Automatic mm / inch conversion · Core engineering specifications
| Overall set layout dimensions | 3200 x 2500 x 850 mm | |
|---|---|---|
| 3-seater sofa overall dimensions | 1800 x 750 x 850 mm | |
| Single armchair overall dimensions | 650 x 700 x 850 mm | |
| Coffee table overall dimensions | 1200 x 700 x 450 mm | |
| Seat height (sofa and chairs) | 450 mm | |
| Seat depth (all seating) | 500 mm | |
| Backrest height (all seating) | 450 mm | |
| Armrest height above seat | 220 mm | |
| Cantilever frame base footprint | 600 mm front-to-back | |
| Coffee table lower shelf height | 150 mm | |
| Coffee table glass top thickness | 12 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest padding thickness | 40 mm | |
| Seam stitch pitch | 8 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Lumbar Support Zone Height | 240 mm |
Net weight / load capacity / users / durability
| Total set net weight | 145 kg | |
|---|---|---|
| Single chair static load capacity | 150 kg | |
| Seating upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat foam density | 40 kg/m³ | |
| Frame static load cycle rating | 100000 load cycles | |
| Applicable number of seated users | 5 people | |
| Seat foam rebound rate | 45% | |
| Back foam density | 30 kg/m³ | |
| Floor glide abrasion durability | 25000 sliding cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Black PU faux leather, 1.2mm thickness | |
|---|---|---|
| Seat core padding | High-density polyurethane foam, 60mm thickness | |
| Backrest padding | Medium-density polyurethane foam, 40mm thickness | |
| Seating frame and armrests | 1.8mm thick cold-rolled steel tube, matte black powder-coated finish | |
| Armrest pads | Integral wrapped PU padding matching seat upholstery | |
| Coffee table top and lower shelf | 12mm thick tempered black glass, polished edges | |
| Coffee table support frame | 1.5mm thick chrome-plated square steel tube | |
| Frame foot pads | Non-slip plastic floor glides | |
| Seating internal support board | 12mm thick high-density particleboard, moisture-resistant treatment | |
| Seating frame and armrest supports | 1.8mm thick cold-rolled steel tube, matte black powder-coated finish | |
| Armrest top pads | Integral wrapped PU padding matching seat upholstery, 10mm padding thickness | |
| Frame connecting hardware | Zinc-plated steel bolts and locking nuts, corrosion-resistant coating |
Adjustment / rotation / tilt / mobility / storage features
| Cantilever frame flex | Controlled 10-degree backward flex under seated load without adjustment levers | |
|---|---|---|
| Integrated armrest support | Fixed padded armrests aligned to 220mm above seat for elbow support | |
| Coffee table open storage | Fixed lower black glass shelf for storage of reading materials or refreshments | |
| Floor protection | Non-marking plastic glides on all frame feet to prevent scratching hard flooring | |
| Seating configuration flexibility | Single chairs can be repositioned independently around the sofa and table | |
| Table surface function | Smooth non-porous glass top suitable for serving drinks and displaying reception materials | |
| Assembly requirement | Partial assembly required for attaching seat/back units to frames and connecting table frame components | |
| Frame stability | Cantilever frame design with 600mm front-to-back footprint prevents tipping under 150kg static load applied 50mm from front seat edge | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total number of shipping cartons | 5 cartons | |
|---|---|---|
| Largest carton dimensions (3-seater sofa) | 1850 x 780 x 350 mm | |
| Single chair carton dimensions | 680 x 720 x 200 mm | |
| Coffee table carton dimensions | 1250 x 750 x 150 mm | |
| Total shipment gross weight | 170 kg | |
| Total shipment CBM | 0.72 m³ | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 32 sets | |
| Per-carton hardware kit | 1 kit per seating/table unit, including assembly tools and illustrated instruction manual | |
| 40ft HQ container loading quantity | 78 sets |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for waiting areas and visitor lobbies, formal black finish matches professional commercial interiors | |
|---|---|---|
| Executive office meeting zones | Suitable for small informal meeting spaces outside executive suites, accommodates up to 5 visitors | |
| Public institution waiting rooms | Suitable for government, bank or service center waiting areas, durable construction meets high-traffic requirements | |
| Small business meeting rooms | Suitable for compact meeting spaces where informal seating is preferred around a central table | |
| Recommended maintenance | Wipe clean faux leather and glass surfaces with mild detergent, suitable for daily high-use environments | |
| Temporary visitor briefing spaces | Suitable for factory or site office visitor briefing areas, scratch-resistant glides work with concrete, tile or vinyl commercial flooring without surface damage | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office seating safety recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture glass safety recommendation | EN 12150:2015 | |
| Furniture surface emission recommendation | EN 16516:2017 |
US and Canada office-furniture standards
| Lounge seating performance recommendation | ANSI/BIFMA X2020 |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2 | |
| Furniture mechanical performance recommendation | GB/T 3324 | |
| Upholstery leather performance recommendation | GB/T 16799 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Tempered glass safety recommendation: GB 15763.2; 3. Furniture mechanical performance recommendation: GB/T 3324; 4. Upholstery leather performance recommendation: GB/T 16799; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
