Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 2000 x 800 x 850 mm | |
|---|---|---|
| Single armchair overall dimensions | 820 x 780 x 850 mm | |
| Coffee table overall dimensions | 1200 x 650 x 450 mm | |
| Side end table overall dimensions | 600 x 600 x 550 mm | |
| Seat height (sofa and armchairs) | 420 mm | |
| Seat depth (sofa and armchairs) | 500 mm | |
| Backrest height (sofa and armchairs) | 430 mm | |
| Armrest height above seat | 180 mm | |
| Chrome frame tube diameter | 50 mm | |
| Tempered glass table top thickness | 12 mm | |
| Lower coffee table shelf dimensions | 1100 x 550 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 185 kg | |
|---|---|---|
| 3-seat sofa total static load capacity | 360 kg | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Chrome frame static load test rating (per chair) | 150 kg | |
| Recommended maximum occupancy for full set | 5 people | |
| Upholstery Martindale abrasion resistance | 50000 cycles | |
| Seat cushion foam compression set rating | 45 % | |
| Full set maximum recommended occupancy | 5 people | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Dark brown tufted split PU faux leather, 1.2mm thickness | |
|---|---|---|
| Seat cushion core | 40mm high density polyurethane foam, 40kg/m³ density, 45% rebound | |
| Backrest cushion core | 30mm high density polyurethane foam, 35kg/m³ density | |
| Structural frame for seating | 1.5mm thick polished chrome plated cold rolled steel cantilever frame | |
| Armrest padding | 20mm dense foam wrapped under matching upholstery, fixed to steel frame | |
| Table tops | 12mm thick black tempered safety glass with polished flat edges | |
| Table support frames | 50mm diameter polished chrome plated steel tube, matching seating frame finish | |
| Lower coffee table shelf | 8mm thick black tempered safety glass | |
| Frame connection hardware | Zinc plated steel bolts and cross dowels, corrosion resistant | |
| Floor contact glides | Hard plastic non-marking glides fitted to frame feet | |
| Seating support suspension | 40 mm width elastic webbing spaced 80 mm apart under seat foam | |
| Table top panels | 12 mm thick black tempered safety glass with polished flat edges |
Adjustment / rotation / tilt / mobility / storage features
| Cantilever seat flex | Integrated curved steel frame provides gentle flexible give when seated, no mechanical recline | |
|---|---|---|
| Tufted back support | Quilted square tufted panels maintain backrest shape, prevent upholstery shifting with repeated use | |
| Two-tier coffee table storage | Raised main top for serving, lower glass shelf for storage of books, magazines or decor | |
| Fixed assembly structure | All frames bolt together for permanent stable installation, no folding or moving parts on frames | |
| Floor protection | Integrated non-marking glides on all frame feet allow repositioning without scratching tile or polished stone floors | |
| Modular set layout flexibility | Pieces can be arranged in multiple configurations to fit office reception, meeting or executive lounge spaces | |
| Stain resistant upholstery | Smooth PU leather surface can be wiped clean of spills with a damp cloth, suitable for high traffic public office areas | |
| Matching visual coordination | All pieces use identical chrome frame finish and dark brown upholstery for a cohesive professional appearance | |
| Cantilever seat flex response | Integrated curved steel frame provides 12 mm of flexible vertical give when seated, no mechanical recline mechanism | |
| Tufted upholstery shape retention | 80 mm spaced square tufted panels secure upholstery and foam layers, prevent material shifting over 50000 use cycles | |
| Floor protection during repositioning | Integrated non-marking glides on all frame feet allow repositioning without scratching polished tile, stone or hardwood floors | |
| Flexible modular layout | 2 armchairs, 1 three-seat sofa, 1 coffee table and 1 side table can be arranged in L-shape, linear or clustered configurations to fit variable space dimensions |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive office reception lounge | Suitable for placing in private executive office areas to host visiting clients and internal meetings, professional formal appearance | |
|---|---|---|
| Corporate building lobby waiting areas | Durable construction and easy to clean upholstery suited for high traffic public waiting zones | |
| Small business meeting breakout spaces | Five person occupancy supports informal small group discussions and collaborative work | |
| Hotel executive lounge seating | Polished chrome and dark leather aesthetic matches luxury hotel public area design requirements | |
| Boardroom ancillary waiting space | Placed outside formal boardrooms to provide comfortable seating for attendees before meetings | |
| Recommended complementary accessories | Low pile commercial area rug, table lamps, decorative accent items placed on tables to complete lounge presentation | |
| Flooring compatibility | Suitable for installation on polished tile, stone, hardwood and commercial carpet flooring, non-marking glides prevent floor damage | |
| Executive office reception zones | Placed inside private executive suites to host visiting clients and conduct small internal meetings, formal tufted chrome design matches high-end corporate interiors |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic and contract furniture - Seating - Determination of stability, applicable to verify seating does not tip during normal use | |
|---|---|---|
| EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, referenced for minimum structural performance for contract use | |
| EN 15372:2016 | Furniture - Durability requirements for tables for non-domestic use, applicable to coffee and side tables in office environments |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for Lounge Seating, defines static load, durability and stability requirements for public and office lounge seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Standard for Desk Products, applies to the coffee and side tables for load and stability performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden and upholstered furniture, applicable for structural stability and finish quality inspection | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in upholstered furniture, mandatory requirement for formaldehyde and heavy metal content | |
| GB/T 10357.3-2013 | Test method for furniture strength and durability: seating furniture, applicable for static load and fatigue testing of chairs and sofa | |
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable for chrome frame adhesion and corrosion resistance inspection |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden and upholstered furniture, applicable for structural stability and finish quality inspection; 2. GB 18584-2001: Limit of harmful substances in upholstered furniture, mandatory requirement for formaldehyde and heavy metal content; 3. GB/T 10357.3-2013: Test method for furniture strength and durability: seating furniture, applicable for static load and fatigue testing of chairs and sofa; 4. GB/T 3325-2017: General technical requirements for metal furniture, applicable for chrome frame adhesion and corrosion resistance inspection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
