Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2100 × 850 × 820 mm | |
|---|---|---|
| Sofa seat height from floor | 420 mm | |
| Sofa seat depth | 550 mm | |
| Sofa armrest height from seat | 200 mm | |
| Sofa backrest height from seat | 400 mm | |
| Coffee table top thickness | 12 mm | |
| Sofa leg height | 80 mm | |
| Sofa seat cushion thickness | 120 mm | |
| Side table top thickness | 10 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| 3-seater sofa net weight | 75 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seat foam density | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Foam rebound rate | 45% | |
| Recommended total seating capacity | 5 persons | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Sofa upholstery | 1.2mm thick griege PU faux leather | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam with 50mm thick padding layer | |
| Backrest cushion core | High-density polyurethane foam with 40mm thick padding layer | |
| Internal sofa frame | Solid kiln-dried hardwood with 20mm thick structural members | |
| Sofa support legs | 1.5mm thick polished chrome-plated steel with curved decorative foot | |
| Coffee table top | 12mm thick black tempered glass with decorative gold inlay strips | |
| Coffee table frame | 1.2mm thick polished stainless steel square tube frame | |
| Side end table top | 10mm thick black tempered glass with textured inlay section | |
| Sofa seam stitching | High-tenacity polyester thread with 8 stitches per 30mm pitch | |
| Undersofa dust cover | Black non-woven polypropylene fabric | |
| Seat support system | 50mm wide elastic webbing, 80mm spacing across seat frame | |
| Table foot pads | 5mm thick non-slip rubber pads bonded to leg bottoms, floor-protective design |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Tufted seat and back structure | Evenly spaced grid tufting secures foam padding to prevent shifting during long-term use | |
|---|---|---|
| Fixed upholstered armrests | Wide padded armrests integrated with sofa frame for stable arm support without moving parts | |
| Elevated metal leg design | 80mm floor clearance under all seating units allows access for standard vacuum cleaners and robot cleaners | |
| Tempered glass table surface | Smooth non-porous glass surface resists liquid stains and can be wiped clean with standard office cleaning products | |
| Fixed upright seat design | 105° fixed seat-to-back angle supports formal upright postures for professional reception and waiting areas, no recline or tilt mechanisms | |
| Interchangeable modular layout | Three seating units plus two tables can be arranged in L-shape, opposite-facing, or linear layouts to fit different reception room sizes | |
| Gold accent decorative strips | Inlaid gold strips on coffee table top add visual contrast to match formal executive office decor | |
| Flexible modular layout | Three seating units plus two tables can be arranged in linear, L-shaped, or opposite-facing configurations with 300mm minimum walkway clearance between units to fit reception rooms from 12m² to 30m² | |
| Stain-resistant upholstery performance | 1.2mm PU faux leather surface repels water-based spills, allows stain removal within 5 minutes of contact without permanent discoloration | |
| Floor protection design | Rubber foot pads on all sofa and table legs prevent scratching of polished tile, wood, or vinyl office flooring during repositioning | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total number of shipping packages | 6 | |
|---|---|---|
| Largest package (3-seater sofa) dimensions | 2150 x 900 x 650 mm | |
| Total gross shipping weight | 220 kg | |
| Total shipment volume | 2.8 CBM | |
| On-site assembly time | 60 minutes | |
| 40ft HQ container loading quantity | 28 sets | |
| Packaging materials | 5-layer corrugated carton, 20mm thick EPE foam edge protection, plastic stretch wrap | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate executive reception areas | Formal griege color and structured design projects a professional image for visiting clients and business guests | |
|---|---|---|
| Office waiting rooms and lobbies | 5-person total seating capacity accommodates small groups of visitors waiting for meetings | |
| VIP meeting lounge spaces | High-quality faux leather and polished metal finishes create a premium environment for executive discussions | |
| Hotel business center waiting zones | Stain-resistant faux leather and glass surfaces are easy to maintain for high-traffic public use | |
| Recommended matching configuration | Pair with the included rectangular coffee table and side end table to create a complete, coordinated reception set without separate sourcing | |
| Public institution service waiting areas | High-load rated frame and abrasion-resistant upholstery supports continuous use in government or financial service lobby areas, with stable fixed structure for safe public use | |
| Recommended complete configuration | Deploy as a full set with included 3-seater sofa, two armchairs, coffee table and side table to create a coordinated reception group without separate sourcing of matching pieces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture seating strength recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture surface resistance recommendation | EN 12720:2009 | |
| Upholstery fabric durability recommendation | EN 14465:2004 | |
| Furniture stability recommendation | EN 14073:2004 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2 | |
| Formaldehyde emission recommendation | GB 18584 | |
| Furniture fire resistance recommendation | GB 20286 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Tempered glass safety recommendation: GB 15763.2; 3. Formaldehyde emission recommendation: GB 18584; 4. Furniture fire resistance recommendation: GB 20286; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
