PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	595 × 620 × 1005 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight per unit	12 kg
Static seat load capacity	150 kg
Recommended maximum user weight	120 kg
Frame static load rating (per cantilever arm)	80 kg
Backrest mesh tensile strength	180 N
Seat foam density	45 kg/m³
Seat foam rebound rate	42 %
Design service life under daily office use	5 years
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support panel	Reinforced polypropylene internal frame
Backrest upholstery	Tensioned polyester breathable mesh
Seat cushion padding	High-resilience molded polyurethane foam, 60mm thickness
Seat upholstery	Breathable black woven fabric
Armrest pads	Soft polyurethane padded caps
Structural frame	Chrome-plated cold-rolled steel tubing, 1.5mm wall thickness
Floor contact glides	Injection-molded nylon non-slip pads
Seat support plate	2mm thick stamped steel under-seat bracket
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Movement type	Zero-swivel fixed cantilever sled design
Adjustment features	No height, tilt, or armrest adjustment mechanisms
Back support design	Ergonomic contoured lumbar support integrated into back frame
Mobility feature	Non-caster glide base for sliding on hard floors
Back flex function	Flexible mesh back with 10-degree recline give under user weight
Seat edge design	Contoured waterfall front seat edge
Stacking capability	Non-stacking fixed frame design
Armrest function	Fixed-height curved armrests for forearm support
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Primary office application	Conference and meeting rooms
Reception area application	Lobby and guest waiting zones
Training room application	Staff training and presentation rooms
Cubicle visitor seating application	Workstation side guest seating
Flooring compatibility	Suitable for hard wood, tile, and carpeted office floors
User group suitability	Designed for adult office workers and visitors
Cleaning suitability	Easy-maintenance mesh and fabric surfaces suitable for daily janitorial care
Recommended Matching Desk Size	2.4 m executive desk

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Applicable office furniture structural stability standard	EN 1335:2018
Applicable office furniture safety standard	EN 1022:2018
Applicable surface flammability standard	EN 1021:2014
Applicable metal corrosion resistance standard	EN 12542:2000

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Applicable visitor chair static load standard	ANSI/BIFMA X2017Clause 5
Applicable backrest durability test standard	ANSI/BIFMA X2017Clause 8
Applicable seating stability standard	ANSI/BIFMA X2017Clause 13
Applicable floor protection standard	ANSI/BIFMA X2017Clause 18

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Applicable standard for general office chairs	GB/T 3326
Applicable hardware surface coating standard	GB/T 3324
Applicable upholstery fabric durability standard	GB/T 21295
Applicable furniture safety standard	GB 28007

Standardized tender description text

This product must meet the following technical requirements:
1. Applicable standard for general office chairs: GB/T 3326;
2. Applicable hardware surface coating standard: GB/T 3324;
3. Applicable upholstery fabric durability standard: GB/T 21295;
4. Applicable furniture safety standard: GB 28007;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OC-CAN-MSH-001

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OC-CAN-MSH-001

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OC-CAN-MSH-001Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mesh Back Cantilever Visitor Office Chair (model OC-CAN-MSH-001, unbranded) is a purpose-built fixed-structure office visitor chair with a cantilever sled base, designed for consistent, low-maintenance guest and short-term seating across professional settings. Visually, it presents a streamlined, professional silhouette defined by its open mesh backrest, slim continuous chrome sled frame, and integrated fixed armrests, with a cohesive monochrome finish that blends seamlessly with both modern and traditional office decor. The chair’s layout prioritizes open, approachable seating without protruding adjustment levers or bulky mechanical components, creating a clean, uncluttered profile that works well in high-visibility public-facing spaces. Constructed for durable commercial use, the chair features a tensioned polyester breathable mesh backrest supported by a reinforced polypropylene internal frame, paired with an upholstered seat built around a 14mm bent plywood internal support board and 60mm thick high-resilience molded polyurethane foam pad covered in breathable black woven fabric. The structural frame is formed from chrome-plated cold-rolled steel tubing with a 1.5mm wall thickness, anchored by a 2mm thick stamped steel under-seat bracket. Fixed armrests are capped with soft polyurethane pads, and the base is fitted with injection-molded nylon non-slip glides to protect floor surfaces. Functional features are tailored to visitor use: the zero-swivel fixed cantilever design eliminates moving adjustment parts, as the chair has no height, tilt, or armrest adjustment mechanisms. The backrest incorporates an ergonomic contoured lumbar support zone, with flexible mesh that delivers a 10-degree responsive recline under user weight, while the contoured waterfall front seat edge reduces pressure on the backs of legs during extended sitting. The non-caster glide base allows smooth repositioning on hard floors, and the chair uses a non-stacking fixed frame design. This chair is suited for a range of commercial and flexible residential work spaces, including conference and meeting rooms, lobby and guest waiting zones, staff training and presentation rooms, and side guest seating adjacent to individual workstations. It is compatible with hardwood, tile, and carpeted flooring, and engineered for use by adult office workers and visitors. For procurement, note that each unit ships across two cartons, with an assembly time of 40 minutes per set. The non-stacking design requires dedicated storage space when not in use, and fixed dimensions should be verified to align with space planning for table clearance and seating layout targets.

Mesh Back Cantilever Visitor Office Chair with Padded Seat Specifications
