| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall footprint dimensions | 1600 x 1600 x 750 mm | |
|---|---|---|
| Single seat unit width | 800 mm | |
| Single seat unit depth | 800 mm | |
| Seat height from floor to cushion top | 420 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height from seat top | 330 mm | |
| Backrest cushion thickness | 80 mm | |
| Armrest width for end units | 150 mm | |
| Armrest height from seat top | 180 mm | |
| Leg height | 50 mm | |
| Intermediate divider cushion width | 120 mm | |
| Clearance under sofa base | 30 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Per-seat static load capacity | 150 kg | |
|---|---|---|
| Total sofa net weight | 75 kg | |
| Seat foam density | 40 kg/m³ | |
| Back foam density | 30 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Metal frame wall thickness | 1.2 mm | |
| Recommended maximum seated users | 3 people | |
| Structural durability cycle rating | 100000 use cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery fabric | Woven polyester fabric in orange, blue and lime green colorways | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam wrapped in polyester batting | |
| Backrest cushion core | Medium-density polyurethane foam | |
| Internal support frame | Powder-coated steel square tube frame | |
| Intermediate divider cushions | Fabric-wrapped foam panels separating individual seating zones | |
| Armrest cushions | Fabric-wrapped high-density foam, integrated with outer backrest panels | |
| Support legs | Polished chrome-plated steel cylindrical legs | |
| Seat base support | Elastic webbing suspension under seat foam | |
| Seam construction | Stitched fabric seams with 8mm stitch pitch | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular connection system | Units connect via underside metal bracket clips to form stable L-shaped configuration, no visible gaps between joined sections | |
|---|---|---|
| Fixed position seating | Non-reclining, non-adjustable fixed seat and back angle for upright lounge posture, 100 degree backrest angle from seat surface | |
| Floor protection design | Each leg fitted with a non-marking plastic glide to prevent scratching hard floor surfaces, adjustable by 5mm to compensate for uneven floors | |
| Layout flexibility | Individual seat units can be reconfigured into straight, U-shaped or alternative L-shaped layouts by adding or removing matching modular units | |
| Fixed upholstery covers | Fabric covers are permanently tailored to the frame, removable only with upholstery tools for deep cleaning | |
| Divider privacy feature | Padded vertical dividers between adjacent seats create semi-private individual seating zones to reduce close contact between users | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 3 | |
|---|---|---|
| Single carton dimensions | 850 x 850 x 650 mm | |
| Total gross shipping weight | 85 kg | |
| Total shipping volume | 1.4 CBM | |
| On-site assembly time | 30 minutes | |
| 40ft HQ container loading quantity | 72 sets | |
| Packaging materials | 5-layer corrugated carton, EPE foam edge protection, plastic shrink wrap, hardware kit included | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Office reception areas | Suitable for corporate lobby and reception zones, multi-tone color adds visual interest while providing comfortable guest seating | |
|---|---|---|
| Open plan office breakout zones | Ideal for informal employee break and collaboration spaces, semi-private dividers support short casual meetings or individual rest | |
| Public waiting areas | Suitable for healthcare clinics, educational institution lobbies and service center waiting spaces, durable fabric and construction withstands medium daily traffic | |
| Small office corner configurations | Fits tight unused corner spaces in small workplaces, maximizing seating capacity without blocking walkways | |
| Co-working common areas | Appropriate for co-working space lounges, providing flexible casual seating for members to work, relax or hold impromptu discussions |
EU Market Access Requirements* EN Standards
| EN 16139 | 2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating: Applicable as acceptance standard for structural performance in public office lounge environments | |
|---|---|---|
| EN 1021-1 | 2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette: Recommended fire safety requirement for public area upholstered seating |
Standards applicable to China-market projects
| GB 20400-2006 Leather and fur - Limit of harmful matter | Applicable for fabric sofas to restrict harmful substance content in upholstery materials for indoor office use | |
|---|---|---|
| GB/T 3324-2017 General technical requirements for wooden furniture | Referenced for structural stability and dimensional tolerance requirements for upholstered seating support structures | |
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable to control formaldehyde emission from any wood-based frame or padding components |
This product must meet the following technical requirements: 1. GB 20400-2006 Leather and fur - Limit of harmful matter: Applicable for fabric sofas to restrict harmful substance content in upholstery materials for indoor office use; 2. GB/T 3324-2017 General technical requirements for wooden furniture: Referenced for structural stability and dimensional tolerance requirements for upholstered seating support structures; 3. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable to control formaldehyde emission from any wood-based frame or padding components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
