Single Office Workstation with Left Storage Pedestal and Desktop Privacy Screen (model OD-WS-1400-PED-SCR) is listed under Open Workstation. Dimensions: 1400 × 700 × 1200 mm. Materials: 25 mm engineered-wood board with dark charcoal matte laminate and 2 mm matching edge banding. Load capacity: 80 kg. Product Features: modern,style,single,workstation,fixed-height,desk,left,pedestal,storage,desktop,privacy,screen. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | XIANGSHI | Model | OD-WS-1400-PED-SCR |
| Overall dimensions (W × D × H) | 1400 × 700 × 1200 mm | Finished Top Thickness | 50 mm |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | Leg / Support Section | 80 mm main section with 2 mm metal wall |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm | Product net weight | 58 kg |
| Distributed desktop static load | 80 kg | Pedestal top-section load | 15 kg |
| Lower cabinet static load | 25 kg | Open shelf static load | 20 kg |
| Privacy screen lateral load | 15 kg | Leveling adjustment per foot | 10 mm |
| Recommended user weight and equipment load | 120 kg | Suggested warranty period | 5 years |
| Top Static Load Reference | 150 kg uniformly distributed | Worktop substrate and finish | 25 mm engineered-wood board with dark charcoal matte laminate and 2 mm matching edge banding |
| Cabinet panels | 18 mm warm beige engineered-wood panels with dark laminate top and shelf surfaces | Structural legs | Four 32 mm tapered powder-coated steel tubes with champagne-gold metal sleeves |
| Rear screen support | 32 mm black powder-coated steel rail with two vertical posts and rounded end caps | Privacy divider | 25 mm upholstered MDF or particleboard core with beige woven fabric surface |
| Hardware and feet | Steel drawer lock, concealed hinges or drawer slides, and black nylon-tipped adjustable glides | Fixed-height writing and computer setup | 750 mm work surface supports laptop, monitor, keyboard, and writing tasks in a seated posture |
| Integrated left storage pedestal | Combines one lockable shallow drawer, one lower enclosed cabinet, and one adjacent open shelf for mixed office storage | Rear privacy and cable management zone | Upholstered divider on a steel rail creates a rear visual barrier and space for routing cables behind equipment |
| Floor leveling and freestanding installation | Six visible screw-type glides across legs and pedestal compensate for uneven floors without wall attachment | Flat-packed carton dimensions | 1470 x 760 x 180 mm for main pack, 720 x 580 x 320 mm for pedestal, 970 x 410 x 80 mm for screen |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
| Reference Packaging Volume | 1 m³/set | Private office or open workstation area | Designed for one user requiring a 750 mm task surface, drawer security, and under-desk reference storage |
| Executive or boutique-style office interior | Warm beige panels, charcoal top, black steel, and gold accents suit design-focused reception-adjacent workspaces | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 700 × 1200 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 58 kg | |
|---|---|---|
| Distributed desktop static load | 80 kg | |
| Pedestal top-section load | 15 kg | |
| Lower cabinet static load | 25 kg | |
| Open shelf static load | 20 kg | |
| Privacy screen lateral load | 15 kg | |
| Leveling adjustment per foot | 10 mm | |
| Recommended user weight and equipment load | 120 kg | |
| Suggested warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop substrate and finish | 25 mm engineered-wood board with dark charcoal matte laminate and 2 mm matching edge banding | |
|---|---|---|
| Cabinet panels | 18 mm warm beige engineered-wood panels with dark laminate top and shelf surfaces | |
| Structural legs | Four 32 mm tapered powder-coated steel tubes with champagne-gold metal sleeves | |
| Rear screen support | 32 mm black powder-coated steel rail with two vertical posts and rounded end caps | |
| Privacy divider | 25 mm upholstered MDF or particleboard core with beige woven fabric surface | |
| Hardware and feet | Steel drawer lock, concealed hinges or drawer slides, and black nylon-tipped adjustable glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed-height writing and computer setup | 750 mm work surface supports laptop, monitor, keyboard, and writing tasks in a seated posture | |
|---|---|---|
| Integrated left storage pedestal | Combines one lockable shallow drawer, one lower enclosed cabinet, and one adjacent open shelf for mixed office storage | |
| Rear privacy and cable management zone | Upholstered divider on a steel rail creates a rear visual barrier and space for routing cables behind equipment | |
| Floor leveling and freestanding installation | Six visible screw-type glides across legs and pedestal compensate for uneven floors without wall attachment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Flat-packed carton dimensions | 1470 x 760 x 180 mm for main pack, 720 x 580 x 320 mm for pedestal, 970 x 410 x 80 mm for screen | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private office or open workstation area | Designed for one user requiring a 750 mm task surface, drawer security, and under-desk reference storage | |
|---|---|---|
| Executive or boutique-style office interior | Warm beige panels, charcoal top, black steel, and gold accents suit design-focused reception-adjacent workspaces |
EU Market Access Requirements* EN Standards
| Office furniture strength and stability | EN 16139:2013+A1:2019 | |
|---|---|---|
| Office work surface dimensions | EN 527:2011 | |
| Formaldehyde panel emissions | EN 13986:2004+A1:2015 |
US and Canada office-furniture standards
| Desk and table durability | ANSI/BIFMA X2021 | |
|---|---|---|
| Formaldehyde from composite panels | ANSI/BIFMA e2019e |
Standards applicable to China-market projects
| Dimensional and structural furniture safety | GB/T 3324 | |
|---|---|---|
| Formaldehyde emission for wood-based panels | GB 18580 | |
| Office furniture mechanical safety | GB/T 38607 |
This product must meet the following technical requirements: 1. Dimensional and structural furniture safety: GB/T 3324; 2. Formaldehyde emission for wood-based panels: GB 18580; 3. Office furniture mechanical safety: GB/T 38607; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
