Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2100 x 850 x 880 mm | |
|---|---|---|
| Single armchair overall dimensions | 950 x 820 x 860 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Seat height (all seating units) | 420 mm | |
| Seat depth (3-seater sofa) | 560 mm | |
| Seat depth (single armchair) | 540 mm | |
| Backrest height (all seating units) | 460 mm | |
| Armrest height (all seating units) | 620 mm | |
| Coffee table top thickness | 25 mm | |
| Coffee table metal frame tube dimension | 30 x 30 mm | |
| Sofa seat cushion thickness | 120 mm | |
| Clearance under coffee table base | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| 3-seater sofa total weight | 75 kg | |
|---|---|---|
| Single armchair individual weight | 38 kg | |
| Coffee table weight | 28 kg | |
| 3-seater sofa total static load capacity | 450 kg | |
| Seating total occupant capacity | 5 persons | |
| Faux leather surface abrasion resistance | 50000 double rubs | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 30 kg/m³ | |
| 3-seater sofa net weight | 75 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | Brown matte PVC faux leather | |
|---|---|---|
| Seat core cushion padding | High-density polyurethane foam | |
| Backrest padding | Medium-density polyurethane foam | |
| Seating inner frame | Kiln-dried solid hardwood frame | |
| Seating outer side/arm accent panels | Walnut wood veneer over MDF substrate | |
| Coffee table top | Walnut wood veneer over MDF substrate | |
| Coffee table support frame | Matte black powder-coated carbon steel square tubing | |
| Seating glides | Hard plastic non-marking floor glides | |
| Upholstery stitching | Reinforced polyester thread, 8 stitches per 50mm | |
| Coffee table foot pads | TPE non-slip adjustable foot pads, 5mm adjustment range | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed-position non-reclining upright seating | |
|---|---|---|
| Armrest design | Integrated padded curved armrests with wood veneer lower trim | |
| Coffee table support | Open rigid steel sled frame with lower cross brace | |
| Floor protection | Fixed non-marking plastic glides on all seating and table feet | |
| Seating maintenance | Stain-resistant non-porous faux leather surface | |
| Assembly requirement | Knock-down assembly for coffee table, pre-assembled seating units | |
| Seating support | Fixed-position non-reclining upright support with 103° seat-back angle | |
| Armrest support | Integrated padded curved armrests with walnut veneer lower trim, 200mm armrest width | |
| Coffee table stability | Rigid welded open steel sled frame with lower perimeter cross brace | |
| Surface maintenance | Stain-resistant non-porous faux leather surface with wipe-clean finish | |
| Assembly configuration | Pre-assembled fully upholstered seating units, knock-down coffee table requiring frame-to-top attachment | |
| Table level adjustment | 5mm adjustable TPE foot pads on coffee table base |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 4 cartons | |
|---|---|---|
| 3-seater sofa carton dimensions | 2150 x 900 x 650 mm | |
| Single armchair carton dimensions | 1000 x 870 x 620 mm | |
| Coffee table carton dimensions | 1250 x 650 x 120 mm | |
| Total shipment gross weight | 185 kg | |
| Total shipment volume | 2.32 CBM | |
| On-site assembly time | 30 minutes | |
| 40HQ container loading capacity | 52 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Executive office reception areas | Formal professional seating configuration for visitor waiting zones in private executive offices, with coordinated wood veneer accents matching executive desk finishes | |
|---|---|---|
| Corporate lobby waiting spaces | Durable, easy-to-clean seating for high-traffic main building lobbies, with a central coffee table to hold reading materials and refreshments | |
| Conference room breakout zones | Seating for informal pre-meeting gatherings or break sessions adjacent to formal conference spaces, providing a relaxed but professional alternative to conference chairs | |
| Government and institutional guest rooms | Conservative, professional appearance suitable for formal official reception spaces, with medium-firm seating that maintains a formal posture | |
| Small business meeting reception areas | Complete 4-piece set that fills a standard 3m x 3m reception nook with coordinated seating and table, requiring minimal additional furnishing | |
| Executive office reception zones | Formal professional seating configuration for visitor waiting areas in private executive offices, with walnut veneer accents that coordinate with standard executive desk wood finishes | |
| Corporate main lobby waiting spaces | High-traffic rated easy-to-clean seating for building entrance lobbies, with central coffee table to hold reading materials, beverage service and visitor personal items | |
| Government/institutional guest reception areas | Conservative neutral brown and walnut finish suitable for formal official reception spaces, with medium-firm seating that supports upright formal posture |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture - Visitor seating, applicable structural performance standard for static load, stability and durability of all lounge seating units | |
|---|---|---|
| EN 15372:2008 | Furniture - Strength, durability and safety for non-domestic tables, applicable to the coffee table for load capacity and structural stability | |
| EN 1021-1:2014 | Furniture - Assessment of the ignitability of upholstered furniture, Part 1: Ignition source smouldering cigarette, applicable to upholstered seating fire safety |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to the wood veneer components of the seating and coffee table for surface finish, dimensional tolerance and structural stability | |
|---|---|---|
| GB/T 19001-2016 | Quality management system requirement recommendation for production consistency across the upholstered seating and table components in commercial supply | |
| GB 18584-2001 | Indoor decoration and refurbishment materials limit of harmful substances for wooden furniture, applicable to formaldehyde emission limits for MDF and veneer components | |
| GB/T 27904-2011 | Furniture - Upholstered seating for office and public use, applicable to seating structural strength, durability and flame retardant requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to the wood veneer components of the seating and coffee table for surface finish, dimensional tolerance and structural stability; 2. GB/T 19001-2016: Quality management system requirement recommendation for production consistency across the upholstered seating and table components in commercial supply; 3. GB 18584-2001: Indoor decoration and refurbishment materials limit of harmful substances for wooden furniture, applicable to formaldehyde emission limits for MDF and veneer components; 4. GB/T 27904-2011: Furniture - Upholstered seating for office and public use, applicable to seating structural strength, durability and flame retardant requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
