Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (3-seater sofa) | 2000 x 850 x 850 mm | |
|---|---|---|
| Seat height (from floor) | 450 mm | |
| Seat depth | 600 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height (from seat surface) | 400 mm | |
| Armrest height (from floor) | 650 mm | |
| Armrest width | 150 mm | |
| Leg height | 80 mm | |
| Tufted grid panel size (seat/back) | 150 x 150 mm | |
| Seat width per single seating position | 600 mm | |
| Clearance under sofa frame (floor to seat rail) | 80 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seater sofa weight | 80 kg | |
|---|---|---|
| Single armchair weight | 35 kg | |
| Seat static load capacity per seat | 150 kg | |
| Recommended total occupants for set | 5 persons | |
| Foam density (seat cushion) | 40 kg/m³ | |
| Foam density (backrest) | 30 kg/m³ | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Frame static load rating | 450 kg | |
| 3-seater sofa unit weight | 80 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery | 1.2 mm thick brown PU (faux) leather, matte finish | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam, wrapped in polyester batting | |
| Backrest core | Medium-density polyurethane foam, tufted with secured buttons | |
| Internal frame | 30 mm x 50 mm kiln-dried solid hardwood frame, corner-blocked and screwed | |
| Armrest structure | Padded foam core wrapped in matching PU leather, solid wood internal support | |
| Support legs | Polished chrome-plated 1.5 mm thick steel, tapered angled design | |
| Seat support platform | 8 mm thick plywood base with 2 mm elastic webbing suspension | |
| Tufting hardware | Hidden metal buttons securing upholstery to back/seat substrate | |
| Frame joint hardware | 50 mm long wood screws and PVA wood glue at all corner joints | |
| Foot pads | 0.5 mm thick nylon floor glides fitted to leg bases | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Modular 3+1+1 set including one 3-seat sofa and two matching single armchairs | |
|---|---|---|
| Stationary fixed design | Non-reclining, non-rotating fixed structure with no moving adjustment mechanisms | |
| Surface cleaning | Wipe-clean PU leather surface resistant to common office beverage spills | |
| Floor protection | Smooth rounded chrome leg base with optional felt pad compatibility to prevent hard floor scratching | |
| Layout flexibility | Freestanding units can be arranged in L-shape, linear, or facing cluster configurations to fit different reception room sizes | |
| Seating set configuration | Fixed 3+1+1 set including one 3-seat sofa and two matching single armchairs | |
| Stationary structural design | Non-reclining, non-rotating, non-rocking fixed structure with no moving adjustment mechanisms | |
| Surface maintenance | Wipe-clean PU leather surface resistant to common office coffee, tea and water spills, cleanable with mild detergent and soft cloth | |
| Layout adaptability | Freestanding separate units can be arranged in U-shape, L-shape, linear, or facing cluster configurations to fit 12 m² to 25 m² reception room sizes | |
| Structural stability | Wide 850 mm depth base and outward angled legs prevent tipping when users apply 25 kg lateral force to backrest top edge | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total packaging pieces per full set | 4 pcs | |
|---|---|---|
| 3-seater sofa carton dimensions | 2050 x 900 x 650 mm | |
| Single armchair carton dimensions | 950 x 900 x 650 mm | |
| Total gross weight per full set | 180 kg | |
| Total shipping volume per full set | 2.3 CBM | |
| Assembly time per full set | 40 minutes | |
| 20ft GP container loading capacity (full sets) | 12 sets | |
| 40ft HQ container loading capacity (full sets) | 28 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate office reception areas | Formal brown leather appearance and durable construction suitable for welcoming visitors in lobbies and waiting areas | |
|---|---|---|
| Executive office lounge spaces | Matching cohesive set design complements executive office interiors for small group informal meetings | |
| Public institution waiting rooms | High-abrasion upholstery and robust frame support high daily foot traffic in government, bank or service center waiting areas | |
| Small business meeting breakout zones | Compact footprint of single chairs allows flexible arrangement in small meeting rooms for casual discussion | |
| Recommended matching furniture | Pairs with black glass-top chrome frame coffee tables and side tables as shown in reference layout for a complete reception furnishing solution | |
| Corporate office lobby reception areas | Formal tan leather appearance and durable construction suitable for daily visitor welcoming in 25 m² office lobbies with 20daily visitors | |
| Executive office inner lounge spaces | Cohesive boxy formal design complements dark wood and chrome executive office interiors for 4person informal meetings | |
| Financial institution customer waiting rooms | 50000 cycle abrasion rating and robust frame support high daily foot traffic in bank, insurance or service center waiting areas |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable standard for domestic and contract seating strength, durability, and stability requirements for EU market procurement | |
|---|---|---|
| EN 1021-1:2014 | Applicable standard for upholstered furniture ignition resistance to smouldering cigarettes for public space use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Applicable standard for lounge and public seating performance, durability, and structural safety for commercial office installations |
|---|
Standards applicable to China-market projects
| GB 20400-2006 | Applicable standard for leather/faux leather upholstery harmful substance limit testing for indoor use | |
|---|---|---|
| GB/T 3324-2017 | Applicable standards and test results require confirmation | |
| GB 20286-2006 | Applicable standards and test results require confirmation |
This product must meet the following technical requirements: 1. GB 20400-2006: Applicable standard for leather/faux leather upholstery harmful substance limit testing for indoor use; 2. GB/T 3324-2017: Applicable standards and test results require confirmation; 3. GB 20286-2006: Applicable standards and test results require confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
