Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 1850 x 820 x 780 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 800 x 780 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Seat height from floor (all seating units) | 420 mm | |
| Seat depth (all seating units) | 580 mm | |
| Backrest height from seat surface | 400 mm | |
| Armrest height from floor (all seating units) | 620 mm | |
| Chrome support leg cross-section | 50 x 50 mm | |
| Coffee table lower shelf height | 150 mm | |
| Armrest width (each seating unit) | 80 mm | |
| Coffee table glass thickness | 10 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest cushion thickness | 100 mm | |
| Knee clearance under coffee table | 300 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm |
Net weight / load capacity / users / durability
| 3-seat sofa net weight | 72 kg | |
|---|---|---|
| Per-seat static load capacity (all seating) | 160 kg | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Recommended maximum occupancy (3-seat sofa) | 3 adults | |
| Recommended occupancy (single armchair) | 1 adult per unit | |
| Seat cushion indentation load deflection | 45 kgf | |
| Foam rebound rate | 40 % | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest cushion padding | 45 kg/m³ high-density polyurethane foam | |
|---|---|---|
| Seating upholstery | 1.2 mm thick black polyurethane (PU) faux leather | |
| Seating inner frame | 25 mm thick kiln-dried hardwood composite frame | |
| Seating decorative and support trim | Polished chrome-plated cold-rolled steel | |
| Coffee table support frame | 1.2 mm thick polished chrome-plated square steel tubing | |
| Coffee table shelf surfaces | Tempered black safety glass with polished edges | |
| Seat base support | 8 mm thick elastic webbing suspension | |
| Frame foot pads | Non-marking PVC floor protection glides | |
| Seam stitching | Polyester-bonded thread with 8 mm stitch pitch | |
| Backrest internal support | 4 mm thick hardboard backing panel | |
| Chrome finish layer thickness | 0.08 mm chrome plating over nickel undercoat | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Fixed-position seating design | All seat and backrest angles are pre-set to 105 degree recline for relaxed upright waiting posture, no tilt or recline adjustment mechanisms | |
|---|---|---|
| Two-tier coffee table storage | Top tier supports beverage service and small personal items, lower open shelf provides accessible storage for reading materials, brochures and small office items | |
| Floor protection design | All metal legs include non-marking glides to prevent scuffing and scratching on tile, concrete, wood and commercial carpet flooring | |
| Easy-clean surface performance | Faux leather upholstery and tempered glass surfaces may be wiped clean with standard non-abrasive commercial cleaning products for quick maintenance in high-traffic areas | |
| Modular arrangement flexibility | Seating units are freestanding, allowing custom layout configurations including linear row, L-shape or paired seating to fit different reception area dimensions | |
| Integrated arm support | Wide padded armrests on all seating units provide stable arm support and act as a visual boundary between adjacent seats | |
| Anti-tip structural design | All seating units have a 600 mm wide leg base footprint to prevent tipping when occupants lean against armrests or backrests, meeting commercial furniture stability requirements | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total shipping package count | 5 packages | |
|---|---|---|
| Largest package dimensions (3-seat sofa) | 1880 x 850 x 680 mm | |
| Single armchair package dimensions | 930 x 830 x 680 mm | |
| Coffee table package dimensions (frame + glass) | 1230 x 630 x 180 mm | |
| Total shipping gross weight | 170 kg | |
| Total shipping volume (CBM) | 2.1 CBM | |
| Assembly time for full set | 60 minutes | |
| 40ft HQ container loading quantity (full sets) | 56 sets | |
| 20ft GP container loading quantity (full sets) | 22 sets | |
| Required assembly hardware count | 36 pieces |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for waiting areas outside executive offices, main lobbies and visitor entry zones, providing formal, professional seating for visiting clients and guests | |
|---|---|---|
| Public service waiting spaces | Appropriate for government service halls, bank branch waiting areas and professional service offices, with easy-clean surfaces that withstand regular high-volume public use | |
| Small business meeting lounge zones | Can be used in informal internal meeting areas and breakout spaces for short collaborative discussions and team check-ins | |
| Recommended matching configuration | Pair with the included 2-tier coffee table to create a complete reception set, positioned 300mm from seating edges to allow easy leg room and access to placed items | |
| Flooring compatibility | Suitable for installation on hard commercial flooring including polished concrete, tile, laminate and low-pile office carpet, with integrated floor glides preventing surface damage | |
| Healthcare facility waiting annexes | Suitable for non-clinical waiting areas in dental offices, clinics and medical centers, with non-porous surfaces compatible with hospital-grade disinfection wipes | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office furniture structural strength recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture surface fire resistance recommendation | EN 1021:2014 | |
| Tempered glass furniture recommendation | EN 12150:2015 | |
| Surface durability recommendation | EN 14465 |
US and Canada office-furniture standards
| Lounge seating durability recommendation | ANSI/BIFMA X2020 | |
|---|---|---|
| Occasional table performance recommendation | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Tempered glass safety recommendation | GB 15763.2 | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18584 | |
| Upholstered furniture fire safety recommendation | GB 20286 | |
| Hardware corrosion resistance recommendation | GB/T 3325 |
This product must meet the following technical requirements: 1. Tempered glass safety recommendation: GB 15763.2; 2. Formaldehyde emission recommendation: GB 18584; 3. Upholstered furniture fire safety recommendation: GB 20286; 4. Hardware corrosion resistance recommendation: GB/T 3325; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
