PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	625 × 585 × 1015 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Product net weight	12 kg
Static seat load capacity	150 kg
Recommended user weight limit	120 kg
Seat foam density	45 kg/m³
Backrest mesh abrasion resistance	50000 cycles
Frame static load durability	120000 cycles
Applicable user count	1 person
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support structure	Black molded PP plastic frame with Y-shaped lumbar contour
Backrest upholstery	Dark gray breathable woven polyester mesh
Seat cushion core	High-density polyurethane foam
Seat upholstery	Black abrasion-resistant woven fabric
Cantilever base frame	16mm diameter powder-coated black steel tubing
Fixed armrests	Injection-molded black polypropylene with integrated frame attachment
Floor contact glides	Black non-scratch nylon glides
Frame coating	Epoxy powder coat, matte black finish
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating support	Fixed-position cantilever design with gentle flex for static comfort
Lumbar support	Integrated contoured Y-shaped lumbar pad aligned to natural lower back curve
Arm support	Fixed closed-loop armrests positioned at 190mm above seat surface for relaxed arm rest
Back ventilation	Open woven mesh back allows continuous air flow to reduce heat buildup during long meetings
Mobility	Fixed non-swivel, non-rolling design for stable conference and guest seating
Floor protection	Integrated nylon glides prevent scuffing and scratching on hard flooring surfaces
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference room seating	Fixed cantilever design provides consistent, space-efficient seating around meeting tables
Guest reception seating	Neutral black professional appearance suits front office and waiting area use
Open office workstation seating	Stackable-adjacent design works for temporary workstations or training rooms
Training room seating	Stable sled base allows easy arrangement and repositioning between sessions
Hard floor installation suitability	Non-scratch glides prevent damage to tile, wood, and vinyl commercial flooring
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture safety requirement	EN 1335:2020
Office furniture mechanical stability test	EN 1728:2012
Upholstered furniture flammability	EN 1021:2014

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Lounge and guest seating standard	ANSI/BIFMA X2019
Office chair durability and strength	ANSI/BIFMA X2017

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

General technical requirement for office chairs	GB/T 3324
Formaldehyde emission limit for furniture	GB 18584
Office furniture mechanical strength test	GB/T 10357.3

Standardized tender description text

This product must meet the following technical requirements:
1. General technical requirement for office chairs: GB/T 3324;
2. Formaldehyde emission limit for furniture: GB 18584;
3. Office furniture mechanical strength test: GB/T 10357.3;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFCH-CANT-MESH-625

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFCH-CANT-MESH-625

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFCH-CANT-MESH-625Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mesh Back Cantilever Conference Office Chair (model OFCH-CANT-MESH-625, unbranded) presents a streamlined, professional silhouette tailored to commercial workspace settings, with a cohesive matte black and dark gray color palette that aligns with neutral office interiors. Its fixed cantilever sled base creates a clean, unobtrusive profile, while the open-weave mesh back sits vertically above a generously padded seat, paired with closed-loop fixed armrests that maintain consistent, uncluttered lines around conference tables. Overall dimensions measure 625 x 585 x 1015 mm, with 540 mm of clear width between armrests to accommodate a broad range of users.
Built for long-term commercial use, the chair’s frame is constructed from 16mm diameter powder-coated black steel tubing with a matte epoxy finish, mounted with non-scratch black nylon glides at floor contact points. The backrest uses a black molded PP plastic internal structure shaped into a Y-shaped lumbar contour, upholstered in dark gray breathable woven polyester mesh rated for 50,000 abrasion cycles. The seat features a 14mm bent plywood internal support board, topped with high-density 45 kg/m³ polyurethane foam that forms a 90mm thick cushion, upholstered in black abrasion-resistant woven fabric. Fixed injection-molded black polypropylene armrests attach directly to the frame for lasting structural integrity, with the steel frame tested to 120,000 cycles of static load durability.
Functional design prioritizes comfort for extended seated use: the fixed cantilever frame offers gentle flex for static seating comfort, while the integrated 240mm tall contoured Y-shaped lumbar pad aligns with the natural lower back curve. The 125° backrest angle includes three suggested lock positions, and the open mesh back enables continuous air flow to reduce heat buildup during long meetings. Armrests sit 190mm above the seat surface for relaxed arm support, and the non-swivel, non-rolling design delivers stable placement, with nylon glides preventing scuffs to tile, wood, and vinyl hard flooring. The chair holds a 150 kg static seat load capacity, with a 120 kg recommended user weight limit for single-person use.
This model is suited for conference room seating, where its space-efficient profile supports consistent arrangement around meeting tables, including 2.4m executive desks. It also works for front office guest reception, temporary open office workstations, and training rooms, as its stable sled base allows quick repositioning between sessions, and its stackable-adjacent form supports compact storage when needed. For procurement, note that each unit ships in two cartons with a packaged gross weight of 23 kg per set, requiring 40 minutes of assembly per chair. A 20GP container can hold 135 sets at 85% space utilization, making the model scalable for large-space furnishing projects. There are no brand-specific aftermarket service inclusions for this unbranded SKU.

Mesh Back Cantilever Conference Office Chair with Lumbar Support Specifications
