Automatic mm / inch conversion · Core engineering specifications
| Three-seater sofa overall size | 2100 x 850 x 880 mm | |
|---|---|---|
| Single armchair overall size | 950 x 850 x 880 mm | |
| Coffee table overall size | 1300 x 700 x 520 mm | |
| Sofa seat height from floor | 430 mm | |
| Sofa seat depth | 600 mm | |
| Sofa seat cushion thickness | 120 mm | |
| Backrest height above seat | 450 mm | |
| Armrest height above seat | 180 mm | |
| Coffee table open shelf clearance | 300 mm | |
| Coffee table drawer front height | 150 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Three-seater sofa net weight | 75 kg | |
|---|---|---|
| Three-seater sofa total static load capacity | 480 kg | |
| Recommended total occupancy | 5 people | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Foam indentation load deflection (seat) | 40 kg/m³ | |
| Seat foam indentation load deflection | 40 kg/m³ | |
| Back foam indentation load deflection | 30 kg/m³ | |
| Drawer slide load rating | 25 kg | |
| Seam tensile strength | 120 N | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa external upholstery | 0.8mm thick grey PU (faux leather) | |
|---|---|---|
| Seat core padding | 40kg/m³ high-density polyurethane foam | |
| Backrest core padding | 30kg/m³ medium-density polyurethane foam | |
| Sofa internal frame | 30mm x 50mm kiln-dried solid wood + 12mm multilayer plywood | |
| Sofa support legs | 20mm diameter matte black powder-coated steel legs | |
| Coffee table frame | 30mm x 30mm matte black powder-coated square steel tube | |
| Coffee table tabletop | 18mm thick black fire-retardant laminate panel | |
| Coffee table drawer fronts | 15mm thick walnut wood-grain melamine-faced MDF | |
| Coffee table drawer slides | Cold-rolled steel ball-bearing 3-section slides | |
| Sofa stitching | 8 stitches per 100mm seam pitch | |
| Sofa seat support | 70mm wide elastic webbing + 2.4mm sinuous spring | |
| Floor protection glides | 5mm thick HDPE non-marking glides |
Adjustment / rotation / tilt / mobility / storage features
| Fixed reception seating posture | Pre-set 105° backrest angle | |
|---|---|---|
| Coffee table dual storage configuration | Right-side 3-drawer closed storage + left-side open lower shelf | |
| Integrated tea service zone on tabletop | Embedded flush tea tray area on tabletop | |
| Non-marking floor protection | Plastic anti-slip glides installed on bottom of all sofa legs | |
| Modular set layout flexibility | Separated three-seater and two single chairs | |
| Stain-resistant upholstery surface | Water-repellent PU leather surface | |
| Leveling adjustment for table | Adjustable foot pads on coffee table bottom | |
| Integrated tea service zone | Embedded flush tea tray area on tabletop | |
| Table leveling adjustment | 15mm adjustable foot pads on coffee table bottom | |
| Backrest integrated lumbar support | Curved raised lower backrest section | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Corporate executive reception rooms | Formal grey neutral style matches executive office decor, provides seating for 5 visitors for business meetings and guest reception | |
|---|---|---|
| Government and institutional meeting waiting areas | Wear-resistant faux leather and sturdy frame supports high daily visitor traffic, easy to clean and maintain for public-facing office areas | |
| Small office lounge areas | Compact modular layout fits 25sqm rooms, provides comfortable seating for staff breaks and informal internal discussions | |
| High-end shared office common areas | Consistent professional appearance matches co-working space design, modular layout allows reconfiguration for different event sizes | |
| Recommended matching configuration | Pair with 1.6m wide matching TV cabinet and 2000x3000mm commercial office carpet to create a coordinated reception space aesthetic | |
| Enterprise customer visit waiting zones | Fixed stable seating structure avoids casual movement, integrated tea table supports hospitality service for visiting clients |
EU Market Access Requirements* EN Standards
| EN 13759:2010 | Domestic and non-domestic furniture - Seating - Test methods for the determination of strength and durability, applicable to sofa structural performance verification | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable to office reception coffee table performance | |
| EN 1021-1:2014 | Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette, recommended for commercial office fire safety |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame and laminate component quality inspection for reception seating and tables | |
|---|---|---|
| GB/T 16799-2008 | Standard for polyurethane synthetic leather used for furniture, applicable to upholstery material performance verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, required for indoor office air quality compliance | |
| GB/T 10357.1-2013 | Test of mechanical properties of furniture - Strength and durability of tables, applicable to coffee table static load and durability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame and laminate component quality inspection for reception seating and tables; 2. GB/T 16799-2008: Standard for polyurethane synthetic leather used for furniture, applicable to upholstery material performance verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, required for indoor office air quality compliance; 4. GB/T 10357.1-2013: Test of mechanical properties of furniture - Strength and durability of tables, applicable to coffee table static load and durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
