Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2200 x 850 x 750 mm | |
|---|---|---|
| 2-seater sofa overall dimensions | 1800 x 850 x 750 mm | |
| Single armchair overall dimensions | 900 x 850 x 750 mm | |
| Coffee table overall dimensions | 1200 x 800 x 400 mm | |
| Seat height from floor | 420 mm | |
| Seat depth | 580 mm | |
| Backrest height above seat | 330 mm | |
| Armrest height from floor | 620 mm | |
| Metal leg diameter | 20 mm | |
| Coffee table lower shelf clearance | 150 mm | |
| Seat cushion thickness | 120 mm | |
| Individual seat width (3-seater unit) | 680 mm | |
| Seat cushion depth | 580 mm | |
| Armrest width | 120 mm | |
| Coffee table top thickness | 25 mm | |
| Finished Seat Cushion Thickness | 90 mm |
Net weight / load capacity / users / durability
| 3-seater sofa net weight | 75 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Recommended total occupancy for full set | 6 persons | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Seat foam density | 40 kg/m³ | |
| Back foam density | 30 kg/m³ | |
| Floor glide scratch resistance | 10000 cycles of lateral movement without leaving finish marks on polished hard flooring | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Camel-toned polyurethane (faux) leather | |
|---|---|---|
| Seat cushion fill | High-resilience polyurethane foam wrapped in polyester fiber | |
| Back cushion fill | Blown polyester fiber with foam core | |
| Throw arm cushions | Polyester fiber filled, matching upholstery cover | |
| Internal seating frame | Kiln-dried solid hardwood with plywood reinforcement | |
| Seating support legs and underframe | Polished 201 stainless steel, 20mm diameter cylindrical legs with connecting cross frame | |
| Coffee table frame | Polished 201 stainless steel square tube, 30mm profile | |
| Coffee table top and lower shelf | 25mm thick white matte laminate over particleboard core | |
| Seat base support | 8mm thick elastic webbing spaced 80mm apart | |
| Stitching details | Matching color bonded polyester thread, 8 stitches per 30mm seam length | |
| Floor protection | Black plastic glides fitted to base of each metal leg | |
| Integrated arm cushions | Polyester fiber filled, matching upholstery cover, stitched into armrest frame |
Adjustment / rotation / tilt / mobility / storage features
| Modular set configuration | 3-seat sofa, 2-seat sofa, single armchair and matching coffee table | |
|---|---|---|
| Loose cushion design | Separate seat and back cushions are removable for cleaning and rotation | |
| Box arm integrated design | Armrests form a continuous rigid frame with the sofa outer shell, providing wide padded arm support | |
| Integrated lower metal cross frame | Stainless steel underframe connects all legs to improve structural rigidity and prevent frame wobble | |
| Coffee table dual-level storage | Upper top surface for active use, lower open shelf for storage of reading materials or accessories | |
| Fixed seating angle | Seat and back are fixed at a 105-degree relaxed seating angle, no recline mechanism | |
| Floor glide function | Rigid plastic glides prevent scratching hard floors and allow gentle repositioning without lifting full unit | |
| Cushion retention | Integrated hook and loop fasteners at cushion base prevent sliding during normal use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total number of shipping cartons | 6 | |
|---|---|---|
| Largest carton dimensions (3-seater sofa) | 2250 x 900 x 650 mm | |
| Total shipping gross weight for full set | 240 kg | |
| Total shipping volume (CBM) | 3.2 | |
| On-site assembly time for full set | 30 minutes | |
| 20ft GP container loading quantity (full sets) | 8 | |
| 40ft HQ container loading quantity (full sets) | 20 | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate office waiting areas | Provides comfortable, durable seating for visitors and waiting staff, with professional minimalist aesthetic matching modern office interiors | |
|---|---|---|
| Informal meeting breakout zones | Configurable layout supports impromptu small group discussions and casual collaboration away from formal desks | |
| Lobby and reception spaces | Cohesive matching set creates a polished, welcoming first impression for commercial buildings, hotels and serviced offices | |
| High-traffic public spaces | Wipe-clean upholstery and robust metal framing is suited for daily heavy use in public facing environments | |
| Executive lounge spaces | Neutral camel upholstery and polished metal details complement premium executive office environments | |
| Co-working and flexible workspace common areas | Rearrangeable units allow teams to adjust the seating layout to match different group sizes and events | |
| High-traffic public service spaces | Wipe-clean faux leather upholstery and robust metal framing is suited for daily heavy use in government service halls, banking waiting zones and healthcare reception areas | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety for non-domestic seating, applicable load and durability requirements for contract lounge use | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability, required to ensure seating does not tip during normal use | |
| EN 13722:2004 | Furniture - Tables - Test methods for strength and durability, applicable to the matching coffee table | |
| EN 13501-1:2018 | Fire classification of construction products and building elements, applicable to upholstery fire performance for commercial installations |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish quality of the seating frames | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, required for indoor use to control formaldehyde emissions from core materials | |
| GB/T 19001-2016 | Quality management system requirement reference for consistent production quality of commercial grade furniture | |
| GB 20286-2006 | Fire performance requirements for furniture in public places, applicable to upholstery and fill materials for high-traffic installations |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish quality of the seating frames; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, required for indoor use to control formaldehyde emissions from core materials; 3. GB/T 19001-2016: Quality management system requirement reference for consistent production quality of commercial grade furniture; 4. GB 20286-2006: Fire performance requirements for furniture in public places, applicable to upholstery and fill materials for high-traffic installations; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
