Name: Black Mesh Back Conference Office Chair with Cantilever Sled Base
Brand: YUXIANG
SKU: P62D0W

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	660 × 620 × 1050 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total product weight	12 kg
Static seat load capacity	120 kg
Recommended user weight limit	110 kg
Frame cyclic durability rating	100000 cycles
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles
Five-star Base Static Load Reference	Acceptance target ≥120 kg; chair reference load 150 kg
Caster Rolling Durability Reference	Acceptance target 30000 cycles
Gas-lift Cycling Reference	Acceptance target 100000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support surface	Breathable woven polyester mesh stretched over internal plastic support frame
Lumbar support zone	Molded contoured hard plastic panel with mesh overlay at mid-back
Seat core cushion	Molded high-density polyurethane foam, 80mm thick
Seat upholstery	Black abrasion-resistant woven fabric covering entire seat cushion
Armrest tops	Hard molded black polypropylene flat arm pads fixed to frame
Cantilever leg frame	1.8mm thick black powder-coated steel tube, continuous sled base
Frame foot glides	Injection-molded black nylon floor glides at all base contact points
Frame connection hardware	Zinc-plated steel bolts securing seat and back to leg frame
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat position	Fixed non-adjustable height and depth, optimized for standard 760 mm height conference desks
Backrest action	Fixed ergonomic lumbar contour with flexible mesh give, no tilt or recline mechanism
Armrest position	Fixed height and position, provides arm support for typing and seated meetings
Base mobility	Floor-placed sled base with glides, no casters, resists sliding on hard floors
Back ventilation	Open mesh upper back allows continuous air flow to reduce heat build-up during long meetings
Floor protection	Soft nylon glides prevent scuffing on hardwood, tile and vinyl office flooring
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Conference and meeting rooms	Fixed stable design for multi-hour meeting use at standard height conference tables
Visitor and reception areas	Professional black aesthetic and non-rolling base for formal guest seating in reception zones
Training room seating	Stackable-compatible cantilever frame allows compact storage between training sessions
Open office workstations	Breathable mesh back for extended seated work at open plan desk positions
Healthcare and public waiting areas	Easy-to-clean fabric and mesh surfaces for high-traffic public waiting zones
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture seating stability	EN 1335:2009
Office chair strength and durability	EN 16139:2013

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Fixed seating performance standard	ANSI/BIFMA X2017
Low-back task chair load requirements	ANSI/BIFMA X5.1 Test 5, 11, 13

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office chair structural safety	GB/T 3326
Formaldehyde emission limits	GB 18584

Standardized tender description text

This product must meet the following technical requirements:
1. Office chair structural safety: GB/T 3326;
2. Formaldehyde emission limits: GB 18584;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFC-MSH-SLED-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFC-MSH-SLED-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFC-MSH-SLED-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The YUXIANG OFC-MSH-SLED-01 Black Mesh Back Conference Office Chair presents a streamlined, professional silhouette tailored to structured commercial and residential workspaces, with a unified monochromatic black finish that complements neutral and formal interior palettes. Its cantilever sled base forms a continuous, open lower profile that eliminates visual clutter, while fixed armrests sit at a consistent, evenly spaced width to frame the generously padded seat. The chair follows a clean linear layout, with an upright ergonomic back that aligns naturally with standard table heights for consistent sightlines across meeting arrangements. Constructed for regular high-traffic use, the chair’s back combines a breathable woven polyester mesh stretched over an internal plastic support frame, with a molded contoured hard plastic lumbar panel overlaid with mesh at the mid-back to deliver targeted support. The seat core uses molded high-density polyurethane foam, wrapped in abrasion-resistant black woven fabric, supported by a bent plywood internal board. Armrests feature hard molded black polypropylene flat pads fixed directly to the frame, while the cantilever leg structure is built from thick black powder-coated steel tube fitted with injection-molded black nylon glides at all floor contact points; zinc-plated steel bolts secure all seat and back connections to the leg frame. Functional design prioritizes stability and low-maintenance usability: the chair has a fixed seat position with non-adjustable height and depth, optimized for standard conference desk heights, and a fixed back with no tilt or recline mechanism, paired with the flexible give of the mesh upper back to allow continuous airflow and reduce heat buildup during long periods of seated use. The fixed armrests offer stable support for typing and meeting interactions, while the caster-free sled base resists unintended sliding on hard floors, and soft nylon glides prevent scuffing on hardwood, tile, and vinyl surfaces. The cantilever frame supports stackable storage to save space when not in use, and the fabric and mesh surfaces are easy to wipe clean for high-turnover environments. This chair is well suited for conference and meeting rooms, formal visitor and reception areas, training spaces, open office workstations, and healthcare or public waiting zones, pairing easily with full-size executive desks and standard conference tables. Procurement teams should note that each unit ships across two cartons, requires on-site assembly, and is designed for users within the published recommended weight limit to maximize service life; load and durability ratings align with regular daily commercial use, and packaging dimensions support efficient bulk shipping for large-space outfitting projects.

Black Mesh Back Conference Office Chair with Cantilever Sled Base Specifications
