minimize storage footprint when not in use, and is engineered to support a suggested user weight capacity of 120 kg for up to 8 hours of daily use. This model is well suited for a range of commercial spaces, including conference rooms as guest seating paired with standard height tables, reception and waiting lobbies, open office workstations for adjacent visitor use, training classrooms requiring lightweight movable seating, and executive offices where two units can be placed in front of executive desks for formal guest arrangements. For procurement, teams should note that each unit ships across two cartons, requires roughly 40 minutes of assembly per set, and can be loaded in quantities aligned with standard 20GP container capacity to streamline bulk order planning. The fixed armrest height is calibrated for standard desk height use, making pre-installation space planning a straightforward step for large-scale rollouts.
