Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seater sofa dimensions | 2100 x 850 x 820 mm | |
|---|---|---|
| Overall single armchair dimensions | 950 x 850 x 820 mm | |
| Coffee table overall dimensions | 1200 x 650 x 450 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (usable) | 550 mm | |
| Backrest height above seat | 400 mm | |
| Armrest height above seat | 180 mm | |
| Armrest width | 120 mm | |
| Chrome leg height | 120 mm | |
| Coffee table glass top thickness | 12 mm | |
| Coffee table metal leg tubing diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 185 kg | |
|---|---|---|
| Single seat static load capacity | 150 kg | |
| Total sofa set seating capacity | 5 persons | |
| Seat foam density | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Seam stitch strength | 100 N | |
| Chrome frame corrosion resistance | 48 hours | |
| Foam indentation load deflection (seat) | 220 N | |
| Foam rebound rate | 40% | |
| Furniture tipping threshold (horizontal force) | 300 N |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Red smooth PU faux leather, 1.0mm thickness | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam, wrapped with polyester fiber batting | |
| Back cushion core | Medium-density polyurethane foam, attached to internal frame | |
| Internal seating frame | 20mm x 40mm rectangular steel tube, powder-coated internal finish | |
| Exterior support legs | Polished chrome-plated cold-rolled steel, 1.2mm wall thickness | |
| Coffee table top | Clear tempered safety glass, polished flat edge | |
| Coffee table support frame | Polished chrome-plated steel with cross-braced base, black accent side leg | |
| Seat underside dust cover | Black non-woven polypropylene fabric | |
| Upholstery stitching | Nylon-bonded thread, 8 stitches per 30mm seam pitch | |
| Armrest internal structure | 12mm thickness medium-density fiberboard wrapped with foam, same PU upholstery as seat/back | |
| Exterior seating support legs | Polished chrome-plated cold-rolled steel, 1.2mm wall thickness, integrated perimeter foot frame | |
| Leg floor glides | 8mm thick nylon glide pads, press-fit into base of each steel leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed non-reclining upright posture, designed for formal short-duration reception seating | |
|---|---|---|
| Assembly requirement | Knock-down leg attachment for seating pieces, bolt-on assembly for coffee table frame and top | |
| Floor protection | Plastic glide pads fitted to bottom of all metal legs to prevent hard floor scratching | |
| Upholstery maintenance | Smooth non-porous surface allows wipe-clean disinfection suitable for public office spaces | |
| Coffee table function | Flat stable surface for placing documents, laptops, beverages and reception reading materials | |
| Stability design | Wide-set four legs per seating piece and cross-braced coffee table base to prevent tipping under normal use | |
| Color consistency | Matching uniform red upholstery and chrome finish across all seating pieces in the set | |
| Cleaning access | 120mm ground clearance under all seating units allows robotic vacuum and broom access without moving furniture | |
| Load distribution | Perimeter steel leg frame transfers occupant weight evenly across four contact points, preventing floor indentation on soft commercial carpet | |
| Edge safety | Rounded 2mm radius edges on all glass table corners and upholstered arm edges to eliminate sharp contact hazards for visitors | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 4 | |
|---|---|---|
| Largest shipping carton dimensions | 2150 x 900 x 650 mm | |
| Total shipping gross weight | 210 kg | |
| Total shipping volume | 2.6 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 10 sets | |
| 40ft HQ container loading quantity | 24 sets | |
| Packaging materials | 5-layer corrugated carton, EPS foam corner protection, PE film wrap, hardware kit with assembly instructions | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Office reception lobbies | Formal structured seating for visitor waiting areas, matching professional corporate office environments | |
|---|---|---|
| Executive meeting lounges | Small group discussion seating for informal internal meetings or client consultations | |
| Public waiting areas | Durable wipe-clean upholstery suitable for high-traffic service areas including banking, healthcare admin or government reception spaces | |
| Open plan office breakout zones | Compact modular layout creates defined casual seating areas without overcrowding open workspaces | |
| Recommended accessory pairing | Pair with low-pile commercial area rug and arc floor lamp as shown for a complete curated reception layout | |
| Corporate office reception lobbies | Formal structured 5-person seating arrangement for visitor waiting areas, with professional red upholstery and chrome finishes matching modern corporate front-of-house environments | |
| High-traffic public waiting areas | Durable wipe-clean PU upholstery suitable for banking branches, healthcare administrative lobbies and government service centers with high daily visitor turnover | |
| Showroom and gallery waiting areas | Stylized contemporary design suitable for automotive showrooms, design studios and retail customer waiting spaces, creating a polished professional impression for visitors |
EU Market Access Requirements* EN Standards
| Office furniture seating safety recommendation | EN 1335:2020 | |
|---|---|---|
| Furniture glass safety recommendation | EN 12150:2015 | |
| Upholstered furniture durability recommendation | EN 16139:2013 | |
| Non-domestic seating safety recommendation | EN 16139:2013 | |
| Furniture toughened glass safety recommendation | EN 12150:2015 | |
| Upholstery abrasion recommendation | EN 14465:2004 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 17927.1 | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2 | |
| Furniture mechanical stability recommendation | GB/T 10357.2 | |
| Upholstered furniture flammability recommendation | GB 17927.1 | |
| Tempered glass furniture safety recommendation | GB 15763.2 | |
| Formaldehyde emission recommendation | GB 18584 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 17927.1; 2. Tempered glass safety recommendation: GB 15763.2; 3. Furniture mechanical stability recommendation: GB/T 10357.2; 4. Upholstered furniture flammability recommendation: GB 17927.1; 5. Tempered glass furniture safety recommendation: GB 15763.2; 6. Formaldehyde emission recommendation: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
