Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2300 × 900 × 850 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Sofa total seating capacity | 3 persons | |
|---|---|---|
| Armchair seating capacity | 1 person per chair | |
| Sofa suggested static load capacity | 300 kg | |
| Sofa net weight reference | 75 kg | |
| Seat foam compression set reference | 35 kg/m3 | |
| Backrest foam density reference | 25 kg/m3 | |
| Seat fabric or leather abrasion acceptance target | 30000 cycles | |
| Recommended user body height | 1900 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Primary upholstery | Caramel leather or leather-look surface covering continuous sofa shells, armchairs, seats and arm pads | |
|---|---|---|
| Seat cushion structure | High-resilience polyurethane foam with padded upholstered surface and sewn cushion divisions | |
| Back cushion structure | Integrated curved padded back with two horizontal cushion zones and tonal seam division | |
| Armrest construction | Soft-padded wraparound arms with stitched face panels and outward-flared front profile | |
| Internal load frame | Hardwood and engineered-board supporting frame with 30 mm nominal structural rail section | |
| Support legs | Four slim matte dark metal legs on each seating unit, with exposed tubular or flat profile |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lounge seating posture | Fixed 100-degree relaxed back angle with 580 mm deep seat for reception and conversation use | |
|---|---|---|
| Set configuration | One three-seat sofa paired with two matching single armchairs for four formal seats | |
| Support and floor contact | Each seating unit rests on four rigid metal legs without wheels, recline hardware or folding joints | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate reception and executive lounge | Use for visitor waiting, informal discussion and executive break areas because the four-seat layout faces a central table zone | |
|---|---|---|
| Premium residential living room or hotel lounge | Suitable for contemporary living rooms, hotel suites and high-end club seating where caramel upholstery and low metal legs are desired |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic furniture durability recommendation | EN 12520:2015 | |
|---|---|---|
| Contract furniture durability recommendation | EN 16139:2013+A1:2021 | |
| Upholstered furniture flammability recommendation | EN 1021:2014 and EN 1021:2014 | |
| Formaldehyde emission recommendation | EN 717:2004 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Seat and back loading recommendation | ANSI/BIFMA X2023 | |
|---|---|---|
| Stability acceptance recommendation | ANSI/BIFMA X2023stability clauses |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstery furniture safety recommendation | GB/T 3324wooden furniture general technical requirements | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18580 | |
| Leather or coated fabric verification recommendation | GB/T 16799furniture-use leather | |
| Fabric and furniture flammability recommendation | GB 17927upholstered furniture anti-destructive ignition specification |
This product must meet the following technical requirements: 1. Upholstery furniture safety recommendation: GB/T 3324wooden furniture general technical requirements; 2. Formaldehyde emission recommendation: GB 18580; 3. Leather or coated fabric verification recommendation: GB/T 16799furniture-use leather; 4. Fabric and furniture flammability recommendation: GB 17927upholstered furniture anti-destructive ignition specification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
