Automatic mm / inch conversion · Core engineering specifications
| Overall L-shaped footprint | 2400 x 2400 x 750 mm | |
|---|---|---|
| Single modular seat unit dimensions | 600 x 600 x 750 mm | |
| Seat height from floor to top of cushion | 420 mm | |
| Seat cushion depth | 550 mm | |
| Backrest height above seat cushion | 330 mm | |
| Armrest height above floor | 650 mm | |
| Hexagonal ottoman dimensions | 450 x 450 x 400 mm | |
| Metal leg height | 120 mm | |
| Corner internal knee clearance | 600 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total product net weight (all 4 sofa modules) | 140 kg | |
|---|---|---|
| Static load capacity per seat position | 150 kg | |
| Total recommended seating capacity | 4 persons | |
| Seat foam density | 40 kg/m³ | |
| Backrest foam density | 28 kg/m³ | |
| Fabric upholstery abrasion resistance | 50000 Martindale cycles | |
| Frame static load rating | 600 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | Woven polyester commercial fabric in matte multi-color (orange, mid-grey, lime green, teal, lime green/red for ottomans) | |
|---|---|---|
| Seat cushion core | High resilience polyurethane foam wrapped with soft polyester fiber layer | |
| Backrest core | Medium-density polyurethane foam with fiber topper for soft back support | |
| Inner support frame | Kiln-dried solid wood and structural plywood frame with screwed and doweled joinery | |
| Support legs | Chrome-plated cast zinc alloy tapered angled legs, 4 legs per modular unit | |
| Seat support deck | Elastic webbing suspension stretched across seat frame under foam cushion | |
| Seam construction | Reinforced stitched seams with 8 stitches per 30mm pitch at all fabric panel joints | |
| Modular connection hardware | Heavy-duty metal connecting clips fitted to adjacent module bases to prevent shifting | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | All 4 seat units connect via underside metal clips, allowing rearrangement into linear, U-shape or separate individual seats as needed | |
|---|---|---|
| Integrated end armrests | Upholstered curved armrests fitted to the two outermost end units, providing soft arm support without sharp corners | |
| Auxiliary ottoman use | Matching hexagonal upholstered ottomans function as movable footrests or temporary extra side seating, positioned freely around the sofa | |
| Low-back lounge support | Low profile backrest provides relaxed upper back support for casual conversation and break use, not designed for full lumbar support during extended desktop work | |
| Floor protection | Each metal leg is fitted with a non-scratch felt floor glide to prevent damage to carpet or hard flooring, with no rolling casters | |
| Stain-resistant maintenance | Commercial-grade fabric upholstery allows spot cleaning with mild detergent for regular office spill maintenance | |
| Leveling adjustment | Each leg has a 10mm threaded height adjustment to compensate for uneven office flooring | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total number of shipping packages | 6 | |
|---|---|---|
| Largest shipping carton dimensions | 650 x 650 x 800 mm | |
| Total shipping gross weight | 165 kg | |
| Total shipping volume (CBM) | 1.94 CBM | |
| On-site assembly time | 20 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 46 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Office breakout and lounge areas | Ideal for informal employee break spaces, relaxation zones and casual meeting corners, with relaxed seat height and colorful design to reduce work environment formality | |
|---|---|---|
| Startup and creative office environments | Vibrant multi-color upholstery suits creative agency, tech startup and co-working spaces where informal collaboration and visual energy are prioritized | |
| Reception waiting areas | Suitable for small office reception zones placed in a corner, providing 4 seats for waiting visitors without occupying excessive floor space | |
| Informal collaboration spaces | Low-back modular configuration supports casual team discussions and quick brainstorming sessions without the formality of conference room seating | |
| Education and training common rooms | Durable contract-grade construction suits student common rooms and campus staff lounge areas with regular daily use | |
| Recommended complementary furniture | Pair with small round side tables for placing drinks and devices; use additional matching ottomans to expand seating capacity for larger groups |
EU Market Access Requirements* EN Standards
| Office lounge furniture safety recommendation | EN 16139:2013 Furniture - Seating - Strength, durability and safety for non-domestic seating | |
|---|---|---|
| Upholstery flame retardant recommendation | EN 1021:2014 Upholstered furniture - Assessment of ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette |
US and Canada office-furniture standards
| Lounge seating durability recommendation | ANSI/BIFMA X2022Lounge and Public Seating | |
|---|---|---|
| Upholstered furniture VOC recommendation | ANSI/BIFMA e2019Furniture Sustainability Standard |
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Fabric safety recommendation | GB 20286Fire performance of furniture and upholstery components in public places | |
| Formaldehyde emission recommendation | GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 3324General technical requirements for wooden furniture; 2. Fabric safety recommendation: GB 20286Fire performance of furniture and upholstery components in public places; 3. Formaldehyde emission recommendation: GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
