Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2100 x 850 x 800 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 850 x 800 mm | |
| Coffee table overall dimensions | 1300 x 700 x 450 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (usable) | 580 mm | |
| Armrest height from seat | 180 mm | |
| Backrest total height from seat | 380 mm | |
| Coffee table glass top thickness | 12 mm | |
| Sofa leg height | 80 mm | |
| Side end table dimensions | 600 x 600 x 450 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seater sofa weight | 85 kg | |
|---|---|---|
| Single armchair weight per unit | 38 kg | |
| Coffee table weight | 45 kg | |
| Per-seat static load capacity | 150 kg | |
| Seating capacity (full set) | 5 people | |
| Upholstery abrasion resistance | 50000 cycles | |
| Foam density (seat cushions) | 45 kg/m³ | |
| Foam rebound rate (seat cushions) | 45% | |
| 3-seater sofa net weight | 85 kg | |
| Full set total seating capacity | 5 people |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick wine red PU leather with grid tufted detailing | |
|---|---|---|
| Seat cushion core | 45kg/m³ high-resilience polyurethane foam, 120mm thick | |
| Backrest cushion core | 35kg/m³ polyurethane foam, 80mm thick | |
| Inner sofa frame | 25mm thick kiln-dried solid hardwood frame with metal corner bracing | |
| Sofa legs | 1.5mm thick polished chrome plated zinc alloy, tapered square design | |
| Armrest structure | Padded PU leather over solid wood frame, same thickness as seat upholstery | |
| Coffee table top | 12mm thick tempered black glass with 2 polished gold metal decorative inlay strips | |
| Coffee table frame | 1.2mm thick polished 304 stainless steel rectangular tube, open box frame design | |
| Stitching details | 8 stitches per 50mm seam length, matching wine red thread | |
| Side end table top | 10mm thick tempered black glass, matching polished metal frame | |
| Inner seating frame | 25mm thick kiln-dried solid hardwood frame with 1.5mm steel corner bracing at all joints | |
| Sofa support legs | 1.5mm thick polished chrome-plated zinc alloy, tapered square design with integrated non-slip plastic glide |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 3+1+1 modular arrangement, can be positioned in U-shape for face-to-face reception meetings | |
|---|---|---|
| Surface maintenance | Smooth PU leather upholstery can be wiped clean with mild detergent for spill and stain removal | |
| Coffee table placement | Stable open-frame table provides central surface for drink service, document placement and decorative items, no integrated storage | |
| Floor protection | Each metal leg is fitted with a non-slip plastic floor glide to prevent scratching hard tile or wood flooring | |
| Tufted back design | Segmented grid tufting prevents foam shifting over long term use and creates structured formal aesthetic | |
| Leg structure | Fixed non-swivel, non-adjustable metal legs provide rigid stable support without wobble on level flooring | |
| Color option | Primary finish is wine red; additional standard color options (black, brown) are available to match different office decor schemes | |
| Edge protection | All sofa armrest and frame edges are rounded and padded to eliminate sharp corners for user safety in busy reception areas | |
| Layout configuration | Fixed 3+1+1 modular units that can be arranged in a U-shape for face-to-face reception meetings, no inter-unit connectors required for standard placement | |
| Table functionality | Central open-frame coffee table provides a stable flat surface for drink service, document placement and decorative items, with no integrated drawers or closed storage | |
| Tufted structure function | Uniform grid tufting across seats and backs secures foam cores in place to prevent shifting over 5 years of regular use, and creates a structured formal aesthetic | |
| Structural support | Fixed non-swivel, non-adjustable metal legs provide rigid stable support with less than 2mm lateral wobble on level finished flooring |
Verified carton / gross weight / assembly / loading data
| Total packaging pieces per full set | 7 packages | |
|---|---|---|
| Sofa unit packaging (3-seater) | 2150 x 900 x 650 mm, 95 kg gross weight | |
| Single armchair packaging per unit | 950 x 900 x 650 mm, 43 kg gross weight | |
| Coffee table packaging | 1350 x 750 x 150 mm (glass top) + 1350 x 750 x 200 mm (frame parts), 55 kg total gross weight | |
| Side end table packaging | 650 x 650 x 120 mm, 18 kg gross weight | |
| Total shipment volume per full set | 1.9 CBM | |
| Assembly time per full set | 60 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 46 sets | |
| 3-seater sofa packaging | 2150 x 900 x 650 mm, 95 kg gross weight |
Recommended spaces / users / usage modes
| Corporate office reception areas | Formal structured design creates professional first impression for visiting clients, suitable for waiting rooms and executive reception zones | |
|---|---|---|
| Executive office meeting nooks | Compact U-shaped arrangement supports small informal discussions between executives and 3visitors, paired coffee table provides surface for document review and refreshments | |
| Government and institutional meeting rooms | Formal non-reclining fixed seating aligns with official meeting space requirements, easy-to-clean leather finish simplifies regular facility maintenance | |
| Hotel business lounges | Durable commercial grade construction supports continuous high-volume guest use, polished metal legs complement modern hotel lobby interior finishes | |
| Small business meeting spaces | 5-person seating capacity accommodates small team meetings or client consultations without taking excessive floor space, modular units can be repositioned for different layout needs | |
| Recommended matching configuration | Pair with 2 matching black glass side tables for additional surface space next to single armchairs, add 600mm diameter floor plant decor to complete formal reception layout | |
| Corporate office reception lobbies | Formal structured wine red design creates a professional first impression for visiting clients, with durable upholstery rated for 50000 abrasion cycles to handle regular visitor traffic | |
| Hotel business center lounges | Commercial grade load-rated construction supports continuous high-volume guest use, with polished chrome legs that complement modern hotel lobby interior finishes |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Applicable standard for domestic and contract seating stability, specifies test methods for overturning resistance of stationary sofas and armchairs | |
|---|---|---|
| EN 12520:2015 | Applicable standard for furniture strength, durability and safety for domestic and contract seating, defines static load and fatigue test requirements | |
| EN 13722:2004 | Applicable standard for office furniture reception seating, specifies ergonomic and performance requirements for visitor and waiting area seating | |
| EN 12150-1:2015 | Applicable standard for thermally toughened soda lime silicate safety glass used in furniture, specifies impact and breakage requirements for glass table tops |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Applicable standard for lounge and public seating, defines static load, impact and durability test methods for commercial reception seating | |
|---|---|---|
| ANSI/BIFMA X7.1-2011 | Applicable standard for formaldehyde and TVOC emission limits for office furniture systems and seating, sets low-emission requirements for indoor office environments |
Standards applicable to China-market projects
| GB 18587-2001 | Applicable standard for limit of harmful substances in upholstered furniture, sets formaldehyde and VOC emission limits for indoor office use | |
|---|---|---|
| GB/T 3324-2017 | Applicable standard for general technical requirements for wooden furniture, covers solid wood frame moisture content, structural strength and surface finish | |
| GB/T 3280-2015 | Applicable standard for cold-rolled stainless steel sheet and strip, specifies material requirements for polished metal table frames |
This product must meet the following technical requirements: 1. GB 18587-2001: Applicable standard for limit of harmful substances in upholstered furniture, sets formaldehyde and VOC emission limits for indoor office use; 2. GB/T 3324-2017: Applicable standard for general technical requirements for wooden furniture, covers solid wood frame moisture content, structural strength and surface finish; 3. GB/T 3280-2015: Applicable standard for cold-rolled stainless steel sheet and strip, specifies material requirements for polished metal table frames; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
