PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	610 × 580 × 960 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	120 kg
Net product weight	12 kg
Seat foam density	45 kg/m³
Seat foam rebound rate	40%
Static load on cantilever frame	500 kg
Standard warranty period	3 years
Available color options	1
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support panel	Breathable woven polyester mesh
Backrest frame	Reinforced black polypropylene
Seat cushion core	High-resilience polyurethane foam
Seat upholstery	Wear-resistant black fabric
Armrests	Integrated loop-style black polypropylene
Cantilever base frame	1.5mm wall thickness powder-coated black steel
Foot glides	Non-marking injection-molded nylon
Mesh fabric abrasion resistance	50000 cycles
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Frame movement	Fixed non-swivel cantilever sled base
Back support	Built-in fixed lumbar support band
Arm support	Fixed closed-loop armrests
Floor protection	Built-in non-slip nylon glides
Seat comfort	Contoured waterfall seat edge
Back breathability	Taut tensioned mesh back
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Shipping carton dimensions	650 x 620 x 570 mm
Gross shipping weight	14 kg
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference room seating	Designed for fixed meeting room placement
Visitor reception seating	Suitable for reception and guest waiting areas
Training room seating	Appropriate for staff training and classroom spaces
Open office workstation seating	Usable for individual desk workstations
Commercial public space seating	Applicable for government and public service halls
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture seating safety	EN 1335:2018
Office furniture seating stability	EN 1022:2018
Office seating surface flammability	EN 1021:2014

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	ANSI/BIFMA X5.1 General-Purpose Office Chairs

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office chair strength and stability	GB/T 10357.2
Office chair durability	GB/T 10357.3
Furniture harmful substance limits	GB 18584

Standardized tender description text

This product must meet the following technical requirements:
1. Office chair strength and stability: GB/T 10357.2;
2. Office chair durability: GB/T 10357.3;
3. Furniture harmful substance limits: GB 18584;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OF-CHR-CANT-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OF-CHR-CANT-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OF-CHR-CANT-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mesh Back Cantilever Frame Conference Office Chair is a streamlined, purpose-built seating solution with a clean, unified silhouette suited to structured workspace layouts. Its fixed cantilever sled base creates an open, uncluttered visual profile, with integrated loop armrests that form smooth, continuous lines from the backrest frame down toward the floor, eliminating disjointed hardware components for a polished, professional aesthetic. The taut mesh backrest is framed in matte black reinforced polypropylene, paired with a generously padded black fabric seat that balances soft, approachable texture with the durable, uniform finish of the powder-coated black steel frame. Construction centers on hard-wearing, performance-focused materials selected for high-traffic use. The backrest uses breathable woven polyester mesh stretched taut across its support frame, anchored by a built-in fixed lumbar support panel. The seat core is formed from high-resilience polyurethane foam, upholstered in wear-resistant black fabric, and finished with a contoured waterfall edge to reduce pressure on the backs of the legs during extended seated periods. The cantilever base is constructed from powder-coated black steel, fitted with non-marking, non-slip injection-molded nylon foot glides to protect floor surfaces from scuffs or slippage. The fixed closed-loop armrests are molded from durable black polypropylene, matched to the backrest frame for a cohesive finish. The chair supports a recommended user weight of 120 kg, with a static load capacity on the cantilever frame of 500 kg. The backrest is set to a 125-degree recline angle with three suggested lock positions to support a range of seated postures, while the open mesh construction maintains consistent airflow to prevent heat buildup during long meetings or work sessions. This chair is versatile across both commercial and residential-adjacent workspace settings, with primary application in fixed conference room layouts paired with the recommended executive desk size. It works equally well for visitor reception and guest waiting areas, staff training and classroom-style spaces, individual open office workstations, and high-foot-traffic public service areas including government and public service halls. The cohesive black finish and streamlined profile blend seamlessly with modern, transitional, and traditional office design schemes. Procurement teams should note the model carries a 3-year standard warranty, with one available color option for consistent bulk deployment. Each unit ships across two cartons, with a standard assembly time of 40 minutes per set for on-site setup. The non-marking glides reduce maintenance requirements for delicate flooring, and the durable mesh and fabric surfaces are built to withstand the frequent use common to shared public and commercial seating zones. The fixed non-swivel base supports orderly, permanent seating arrangements in spaces where unplanned movement could create hazards or disrupt organized layouts.

Mesh Back Cantilever Frame Conference Office Chair Specifications
