Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 585 x 515 x 1030 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 12 kg | |
|---|---|---|
| Static seat load capacity | 136 kg | |
| Backrest static load rating | 91 kg | |
| Recommended user weight limit | 113 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam thickness | 50 mm | |
| Back mesh tensile strength | 180 N/5cm | |
| Durability cycle rating for frame | 100000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Backrest mesh | Breathable polyester woven mesh | |
|---|---|---|
| Back support frame | Injection molded light grey polypropylene | |
| Integrated lumbar insert | Molded PP lumbar support insert | |
| Seat cushion core | Molded high resilience polyurethane foam | |
| Seat upholstery | Wear-resistant fabric upholstery | |
| Armrests | Integrated fixed PP armrests with smooth finish | |
| Sled base frame | 16mm diameter powder-coated steel tube | |
| Floor glides | Non-marking PP floor glides | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cantilever flex movement | Base provides gentle dynamic flex without tilting mechanism | |
|---|---|---|
| Fixed integrated armrests | Armrests provide stable forearm support without height or width adjustment | |
| Built-in lumbar support | Contoured lumbar insert maintains natural lower back curve | |
| Breathable back ventilation | Mesh construction allows continuous air flow through backrest | |
| No swivel mechanism | Fixed orientation non-swivel seating | |
| Non-adjustable fixed seat angle | Seat fixed at 3 degree backward tilt for upright working posture | |
| Floor protection glides | Smooth glides allow repositioning without scratching hard floors | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 620 x 550 x 1070 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Corporate conference rooms | Fixed-position seating ideal for boardrooms and meeting spaces, prevents disruptive swiveling | |
|---|---|---|
| Office visitor and waiting areas | Sleek light frame design suits reception and guest waiting zones for temporary seating | |
| Open plan workstation guest seating | Suitable for placement beside desks for short-term collaborative work and visitor use | |
| Training room seating | Stackable? No, fixed sled base durable configuration suitable for daily training room use | |
| Government and institutional meeting spaces | Commercial-grade construction meets high-traffic public sector seating requirements | |
| Co-working space shared areas | Neutral color and durable design fits flexible shared working environments | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Applicable European standard for office chair safety requirements | |
|---|---|---|
| EN 1335-3:2018 | Applicable test methods for office chair strength and stability |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.1 General-Purpose Office Chairs |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable standard for office furniture chair dimensional accuracy | |
|---|---|---|
| GB/T 10357.2-2013 | Applicable mechanical stability test standard for straight chairs | |
| GB/T 10357.3-2013 | Applicable strength and durability test for office chair seats and backs |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable standard for office furniture chair dimensional accuracy; 2. GB/T 10357.2-2013: Applicable mechanical stability test standard for straight chairs; 3. GB/T 10357.3-2013: Applicable strength and durability test for office chair seats and backs; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
