Integrated Side-Credenza Executive Workstation with Hutch and Privacy Screen (model EXEC-CRD-2400-INT) is listed under Open Workstation. Dimensions: 2400 × 1700 × 1250 mm. Materials: 25 mm engineered-wood board with matte charcoal melamine finish and sealed edge banding. Load capacity: 80 kg. Product Features: modern,executive,style,integrated,storage,upholstered,privacy,screen,metal,tapered,legs. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | XIANGSHI | Model | EXEC-CRD-2400-INT |
| Overall dimensions (W × D × H) | 2400 × 1700 × 1250 mm | Finished Top Thickness | 50 mm |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | Leg / Support Section | 80 mm main section with 2 mm metal wall |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm | Net weight | 128 kg |
| Desktop distributed static load | 80 kg | Credenza shelf distributed static load | 30 kg per shelf |
| Drawer load capacity | 15 kg per drawer | Single-user capacity | 1 person |
| Power outlet count | 6 sockets | Drawer count | 3 drawers |
| Open equipment bays | 3 bays | Top Static Load Reference | 150 kg uniformly distributed |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | Desktop and charcoal panels | 25 mm engineered-wood board with matte charcoal melamine finish and sealed edge banding |
| Beige cabinet carcass | 18 mm engineered-wood panels with warm beige matte coating | Support frame | Black powder-coated tapered steel legs with a 32 mm upper tube and brass effect foot ferrules |
| Privacy screen | Padded fabric or leather-look upholstery over a 35 mm board with rounded metal top rail | Drawer hardware | Side-mounted ball-bearing drawer slides with one integrated lock on the top drawer area |
| Power panel | White thermoplastic socket inserts set in a charcoal panel, supplied as a 6-outlet desktop power cluster | Integrated work and storage layout | The side credenza, hutch shelf and projecting desktop provide one seated work bay plus adjacent filing, display and computer-tower storage. |
| Power and cable management | The six-socket panel sits beside the equipment bays, supporting desktop devices and tower computers while cables route behind the central divider. | Privacy and sight-line control | The 350 mm-high upholstered divider screens the rear shelf and equipment without blocking seated sight lines across the desktop. |
| Drawer filing and lock control | Three vertically stacked drawers use side slides for file access, while the visible cylinder lock secures the top drawer or pedestal set. | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | Reference Packaging Volume | 1 m³/set |
| Private executive office | Suitable for managers and directors needing a writing desk, personal filing, display shelf and computer storage in one continuous wall-side unit. | Professional meeting or consultant room | Supports laptop work, document review and concealed equipment storage in a premium advisory or sales office. |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1700 × 1250 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 128 kg | |
|---|---|---|
| Desktop distributed static load | 80 kg | |
| Credenza shelf distributed static load | 30 kg per shelf | |
| Drawer load capacity | 15 kg per drawer | |
| Single-user capacity | 1 person | |
| Power outlet count | 6 sockets | |
| Drawer count | 3 drawers | |
| Open equipment bays | 3 bays | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop and charcoal panels | 25 mm engineered-wood board with matte charcoal melamine finish and sealed edge banding | |
|---|---|---|
| Beige cabinet carcass | 18 mm engineered-wood panels with warm beige matte coating | |
| Support frame | Black powder-coated tapered steel legs with a 32 mm upper tube and brass effect foot ferrules | |
| Privacy screen | Padded fabric or leather-look upholstery over a 35 mm board with rounded metal top rail | |
| Drawer hardware | Side-mounted ball-bearing drawer slides with one integrated lock on the top drawer area | |
| Power panel | White thermoplastic socket inserts set in a charcoal panel, supplied as a 6-outlet desktop power cluster |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated work and storage layout | The side credenza, hutch shelf and projecting desktop provide one seated work bay plus adjacent filing, display and computer-tower storage. | |
|---|---|---|
| Power and cable management | The six-socket panel sits beside the equipment bays, supporting desktop devices and tower computers while cables route behind the central divider. | |
| Privacy and sight-line control | The 350 mm-high upholstered divider screens the rear shelf and equipment without blocking seated sight lines across the desktop. | |
| Drawer filing and lock control | Three vertically stacked drawers use side slides for file access, while the visible cylinder lock secures the top drawer or pedestal set. |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive office | Suitable for managers and directors needing a writing desk, personal filing, display shelf and computer storage in one continuous wall-side unit. | |
|---|---|---|
| Professional meeting or consultant room | Supports laptop work, document review and concealed equipment storage in a premium advisory or sales office. |
EU Market Access Requirements* EN Standards
| EN 527-1 office desk dimensions | Use seated work-surface height, knee clearance and safety requirements as the workstation acceptance basis. | |
|---|---|---|
| EN 527-2 office desk mechanical safety | Specify stability, vertical load and durability testing for the desktop and support structure. | |
| EN 16139 seating strength does not apply; storage strength follows EN 16121 | Use EN 16121 for non-domestic storage cabinets, shelves, drawers and door durability. | |
| EN 60884-1 plugs and socket-outlets | Applicable standards and test results require confirmation |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5 desk and table products | Use as the structural performance, load and stability acceptance reference for the work surface and legs. | |
|---|---|---|
| ANSI/BIFMA X5.9 storage units | Apply to drawer operation, shelf deflection, lock cycling and cabinet stability. | |
| ANSI/BIFMA E3 electrical furniture systems | Use for integrated power distribution, outlet mounting, grounding and cable-management review. |
Standards applicable to China-market projects
| GB/T 3324 dimensional and structural guidance | Apply to wooden furniture dimensions, tolerances, surface inspection and assembly quality for the cabinet and desktop. | |
|---|---|---|
| GB/T 3325 metal furniture structural guidance | Apply to steel leg strength, coating integrity, stability and load-bearing inspection. | |
| GB/T 10357.6 cabinet strength test | Use as a shelf and cabinet static-load acceptance reference for storage compartments. | |
| GB 2099.1 socket safety | Apply if the six-socket module is supplied for the China market; require rated current, grounding and supplier certificate. |
This product must meet the following technical requirements: 1. GB/T 3324 dimensional and structural guidance: Apply to wooden furniture dimensions, tolerances, surface inspection and assembly quality for the cabinet and desktop.; 2. GB/T 3325 metal furniture structural guidance: Apply to steel leg strength, coating integrity, stability and load-bearing inspection.; 3. GB/T 10357.6 cabinet strength test: Use as a shelf and cabinet static-load acceptance reference for storage compartments.; 4. GB 2099.1 socket safety: Apply if the six-socket module is supplied for the China market; require rated current, grounding and supplier certificate.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
