Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 1800 x 750 x 780 mm | |
|---|---|---|
| Single armless armchair overall dimensions | 720 x 700 x 780 mm | |
| Coffee table overall dimensions | 1200 x 650 x 450 mm | |
| Side end table overall dimensions | 600 x 600 x 500 mm | |
| Seating seat height from floor | 420 mm | |
| Seating seat depth | 580 mm | |
| Seating backrest height | 380 mm | |
| Coffee table lower shelf clearance | 220 mm | |
| Wooden leg height for seating | 150 mm | |
| Table frame leg cross-section | 50 x 50 mm | |
| Tempered glass tabletop thickness | 10 mm | |
| Single seating seat width | 650 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| 3-seat sofa total static load capacity | 450 kg | |
|---|---|---|
| Seating set total net weight | 115 kg | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Foam compression set resistance | 35 kg/m³ density, 40% rebound | |
| Upholstery fabric Martindale abrasion resistance | 50000 cycles | |
| Seat foam compression set resistance | ≤10% after 50000 compression cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | Teal polyester woven fabric | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam, 80mm thick | |
| Backrest core | Medium-density polyurethane foam, 60mm thick | |
| Seating internal frame | 18mm thick plywood frame with hardwood bracing | |
| Seating legs | Solid natural beech wood, tapered cylindrical profile, clear matte lacquer finish | |
| Table tabletop and shelves | 10mm thick tempered black safety glass, polished rounded edges | |
| Table support frame | Polished chrome-plated square steel tube, 50x50mm cross-section, 1.2mm wall thickness | |
| Table foot pads | Non-marking PE plastic floor glides | |
| Seating upholstery fabric | Solution-dyed teal polyester woven fabric, 350g/m² weight, matte finish | |
| Backrest cushion core | 60mm thick 35kg/m³ medium-density polyurethane foam | |
| Seating internal support frame | 18mm thick hardwood plywood frame, reinforced with solid wood corner bracing, glued and stapled construction | |
| Seating support legs | Solid natural beech wood, tapered cylindrical profile, clear matte lacquer finish, 50mm top diameter |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed non-modular layout, no recline or tilt mechanisms | |
|---|---|---|
| Armless seating design | No integrated armrests, allowing flexible side-by-side placement and accessible entry from either seat side | |
| Coffee table dual-tier storage | Upper tabletop for refreshments and active use, lower black glass shelf for concealed magazine and book storage | |
| Side table dual-tier storage | Upper glass top for display items, lower open shelf for small office accessories | |
| Floor protection | All legs fitted with non-slip non-marking glides, suitable for tile, concrete and polished stone commercial flooring | |
| Upholstery maintenance | Stain-repellent fabric finish allows spot cleaning with water-based upholstery cleaners | |
| Seating unit functionality | Fixed non-reclining, non-tilting static construction, no movable mechanisms | |
| Armless seating accessibility | No integrated armrests, allowing entry/exit from either side of each seat, and flexible adjacent placement for extra seating capacity during high visitor volume | |
| Floor protection performance | All seating and table legs fitted with non-slip non-marking PE glides, suitable for use on tile, polished concrete, terrazzo and stone commercial flooring | |
| Upholstery maintenance feature | Stain-repellent fabric finish allows spot cleaning with neutral water-based upholstery cleaners, no dry cleaning required for routine spills | |
| Table glass stability | White circular anti-slip silicone suction pads fitted at all glass-to-frame contact points, preventing glass slippage under normal use loads | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Total packaged units | 5 cartons | |
|---|---|---|
| 3-seat sofa carton dimensions | 1850 x 800 x 350 mm | |
| Single armchair carton dimensions (per unit) | 770 x 750 x 300 mm | |
| Coffee table carton dimensions | 1250 x 700 x 150 mm | |
| Side table carton dimensions | 650 x 650 x 120 mm | |
| Total shipment gross weight | 140 kg | |
| Total shipment CBM | 1.3 cbm | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 42 sets | |
| 40ft HQ container loading quantity | 105 sets |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for welcoming visitors in high-rise office lobbies, with coordinated seating and table set for guest waiting | |
|---|---|---|
| Co-working breakout zones | Armless design allows flexible seating arrangements for informal meetings and casual work breaks | |
| Small business waiting rooms | Compact footprint fits small reception spaces for medical offices, legal practices or service centers | |
| Public institution visitor areas | Stain-resistant fabric and easy-clean glass surfaces suit high-footfall public sector waiting spaces | |
| Executive office informal meeting zones | Coordinated set provides dedicated seating for short meetings and guest visits in private office spaces | |
| Hotel business lounge areas | Contemporary minimalist design fits modern hotel business centers for guest use | |
| Corporate headquarters reception lobbies | Suitable for guest waiting areas in high-rise corporate offices, providing coordinated seating and table surfaces for refreshments and reading materials; modern minimalist design matches contemporary commercial interior aesthetics visible in the render | |
| Co-working space breakout zones | Armless flexible design supports impromptu small group discussions and casual work breaks, with low-back profile that does not block open-plan sightlines; durable fabric withstands daily use by rotating members |
EU Market Access Requirements* EN Standards
| Office seating safety recommendation | EN 16139:2013 | |
|---|---|---|
| Glass in furniture safety recommendation | EN 12150:2015 | |
| Furniture surface durability recommendation | EN 15185:2011 | |
| Contract non-domestic seating safety recommendation | EN 16139:2013 | |
| Toughened glass for furniture safety recommendation | EN 12150:2015 | |
| Furniture surface abrasion resistance recommendation | EN 15185:2011 |
US and Canada office-furniture standards
| Lounge seating performance recommendation | ANSI/BIFMA X2022 | |
|---|---|---|
| Occasional tables performance recommendation | ANSI/BIFMA X2021 |
Standards applicable to China-market projects
| Furniture structural safety recommendation | GB/T 3324 | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2 | |
| Upholstered furniture flammability recommendation | GB 20286 | |
| Furniture hardware durability recommendation | GB/T 17657 | |
| Upholstered furniture structural safety recommendation | GB/T 3324 | |
| Tempered glass for furniture safety recommendation | GB 15763.2 |
This product must meet the following technical requirements: 1. Furniture structural safety recommendation: GB/T 3324; 2. Tempered glass safety recommendation: GB 15763.2; 3. Upholstered furniture flammability recommendation: GB 20286; 4. Furniture hardware durability recommendation: GB/T 17657; 5. Upholstered furniture structural safety recommendation: GB/T 3324; 6. Tempered glass for furniture safety recommendation: GB 15763.2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
