PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall product dimensions	680 x 660 x 900 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Suggested user weight capacity	120 kg
Net weight per chair	13 kg
Static base load verification	180 kg
Seat foam density	35 kg/m3
Back foam density	30 kg/m3
Foam rebound performance	40%
Upholstery abrasion acceptance	30,000 Martindale cycles
Swivel operating cycles	50,000 cycles
Color options shown	3 colors
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Outer upholstery	Woven fabric cover over a one-piece curved shell; material grade requires supplier BOM confirmation
Seat cushion	Polyurethane foam pad over a molded structural inner shell, 90 mm total padded edge thickness
Back and side wings	Continuous upholstered shell with integrated side support and no exposed separate arm frame
Center column	Chrome-plated steel gas-lift tube, 50 mm diameter, with visible black height-setting collar
Four-star base	Polished aluminum-look four-prong pedestal with flat radiating feet and black end caps
Floor contacts	Black polymer protective end pads fitted to each base foot

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Swivel function	360-degree rotation around the central bearing column for conversational seating without moving the base
Height adjustment	Gas-lift height adjustment with a 120 mm maximum stroke and lever release under the seat shell
Integrated body support	The continuous seat, back, and side-wing shell provides arm and upper-body support without separate armrests
Floor protection	Four black non-marking end pads distribute load on hard floors and reduce scraping during repositioning

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Gross weight per carton	16 kg
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Lounge and reception use	Suitable for waiting areas, break rooms, showrooms, and hotel lobbies where compact swivel seating is grouped around low tables
Collaborative break-out configuration	Use one round table with three to four chairs for short meetings, refreshments, or casual guest conversations

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.4

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LCS-SHELL-4STAR-FABRIC

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LCS-SHELL-4STAR-FABRIC

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LCS-SHELL-4STAR-FABRICOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Upholstered Swivel Lounge Chair with Polished Four-Star Base presents a compact, contemporary lounge form defined by a continuous curved shell and a clean pedestal silhouette. Its seat, back, and side wings flow into one another, creating integrated arm and upper-body support without a separate exposed arm frame. The polished four-prong base radiates from the central column, giving the chair a structured yet light visual profile suited to grouped reception and lounge layouts. Overall dimensions are 680 x 660 x 900 mm, with 540 mm of clear width between the armrest areas. Construction combines a fabric-upholstered molded shell with polyurethane foam padding. The seat cushion has a 90 mm padded edge thickness and 35 kg/m3 foam density, while the backrest uses 70 mm padding and 30 kg/m3 foam. A 240 mm lumbar support zone is integrated into the continuous back and side-wing form. The outer cover is a woven fabric over a one-piece curved shell; the exact material grade should be confirmed through the supplier bill of materials. The center support is a 50 mm diameter chrome-plated steel gas-lift tube with a visible black height-setting collar, paired with a polished aluminum-look four-star pedestal and black polymer protective end pads on each foot. Functionally, the chair rotates 360 degrees around the central bearing column, allowing users to turn between conversation points without moving the base. A lever under the seat shell controls gas-lift height adjustment, with a 120 mm maximum stroke. The non-marking end pads help distribute load on hard floors and reduce scraping when the chair is repositioned. The published suggested user weight capacity is 120 kg, static base load verification is 180 kg, and upholstery abrasion acceptance is 30,000 Martindale cycles. Foam rebound performance is listed at 40 percent. This unbranded model, LCS-SHELL-4STAR-FABRIC, is appropriate for waiting areas, break rooms, showrooms, hotel lobbies, and casual collaborative zones. It can be grouped around low tables, or arranged with one round table and three to four chairs for short meetings, refreshments, or informal guest conversations. The design also works in residential studies, bedrooms, or living spaces where a swivel lounge chair is desired. For procurement, buyers should note that each chair weighs 13 kg net and ships as one set across two cartons, with a packaged gross weight of 23 kg per set and reference carton volume of 0.26 m3. Assembly time is listed as 40 minutes per set. Material grade, fabric appearance, lead time, replacement parts, and finish consistency should be confirmed before volume ordering, especially for multi-chair installations where visual and comfort uniformity matter.
