Automatic mm / inch conversion · Core engineering specifications
| 3-seater waiting bench overall dimensions | 1800 x 680 x 900 mm | |
|---|---|---|
| Single guest armchair overall dimensions | 680 x 680 x 900 mm | |
| Seat height from floor for all seating units | 420 mm | |
| Seat depth for all seating units | 480 mm | |
| Backrest height above seat surface for seating | 480 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Armrest height above seat surface for seating | 200 mm | |
| Chrome frame tube diameter for seating | 32 mm | |
| Lower coffee table shelf clearance above floor | 100 mm | |
| Seat width per individual seat on 3-seater bench | 580 mm | |
| Coffee table lower shelf usable dimensions | 1100 x 500 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 85 kg | |
|---|---|---|
| Static load capacity per seating position | 150 kg | |
| Recommended maximum continuous occupancy duration | 4 hours | |
| Total seating capacity per set | 5 people | |
| Seating frame static overload test threshold | 300 kg per seat | |
| Standard commercial warranty for frame components | 3 years | |
| Maximum continuous recommended occupancy duration | 4 hours | |
| Frame component warranty period | 3 years | |
| Upholstery abrasion resistance rating | 50000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | 1.0mm thick black PVC faux leather, stitched vertical channel contoured panels | |
|---|---|---|
| Seating frame structure | 1.2mm wall thickness polished chrome-plated cold-rolled steel tubing, welded cantilever leg design | |
| Armrest pads | Curved wood-look (solid wood veneer or high-impact PVC) caps mounted to steel arm supports | |
| Coffee table top surface | 8mm thick black tempered glass with textured printed black finish | |
| Coffee table lower shelf | 15mm thick black particleboard with matte melamine laminate finish | |
| Coffee table frame | 25mm diameter polished chrome-plated steel tubing, rounded corner U-leg design with cross supports | |
| Seat cushion core | 40mm thick high-resilience polyurethane foam, density 35kg/m³ | |
| Backrest cushion core | 30mm thick polyurethane foam, density 30kg/m³ | |
| Frame surface treatment | Multi-layer chrome plating over rust-inhibitive primer | |
| Floor contact glides | Injection-molded PP plastic glides recessed into leg bottoms | |
| Seam construction | 9mm stitch pitch bonded nylon thread, seam allowances finished to prevent fraying | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating support design | Fixed cantilever steel frame provides gentle flex when seated, no recline or adjustment mechanisms | |
|---|---|---|
| Per-seat privacy separation | Vertical upholstered dividers between each bench seat prevent side contact between adjacent users | |
| Armrest support | Curved padded armrests on both sides of every seat position to assist standing entry and exit | |
| Coffee table storage | Two-tier open design provides upper surface for serving and display, lower open shelf for magazine and accessory storage | |
| Floor protection | Recessed plastic glide feet on all frame leg bottoms prevent scratching of hard floor surfaces | |
| Set layout flexibility | Single armchairs can be positioned independently flanking the bench or rearranged to suit different reception room shapes | |
| Cleaning access | Smooth non-porous upholstery and polished metal frames allow wipe-down cleaning between users without disassembly | |
| Set stability | Splayed cantilever leg geometry creates a 680mm wide stance per seating unit, preventing tip-over when users lean to one side or push up from armrests | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons per complete set | 4 cartons | |
|---|---|---|
| Largest carton dimensions (three-seater bench) | 1850 x 730 x 380 mm | |
| Total shipping gross weight per set | 100 kg | |
| Total shipping volume per set | 0.65 CBM | |
| Required assembly time per complete set | 60 minutes | |
| 20ft GP container loading quantity for full sets | 42 sets | |
| Packaging material specification | 5-layer corrugated carton with 20mm EPS foam edge protection, PE wrap for upholstered components | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate office reception lobbies | Formal black and chrome aesthetic matches professional business environments, 5-person capacity accommodates visiting clients and guests | |
|---|---|---|
| Public waiting areas for service centers | Durable fixed steel frame and wipe-clean surfaces withstand high daily traffic in government offices, bank branches and medical admin waiting rooms | |
| Small meeting breakout spaces | Matching chair and table set provides a compact conversational grouping for informal internal meetings or candidate interview waiting | |
| Hotel concierge or guest waiting zones | Neutral color palette and polished metal finish complements modern hotel lobby decor without clashing with existing interior design | |
| Recommended placement layout | Position three-seater bench against the rear wall, place single armchairs opposite flanking the coffee table to create a face-to-face conversation area | |
| Public service center waiting areas | Durable fixed steel frame and wipe-clean surfaces withstand 200+ daily user cycles in bank branches, government service halls and medical administrative waiting rooms | |
| Small meeting breakout zones | Matching chair and table set creates a compact conversational grouping for informal internal discussions or pre-meeting guest waiting | |
| Hotel concierge guest waiting areas | Neutral black and polished chrome finish complements modern hotel lobby decor without clashing with existing interior design |
EU Market Access Requirements* EN Standards
| Applicable office furniture stability standard | EN 16139:2013 Seating for non-domestic use - Strength, durability and stability | |
|---|---|---|
| Applicable surface finish standard | EN 12720:2009 Furniture - Assessment of surface resistance to cold liquids | |
| Applicable table safety standard | EN 15372:2016 Tables for non-domestic use - Strength, durability and stability | |
| Non-domestic seating strength and stability | EN 16139:2013 Seating for non-domestic use - Strength, durability and stability | |
| Furniture surface cold liquid resistance | EN 12720:2009 Furniture - Assessment of surface resistance to cold liquids | |
| Non-domestic table strength and stability | EN 15372:2016 Tables for non-domestic use - Strength, durability and stability |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Applicable safety standard for metal frame public seating | GB/T 3324General technical requirements for metal furniture | |
|---|---|---|
| Applicable upholstery performance standard | GB/T 16799Furniture leather | |
| Applicable tempered glass safety standard | GB 15763.2Safety glazing materials in building - Part 2: Tempered glass | |
| Metal furniture general technical requirement | GB/T 3324General technical requirements for metal furniture | |
| Furniture upholstery leather performance | GB/T 16799Furniture leather | |
| Tempered glass safety specification | GB 15763.2Safety glazing materials in building - Part 2: Tempered glass |
This product must meet the following technical requirements: 1. Applicable safety standard for metal frame public seating: GB/T 3324General technical requirements for metal furniture; 2. Applicable upholstery performance standard: GB/T 16799Furniture leather; 3. Applicable tempered glass safety standard: GB 15763.2Safety glazing materials in building - Part 2: Tempered glass; 4. Metal furniture general technical requirement: GB/T 3324General technical requirements for metal furniture; 5. Furniture upholstery leather performance: GB/T 16799Furniture leather; 6. Tempered glass safety specification: GB 15763.2Safety glazing materials in building - Part 2: Tempered glass; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
