PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	640 × 560 × 1015 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net product weight	12 kg
Recommended static load capacity	120 kg
Recommended user weight limit	110 kg
Seat cushion foam density	45 kg/m³
Mesh back abrasion resistance	50000 cycles
Frame static load test rating	1500 N
Standard warranty period	3 years
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest upholstery	Breathable woven polyester mesh
Seat upholstery	Woven commercial fabric over foam pad
Seat core padding	High-density polyurethane foam
Armrests	Integrated molded polypropylene support with flat resting pad
Structural frame	1.8mm thick chrome-plated steel tubing
Back support frame	Molded polypropylene inner frame for mesh tension
Seat base plate	2mm thick powder-coated steel connecting plate
Frame feet	Anti-scratch plastic end caps on base contact points
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Tilt function	4-degree backrest tilt with locking mechanism
Movement capability	Fixed non-swivel, non-rolling cantilever design
Armrest support	Fixed-height integrated armrests for forearm support
Lumbar support	Contoured mesh back with built-in molded lumbar zone
Floor protection	Sled base glides prevent floor scuffing
Assembly requirement	Knock-down construction requiring minimal on-site assembly
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference room seating	Fixed base for stable seating around meeting tables without rolling interference
Visitor reception areas	Professional mid-back design suitable for guest waiting spaces
Open office workstation seating	Cantilever design suitable for compact desk-side task seating
Training room seating	Stackable-adjacent fixed frame ideal for multi-purpose training spaces
Commercial office environments	Durable commercial-grade construction for high-traffic daily use
Hard flooring installation	Integrated glides suitable for tile, wood and laminate floor surfaces
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office chair stability recommendation	EN 1335:2009
Upholstery fabric durability recommendation	EN 14465:2003

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Visitor chair strength recommendation	ANSI/BIFMA X2017

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Upholstery formaldehyde limit recommendation	GB 18584

Standardized tender description text

This product must meet the following technical requirements:
1. Upholstery formaldehyde limit recommendation: GB 18584;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFCH-CB-056

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFCH-CB-056

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFCH-CB-056Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mesh Back Cantilever Visitor Conference Office Chair, model OFCH-CB-056, presents a streamlined mid-back silhouette defined by its continuous chrome-plated steel cantilever sled base, delivering a clean, uncluttered professional aesthetic suited to formal and flexible workspaces alike. The contoured backrest is crafted from breathable woven polyester mesh stretched over a molded polypropylene inner frame, paired with a neatly upholstered woven commercial fabric seat cushion and fixed integrated molded polypropylene armrests with flat, smooth resting pads, creating a balanced, structured visual profile that aligns with modern commercial interior design standards. Constructed for consistent long-term use, the chair features a 1.8mm thick chrome-plated steel tubing structural frame, connected to the seat via a 2mm thick powder-coated steel connecting plate, with a 14mm bent plywood internal seat support board beneath the high-density 45 kg/m³ polyurethane foam seat pad measuring 90mm thick. The mesh backrest includes 70mm of targeted padding across its surface, with a built-in 240mm tall molded lumbar zone, and delivers 50000 cycles of abrasion resistance for frequent use. Anti-scratch plastic end caps cap the frame feet, while the frame holds a 1500N static load test rating, supporting a recommended user weight limit of 110kg with a 120kg recommended static load capacity. Functional design elements prioritize stable, comfortable use: the fixed non-swivel, non-rolling cantilever structure eliminates unwanted movement around tables, while integrated sled base glides prevent scuffing on tile, wood, and laminate hard flooring. The backrest offers a 4-degree tilt range, with three lock positions supporting a maximum 125° recline angle, and fixed-height armrests provide steady forearm support across the 540mm clear width between rests. The knock-down design requires minimal on-site assembly, with a 40-minute per set assembly time, delivered across two cartons per set. This chair is well-suited for conference room seating around meeting tables, visitor reception waiting areas, compact open office workstation task seating, and multi-purpose training rooms, where its adjacent stackable-compatible fixed frame supports flexible space configuration, and its commercial-grade durability holds up to high-traffic daily use. For procurement planning, note the 3-year standard warranty, 12kg net product weight, 23kg packaged gross weight, and 135-set loading capacity for a 20GP container at 85% space utilization to align bulk orders with storage, shipping, and long-term facility maintenance requirements.

Mesh Back Cantilever Visitor Conference Office Chair Specifications
