Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 2100 x 850 x 820 mm | |
|---|---|---|
| Single armchair overall dimensions | 920 x 850 x 820 mm | |
| Coffee table overall dimensions | 1200 x 650 x 450 mm | |
| Seat height from floor | 430 mm | |
| Seat depth for all seating units | 580 mm | |
| Backrest height above seat | 390 mm | |
| Armrest height above seat | 180 mm | |
| Chrome support leg height | 120 mm | |
| Coffee table glass top thickness | 12 mm | |
| Coffee table metal leg diameter | 30 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest cushion thickness | 80 mm | |
| Seat width per position (3-seat sofa) | 620 mm | |
| Armrest width (per side) | 120 mm | |
| Coffee table under-clearance | 400 mm | |
| Finished Seat Cushion Thickness | 90 mm |
Net weight / load capacity / users / durability
| 3-seat sofa net weight | 85 kg | |
|---|---|---|
| Seat static load capacity per position | 150 kg | |
| Total set seating capacity | 5 persons | |
| Recommended fabric abrasion resistance | 50000 double rubs (Martindale) | |
| Seat foam density | 40 kg/m³ | |
| Back foam density | 30 kg/m³ | |
| Foam rebound rate | 45% | |
| Chrome frame corrosion resistance | 48 hours | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery material | Red polyurethane (PU) faux leather, 1.0mm thickness | |
|---|---|---|
| Seat internal frame | 15mm thick plywood frame with reinforced corner blocks | |
| Seat cushion padding | High-resilience polyurethane foam, 120mm thickness, wrapped in 20g polyester wadding | |
| Backrest padding | Medium-density polyurethane foam, 80mm thickness, wrapped in 20g polyester wadding | |
| Seating support legs and base frame | Polished 1.2mm thick chrome-plated tubular steel | |
| Coffee table top | 12mm thick clear tempered glass with polished flat edge | |
| Coffee table frame | 1.2mm thick polished chrome-plated steel with angled leg design and cross-brace support | |
| Upholstery stitching | Color-matched bonded polyester thread, 8 stitches per 30mm seam pitch | |
| Armrest structure | Padded top matching seat upholstery, integrated with sofa frame on internal plywood supports | |
| Seat spring support | 4mm diameter sinuous steel springs spaced 100mm apart, secured to frame with plastic spring clips | |
| Foot glides | 10mm diameter nylon glide pads fitted to all metal leg bases | |
| Upholstery substrate | 5mm thick hardboard backing panel under backrest upholstery, secured with staples to inner frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed pre-configured set including 1 three-seat sofa, 2 single armchairs and 1 matching coffee table | |
|---|---|---|
| Seating support | Fixed non-reclining, non-tilting upright seat and back design | |
| Floor protection | All metal legs fitted with plastic glide feet at contact points | |
| Coffee table function | Fixed height flat top surface for placement of visitor items including laptops, documents, beverageware and reading materials | |
| Upholstery maintenance | Smooth non-porous faux leather surface allows wipe-clean with standard neutral cleaning agents | |
| Modular arrangement flexibility | All seating units are free-standing, can be arranged in linear, U-shape or L-shape configurations to fit different reception room layouts | |
| Under-seat clearance | 120mm open space under all seating units allows access for standard vacuum cleaners and floor cleaning tools | |
| Structural durability | Integrated steel and plywood frame design eliminates loose fastener points common in knockdown budget seating, suitable for 8+ hours of daily public area use | |
| Seating posture | Fixed non-reclining, non-tilting upright seat and back design with 100° seat-back angle | |
| Color fastness | Upholstery meets grade 4 light fastness to prevent fading under standard indoor office lighting over 3 years of use | |
| Edge safety | All upholstered edges have 10mm radius rounded corners, glass table top has 1mm polished beveled edge to eliminate sharp contact points | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Total shipping units | 6 packages | |
|---|---|---|
| 3-seat sofa packing carton dimensions | 2150 x 900 x 600 mm | |
| Single armchair packing carton dimensions | 970 x 900 x 600 mm | |
| Coffee table glass top carton dimensions | 1250 x 700 x 80 mm | |
| Coffee table frame carton dimensions | 1220 x 670 x 150 mm | |
| Total set gross shipping weight | 185 kg | |
| Total set shipping volume | 1.92 CBM | |
| Assembly time | 30 minutes | |
| 40HQ container loading quantity | 42 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Ideal for company lobbies and visitor waiting areas, formal red upholstery creates a professional welcoming appearance for guest seating | |
|---|---|---|
| Executive office meeting zones | Suitable for placement in private executive suites for informal small group meetings with 5 visitors, matched coffee table supports document and device placement | |
| Public service waiting spaces | Applicable for bank, government service hall or consultancy waiting areas, durable wipe-clean upholstery withstands high daily visitor traffic | |
| Hotel business lounge areas | Suitable for hotel business centers or executive lounge seating zones, modern chrome and faux leather finish matches contemporary hospitality interior design | |
| Recommended complementary placement | Pair with a matching arc floor lamp and neutral low-pile area rug as shown, to define the seating zone in open plan lobby spaces | |
| Color option availability | Standard red finish as shown; alternative black, dark brown and light gray upholstery options are typical for this style of commercial reception set for interior color coordination | |
| Recommended warranty term | 3 years structural warranty for frames, 1 year warranty for upholstery and foam components, standard for commercial grade office reception furniture | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 13759:2012 | Domestic and contract furniture - Seating - Test methods for strength and durability, applicable for structural load testing of seat and backrests for commercial use | |
|---|---|---|
| EN 1022:2018 | Domestic and contract furniture - Seating - Determination of stability, applicable for verifying seating units do not tip during normal visitor use | |
| EN 12521:2015 | Furniture - Strength, durability and safety - Requirements for domestic tables, applicable for structural and safety verification of the glass-top coffee table | |
| EN 15372:2008 | Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable for commercial office contract use verification of the coffee table | |
| EN 1021-1:2014 | Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette, applicable for fire safety verification of upholstered components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for Lounge and Public Seating, applicable for commercial office reception seating structural performance, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Standard for Desk Products, applicable for static load and stability testing of the reception coffee table used in office environments |
Standards applicable to China-market projects
| GB 28007-2011 | General technical requirements for upholstered furniture, applicable for structural safety, foam and upholstery material performance verification for this reception seating set | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for internal plywood frame structural performance and dimension tolerance checks | |
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable for chrome-plated steel frame corrosion resistance, strength and stability testing | |
| GB 15763.2-2005 | Safety glazing materials in building - Part 2: Tempered glass, applicable for mandatory safety certification of the coffee table glass top |
This product must meet the following technical requirements: 1. GB 28007-2011: General technical requirements for upholstered furniture, applicable for structural safety, foam and upholstery material performance verification for this reception seating set; 2. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for internal plywood frame structural performance and dimension tolerance checks; 3. GB/T 3325-2017: General technical requirements for metal furniture, applicable for chrome-plated steel frame corrosion resistance, strength and stability testing; 4. GB 15763.2-2005: Safety glazing materials in building - Part 2: Tempered glass, applicable for mandatory safety certification of the coffee table glass top; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
