Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Seat Cushion Thickness | 90 mm | |
|---|---|---|
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Set weight | 68 kg | |
|---|---|---|
| Tabletop distributed load | 40 kg | |
| Single-chair static load | 130 kg | |
| Seating capacity | 4 persons | |
| Swivel rotation | 360 degrees | |
| Recommended user weight | 110 kg per person | |
| Floor contact load | 4.2 kg per chair base cm2 at rated occupancy | |
| Service durability target | 30,000 swivel cycles | |
| Table capacity area | 0.50 m2 per person | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair outer shell | Glossy white molded polymer or fiberglass-reinforced composite shell with continuous bucket form | |
|---|---|---|
| Inner seating surface | Red or green padded upholstery bonded into the seat and back recess | |
| Upholstery facing | Padded faux leather or vinyl facing, 1.0 mm thick, with visible perimeter stitching | |
| Seat cushioning | 60 mm molded polyurethane foam pad at 35 kg/m3 density | |
| Chair pedestal | Glossy white coated cast aluminum or steel tulip stem and flared circular base | |
| Table construction | Glossy white pedestal base with a smooth round hard tabletop and 90 mm center stem |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Swivel seating | Each chair rotates 360 degrees on a concealed center bearing and returns without casters | |
|---|---|---|
| Enclosed bucket support | Integrated seat, back, and side bolsters cradle one user without separate arm components | |
| Four-person circular conversation layout | Chairs face the center table and leave radial access around the pedestal base | |
| Fixed-height bistro service | The 740 mm table and 450 mm seat provide a fixed dining-height relationship |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total packaging volume | 1.74 m3 | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Breakout and cafe seating | Use in staff pantries, reception lounges, cafe corners, or visitor waiting areas where four people can converse around a compact table. | |
|---|---|---|
| Color-focused hospitality setting | Alternating red and green chairs provide visual zoning in modern bars, fast-casual dining, showrooms, and creative office spaces. |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
