PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	610 × 590 × 1000 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Product net weight	20 kg
Recommended static load capacity	113 kg
Seat foam density	45 kg/m³
Seat foam rebound rate	45%
Backrest mesh abrasion resistance	50000 cycles
Frame static load rating	150 kg
Seam stitch pitch	8 stitches per 30mm
Standard warranty period	3 years
Available color options	6
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest upholstery	Breathable polyester sandwich mesh
Seat core padding	High-density molded polyurethane foam
Seat surface upholstery	Wear-resistant polyester fabric
Support frame	25# powder-coated tubular steel
Armrest pads and supports	Injection-molded polypropylene, matte gray finish
Frame under-seat bracing	Double steel cross-brace
Floor contact glides	Non-slip injection-molded plastic feet
Internal seat support board	12mm thick molded plywood
Backrest support frame	Reinforced polypropylene inner frame
Surface finish on steel frame	Electrostatic powder coating
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating function	Fixed static seating for short to medium visitor/conference use
Mobility restriction	No swivel, casters, or gas lift height adjustment
Back support feature	Contoured lumbar curve integrated into mesh back
Backrest recline function	Fixed 100-degree backrest angle
Arm support function	Fixed T-armrests positioned to support forearms at typing rest height
Floor protection function	Replaceable non-slip glides on base contact points
Frame flex function	Controlled slight flex in cantilever frame for seated comfort
Stacking capability	Non-stacking fixed frame design
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference room application	Fixed meeting room seating around boardroom and conference tables
Reception area application	Guest seating in office lobbies and visitor waiting areas
Training room application	Attendee seating for corporate training and seminar spaces
Open office guest application	Side seating at individual workstations for visiting colleagues
Government/education facility application	Public seating in public service offices and campus meeting spaces
Home office guest application	Occasional extra seating for home office workspaces
Recommended table height pairing	Compatible with 760 mm height standard office desks and conference tables
Recommended Matching Desk Size	2.4 m executive desk

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1335-2:2018	Office work chair safety requirements, applicable to structural safety performance validation
EN 1335-3:2018	Office work chair test methods, applicable to strength and stability verification
EN 1022:2019	Furniture seating stability test standard, applicable to cantilever chair anti-tilt verification

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1-2017	General purpose office chairs standard, applicable to load and durability testing
ANSI/BIFMA e3-2019	Furniture sustainability standard, applicable to material environmental attribute assessment

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for metal furniture, applicable to steel frame chair structural integrity
GB/T 35607-2017	Green product assessment standard for furniture, applicable to material low-VOC acceptance
GB/T 10357.3-2013	Furniture mechanical test for chair strength and durability, applicable to static/fatigue load testing

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to steel frame chair structural integrity;
2. GB/T 35607-2017: Green product assessment standard for furniture, applicable to material low-VOC acceptance;
3. GB/T 10357.3-2013: Furniture mechanical test for chair strength and durability, applicable to static/fatigue load testing;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OF-CV-MESH-1006159

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OF-CV-MESH-1006159

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OF-CV-MESH-1006159Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Cantilever Sled Base Mesh Back Conference Visitor Chair, model OF-CV-MESH-1006159, is an unbranded fixed-position seating solution designed for consistent, professional use across commercial and residential work-oriented spaces. Visually, it presents a clean, streamlined profile defined by its open cantilever sled frame, matte gray T-shaped armrests, and structured mesh backrest, with a neutral, understated finish that complements both modern and traditional interior schemes without visual clutter. Its form balances open, airy visual weight from the mesh back with the solid, grounded presence of the sled base, creating a polished look suitable for formal and informal guest settings alike. Construction prioritizes long-term durability and seated comfort, starting with a 25# powder-coated tubular steel frame reinforced by double steel cross-bracing under the seat. The backrest uses breathable polyester sandwich mesh stretched over a reinforced polypropylene inner frame, shaped with an integrated contoured lumbar curve. The seat is built on a molded plywood internal support board, topped with high-density molded polyurethane foam upholstered in wear-resistant polyester fabric. Armrests are constructed from injection-molded polypropylene with a matte gray finish, and base contact points are fitted with replaceable non-slip injection-molded plastic glides to protect floor surfaces. The cantilever frame provides controlled slight flex to add gentle comfort during use, while the backrest holds a fixed upright angle suited to short to medium duration seating. This chair offers no swivel, casters, or height adjustment, creating a stable, static seating position ideal for guest use. Fixed T-armrests are positioned to support forearms at a natural typing rest height, and the open mesh back promotes air circulation to prevent heat buildup during extended meetings or waits. This model fits a wide range of settings: it serves as fixed seating around boardroom and conference tables, guest seating in office lobbies and waiting areas, attendee seating for corporate training and seminar spaces, side seating for visiting colleagues at individual open-office workstations, public seating in government service offices and campus meeting spaces, and occasional extra seating for home office workspaces. For procurement planning, note that each chair ships in two cartons, with an assembly time of 40 minutes per unit. Load ratings align with standard commercial visitor seating requirements, and replaceable glides reduce long-term maintenance needs. Shipping and storage logistics allow for efficient bulk ordering for large fit-out projects, with clear space between armrests and structured padding dimensions suited to a broad range of users.

Cantilever Sled Base Mesh Back Conference Visitor Chair Specifications
