Name: Mid-Back Mesh Swivel Office Task Chair with Height Adjustment
Brand: YUXIANG
SKU: ZXNBXL

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	620 × 640 × 1060 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight	13 kg
Maximum user weight capacity	120 kg
Seat static load rating	800 kg
Backrest static load rating	45 kg
Caster rolling durability cycles	40000
Gas lift cycle rating	60000
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles
Five-star Base Static Load Reference	Acceptance target ≥120 kg; chair reference load 150 kg

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support panel	Grey breathable woven polyester mesh tensioned over PP frame
Seat cushion core	45 kg/m³ density high-resilience polyurethane foam, 80mm thickness
Seat upholstery	Dark blue abrasion-resistant polyester fabric, 30000 double rub wear rating
Armrests	Fixed curved grey polypropylene armrests with integrated frame connection
Gas lift cylinder	Chrome-plated Class 2 steel gas lift, 50mm diameter, 160mm adjustment stroke
Five-star base	Polished chrome-plated 1.5mm thick steel, 320mm radius from center to caster
Casters	50mm diameter black nylon twin-wheel casters, universal hard-floor compatible
Tilt mechanism	2.5mm thick steel plate center-tilt chassis with tension adjustment
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Five-star Base Material Thickness	Metal base wall 3.5 mm; diameter 700 mm
Caster Engineering Specification	5 PU-tread swivel casters, 60 mm diameter

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat height adjustment	Pneumatic height adjustment via right-side lever, 160mm total vertical travel
Seat swivel	360-degree full rotation around central gas lift axis for multi-directional access
Tilt recline	Center-tilt mechanism allows 12-degree backward backrest recline with tension control
Tilt lock	Lockable tilt position to hold upright working posture via under-seat lever
Mobility function	Smooth rolling on five twin-wheel casters across hard floors and low-pile carpet
Back support	Contoured mesh back provides lumbar support with breathable airflow to reduce heat buildup
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open office workstations	Compact footprint fits standard 1200mm workstation desks for daily employee use
Home office spaces	Space-efficient design suitable for home study or remote work setups
Conference meeting rooms	Stackable-adjacent design suitable for temporary meeting seating around tables
Reception visitor areas	Neutral color scheme and professional appearance fit front-of-house visitor seating
Training room environments	Durable construction and rolling mobility support frequent reconfiguration
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1-2017	General purpose office chairs – applicable for safety, strength and durability testing

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · TASK-MID-MESH-62106

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · TASK-MID-MESH-62106

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · TASK-MID-MESH-62106Open Export Tool

Quick Actions

Post an RFQ

Product Description

YUXIANG’s TASK-MID-MESH-62106 is a mid-back mesh swivel office task chair built for consistent everyday use across professional and residential work settings. Its visual profile pairs a grey woven mesh backrest tensioned over a matching polypropylene frame with dark blue abrasion-resistant polyester seat upholstery, fixed curved grey polypropylene armrests, and a polished chrome-plated five-star base, creating a streamlined, professional aesthetic that coordinates with standard office interiors. The compact overall footprint of 620 x 640 x 1060 mm allows adjacent placement without excess gap between seats, with a 540 mm clear width between armrests to accommodate a range of user sizes. Construction centers on durable, performance-focused materials: the backrest uses breathable woven polyester mesh to enable constant airflow, while the seat features a 90 mm thick cushion with a 45 kg/m³ high-resilience polyurethane foam core supported by a 14 mm bent plywood internal board, upholstered in fabric rated for 30000 double rubs of wear. The 240 mm tall lumbar support zone follows the natural curve of the lower spine, with 70 mm of padding in the backrest for balanced support. Core structural components include a 1.5 mm thick polished chrome steel five-star base, a 50 mm diameter chrome-plated Class 2 steel gas lift, 2.5 mm thick steel plate center-tilt chassis, and 50 mm diameter black nylon twin-wheel casters compatible with hard floors and low-pile carpet. The chair supports a maximum user weight of 120 kg, with a seat static load rating of 800 kg, 40000 caster rolling durability cycles, and 60000 gas lift cycle rating for long-term reliability. Key practical functions include pneumatic seat height adjustment with 160 mm of vertical travel controlled via a right-side lever, 360-degree swivel for multi-directional access, 12-degree backward recline with adjustable tension, a lockable tilt function with three suggested lock positions including an upright work posture setting, and smooth rolling mobility for easy repositioning. The chair suits open office workstations paired with standard 1200 mm desks, home office and remote work setups, conference rooms, reception visitor areas, and training rooms where frequent layout changes are required, and also pairs with 2.4 m executive desks. For procurement, note that each unit ships in two cartons with a packaged gross weight of 23 kg per set, requires 40 minutes of assembly time, and allows 135 sets to be loaded in a 20GP container at 85% space utilization. No additional tools or specialized installation support are required for standard setup.
