Product supplierMid-back ergonomic mesh cantilever office visitor chair, White finished glass-fiber reinforced polypropylene
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 620 × 605 × 1100 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight per chair | 10 kg | |
|---|---|---|
| Maximum static user weight capacity | 136 kg | |
| Seat cushion foam density | 65 kg/m³ | |
| Seat foam thickness | 70 mm | |
| Back mesh tensile durability | 100000 flex cycles | |
| Frame static load capacity | 272 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Backrest support frame | White finished glass-fiber reinforced polypropylene | |
|---|---|---|
| Backrest surface | Grey polyester breathable office mesh | |
| Seat cushion core | High-density molded polyurethane foam | |
| Seat upholstery | Wear-resistant polyester fabric over foam | |
| Fixed armrests | Integrated white polypropylene loop connected to seat and back frame | |
| Cantilever sled base | 1.5mm wall thickness white painted steel tube | |
| Floor contact glides | Anti-slip polypropylene pads at base contact points | |
| Internal back support structure | Polypropylene internal rib frame under mesh | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Positioning design | Fixed non-swivel, non-height-adjustable design for meeting/visitor use | |
|---|---|---|
| Back support feature | Integrated contoured lumbar support zone in lower mesh back | |
| Seat edge design | Waterfall front seat edge to reduce leg pressure | |
| Base stability feature | Cantilever sled base with anti-slip glides to prevent floor scratching | |
| Armrest function | Fixed curved loop armrests providing stable upper limb support | |
| Seating application | No recline, no rotation, no tilt mechanism for stable short-duration seating | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packed carton dimensions | 680 x 680 x 1150 mm | |
|---|---|---|
| Packed gross weight per unit | 12 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Conference room seating | Suitable for fixed meeting room rows due to compact footprint and stable sled base | |
|---|---|---|
| Reception area visitor seating | Ideal for front desk reception zones with clean white frame and breathable back | |
| Training room seating | Appropriate for training spaces requiring durable, low-maintenance fixed seating | |
| Open office guest seating | Suitable for desk side visitor positions in open plan workspaces | |
| Waiting area seating | Ideal for office waiting areas with breathable mesh for extended short-term comfort | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture safety applicability | EN 1335:2018 Office furniture - Office work chair - Part 2: Safety requirements | |
|---|---|---|
| Office furniture strength applicability | EN 16139:2013 Furniture - Strength, durability and safety - Non-domestic seating |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Office chair size standard applicability | GB/T 3326Furniture - Tables and chairs - Determination of dimensions | |
|---|---|---|
| Formaldehyde emission applicability | GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission in wood-based furniture and finishing materials |
Standardized tender description text
This product must meet the following technical requirements: 1. Office chair size standard applicability: GB/T 3326Furniture - Tables and chairs - Determination of dimensions; 2. Formaldehyde emission applicability: GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission in wood-based furniture and finishing materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
