Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1650 × 750 × 700 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth for two-seater sofa | 520 mm | |
| Armrest height from seat | 180 mm | |
| Backrest height above seat | 350 mm | |
| Frame tubing diameter | 25 mm | |
| Seat cushion thickness | 100 mm | |
| Clearance under sofa frame | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight | 110 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Total set seating capacity | 4 persons | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Foam density (seat cushion) | 40 kg/m³ | |
| Recommended warranty period (frame) | 5 years | |
| Recommended warranty period (upholstery) | 2 years | |
| Upholstery Martindale abrasion resistance | 50000 cycles | |
| Seat foam density | 40 kg/m³ | |
| Back foam density | 35 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Black 1.2mm thick matte faux leather (PU) | |
|---|---|---|
| Seat cushion padding | High-density polyurethane foam, 100mm thick, 40kg/m³ density | |
| Back cushion padding | Medium-density polyurethane foam, 80mm thick, 35kg/m³ density | |
| Structural frame | Polished 201 stainless steel square tubing, 1.2mm wall thickness | |
| Internal support frame | 15mm thick multilayer plywood panel under seat cushions | |
| Frame weld joints | TIG welded polished joints, no exposed fasteners on visible surfaces | |
| Armrest padding | 20mm thick foam wrapped in matching black faux leather over steel frame | |
| Seat base webbing | 50mm wide elastic webbing spaced 100mm apart | |
| Internal seat support panel | 15mm thick E1-grade multilayer plywood under seat cushions | |
| Armrest top padding | 20mm thick polyurethane foam wrapped in matching black faux leather over steel frame | |
| Seat suspension system | 50mm wide high-elasticity webbing spaced 100mm apart across the seat frame | |
| Frame floor glides | 10mm diameter HDPE plastic glides pressed into all frame leg ends |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed non-reclining upright seating position | |
|---|---|---|
| Frame floor protection | Plastic glide feet fitted to all frame leg ends | |
| Assembly requirement | Knock-down construction requiring simple bolt-on leg/frame attachment | |
| Cleaning and maintenance | Non-porous faux leather surface wipes clean with standard mild detergent and soft cloth | |
| Modular arrangement flexibility | Individual seating units can be repositioned freely to match reception room layout | |
| Weight distribution | Four point tubular frame contact per unit, evenly distributing weight across floor surface | |
| Seating posture design | Fixed non-reclining 105° upright seated back angle | |
| Floor protection function | HDPE glide feet on all leg ends to prevent hard floor scratching and reduce movement noise on smooth surfaces | |
| Assembly configuration | Knock-down construction requiring bolt-on attachment of frame sections to pre-upholstered seat/back modules, all M8 hardware included | |
| Cleaning performance | Non-porous faux leather surface that resists liquid penetration, allowing full spill removal with mild neutral detergent and soft microfiber cloth | |
| Layout flexibility | Free-standing individual units with no permanent connecting hardware, allowing repositioning into linear, L-shaped or clustered layouts to match reception room dimensions | |
| Static stability rating | 10° tilt stability without tipping under offset occupant load |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packaged unit count | 4 cartons total: 1 carton per single armchair, 1 carton for the two-seater sofa, 1 carton for matching coffee table, 1 carton for matching side table | |
|---|---|---|
| Largest carton dimensions (sofa) | 1700 x 800 x 350 mm | |
| Total shipping gross weight | 160 kg | |
| Total shipping volume (CBM) | 1.0 CBM | |
| Assembly time per full set | 60 minutes | |
| 20ft GP container loading capacity | 42 sets | |
| 40ft HQ container loading capacity | 105 sets | |
| Total packaged carton count | 3 cartons total: 1 carton per single armchair, 1 carton for the two-seater sofa | |
| Largest carton dimensions (two-seater sofa) | 1700 x 800 x 350 mm | |
| Single armchair carton dimensions | 830 x 770 x 320 mm |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception areas | Formal professional seating for lobbies, visitor waiting areas and executive meeting anterooms, with a clean minimalist aesthetic suitable for modern office interiors | |
|---|---|---|
| Small business meeting spaces | Compact 4-person seating configuration for informal client meetings or small team discussion areas in open plan offices | |
| Public service waiting areas | Durable easy-clean upholstery suitable for bank, government office or medical clinic waiting rooms with regular visitor turnover | |
| Executive private office lounge zones | Coordinated seating paired with matching glass coffee tables for casual in-office meetings or break spaces adjacent to executive desks | |
| Co-working space common areas | Modular flexible seating that can be rearranged for events, small gatherings or individual work breaks in shared workspaces | |
| Showroom and gallery waiting zones | Minimalist chrome and black aesthetic complements contemporary interior design for retail, showroom or gallery visitor spaces | |
| Corporate office reception lobbies | Formal professional seating for visitor waiting areas and executive floor anterooms, with a clean minimalist aesthetic compatible with modern office interior design | |
| Small business client meeting spaces | Compact 4-person seating configuration for informal client discussions or small team breakout areas in open-plan office layouts |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office seating safety recommendation | EN 1335:2020 Office furniture - Office work chair - Part 1: Dimensions - safety, strength and durability, applicable for structural performance reference | |
|---|---|---|
| Furniture fire safety recommendation | EN 1021:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette | |
| Commercial seating strength recommendation | EN 16139:2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating | |
| Upholstered furniture ignitability recommendation | EN 1021:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette | |
| Formaldehyde emission recommendation | EN 13986:2004 Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Lounge seating performance recommendation | ANSI/BIFMA X2022 Lounge and Public Seating - Tests, applicable to structural and durability performance |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 3324 General technical requirements for wooden furniture, applicable to internal plywood support components | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18584 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture, applicable to internal plywood panels | |
| Leather/faux leather performance recommendation | GB/T 16799 Polyurethane synthetic leather for furniture, applicable to upholstery material | |
| Wooden furniture structural safety recommendation | GB/T 3324 General technical requirements for wooden furniture, applicable to internal plywood and hardboard support components | |
| Formaldehyde emission limit recommendation | GB 18584 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture, applicable to internal plywood panels | |
| PU synthetic leather performance recommendation | GB/T 16799 Polyurethane synthetic leather for furniture, applicable to all upholstery material |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 3324 General technical requirements for wooden furniture, applicable to internal plywood support components; 2. Formaldehyde emission recommendation: GB 18584 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture, applicable to internal plywood panels; 3. Leather/faux leather performance recommendation: GB/T 16799 Polyurethane synthetic leather for furniture, applicable to upholstery material; 4. Wooden furniture structural safety recommendation: GB/T 3324 General technical requirements for wooden furniture, applicable to internal plywood and hardboard support components; 5. Formaldehyde emission limit recommendation: GB 18584 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture, applicable to internal plywood panels; 6. PU synthetic leather performance recommendation: GB/T 16799 Polyurethane synthetic leather for furniture, applicable to all upholstery material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
