PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	595 × 540 × 980 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight per unit	10 kg
Static load capacity	120 kg
Recommended maximum user weight	110 kg
Seat foam density	45 kg/m³
Seat foam thickness	50 mm
Abrasion resistance of seat fabric	30000 cycles
Frame static load rating	150 kg
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support	Flexible breathable polyester mesh stretched over grey PP frame
Seat cushion core	High-resilience molded polyurethane foam
Seat upholstery	Woven polyester fabric over foam cushion
Armrests	Fixed loop-style grey polypropylene armrests attached to seat frame
Support frame	22mm diameter powder-coated round steel tube cantilever sled base
Floor glides	Black non-slip plastic/nylon glides at all frame contact points
Seat pan inner structure	12mm thick molded plywood under seat cushion
Back frame inner support	Glass-fiber reinforced PP back support frame
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating posture support	Contoured lumbar support built into mesh backrest
Arm support	Fixed height closed-loop armrests with 180mm vertical clearance above seat
Movement type	Non-swivel, non-adjustable fixed cantilever seating
Floor protection	Replaceable non-marking nylon glides prevent floor scratching
Seating function	No tilt, height adjustment or recline function
Stacking compatibility	Non-stackable fixed frame design
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference room seating	Ideal for formal meeting rooms with fixed 450mm seat height matching standard 750mm conference tables
Visitor/reception area use	Suitable for reception waiting areas with stable non-rolling base preventing unintended movement
Open office guest seating	Designed for placement on the visitor side of office desks for short meetings and consultations
Training room application	Appropriate for training facilities due to lightweight durable frame and breathable mesh back
Recommended matching furniture	Pairs with 760 mm high office desks, conference tables, and reception counters
Flooring compatibility	Suitable for hard tile, wood, and low-pile carpeted floors with non-marking base glides
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Seating strength and stability	EN 16139:2013
Upholstery flammability	EN 1021:2014
Surface finish safety	EN 12727:2000

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	ANSI/BIFMA X5.1 General-Purpose Office Chairs

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Stability and strength	GB/T 10357.3
Upholstery safety	GB 20400
Structural safety	GB/T 3324

Standardized tender description text

This product must meet the following technical requirements:
1. Stability and strength: GB/T 10357.3;
2. Upholstery safety: GB 20400;
3. Structural safety: GB/T 3324;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OC-CB-M046

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OC-CB-M046

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OC-CB-M046Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mesh Back Cantilever Visitor Office Chair, model OC-CB-M046 from an unbranded line, is a purpose-built conference and visitor seating solution sized at 595 x 540 x 980 mm with a clean, streamlined silhouette suited to professional settings. Its visual profile balances structured support and lightness: the open mesh backrest is paired with fixed loop-style grey polypropylene armrests and a continuous cantilever sled frame, creating a consistent, understated look that coordinates with standard office furnishings without visual clutter. The 540 mm clear width between armrests provides generous personal space for users, while the fixed 450 mm seat height aligns seamlessly with common work surface heights.
Constructed for long-term regular use, the chair features a flexible breathable polyester mesh backrest stretched over a glass-fiber reinforced polypropylene inner frame, with a contoured 240 mm tall built-in lumbar support zone. The seat uses a 50 mm thick high-resilience molded polyurethane foam core at 45 kg/m³ density, wrapped in woven polyester fabric with 30000-cycle abrasion resistance, set atop a 14 mm bent plywood internal support board for a total finished seat cushion thickness of 90 mm. The 22 mm diameter powder-coated round steel tube cantilever frame is fitted with replaceable non-marking black nylon glides at all floor contact points, and supports a static load of 150 kg with a recommended maximum user weight of 110 kg. Fixed polypropylene armrests offer 180 mm of vertical clearance above the seat, and the non-swivel, non-adjustable design holds a 125° seated angle.
This chair delivers consistent, low-maintenance support with no tilt, height adjustment, or recline mechanisms to service, and its stable non-rolling base prevents unintended movement across surfaces. The breathable mesh back supports air circulation for user comfort during extended sessions, while non-marking glides protect hard tile, wood, and low-pile carpeted floors from scratches. It is ideally suited for formal conference rooms paired with 750 mm high conference tables, reception waiting areas, the guest side of open office desks for short consultations, and training facilities, and coordinates seamlessly with 760 mm high office desks and reception counters.
For procurement planning, note the chair is non-stackable, ships as one set across two cartons with a packaged gross weight of 23 kg per set, and requires 40 minutes of assembly per unit. A 20-foot GP container holds 135 sets at 85% space utilization, and each unit has a net weight of 10 kg for easy placement and reconfiguration as needed.

Mesh Back Cantilever Visitor Office Chair Specifications
