Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2000 x 850 x 750 mm | |
|---|---|---|
| Single armchair overall dimensions | 850 x 800 x 750 mm | |
| Ottoman overall dimensions | 450 x 450 x 400 mm | |
| Large coffee table dimensions | 1200 x 600 x 450 mm | |
| Small coffee table dimensions | 800 x 600 x 450 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (usable) | 550 mm | |
| Armrest height from floor | 600 mm | |
| Backrest height above seat | 330 mm | |
| Tempered glass table top thickness | 12 mm | |
| Lower shelf height from floor (coffee tables) | 150 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest cushion thickness | 80 mm | |
| Armrest width | 120 mm | |
| Coffee table leg diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm |
Net weight / load capacity / users / durability
| 3-seater sofa net weight | 75 kg | |
|---|---|---|
| 3-seater sofa static load capacity | 450 kg | |
| Set total seating capacity | 5 people | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Foam density (seat cushions) | 40 kg/m³ | |
| Foam indentation load deflection | 38 kPa | |
| Seam stitching durability | 200 N seam strength | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa/armchair upholstery | Smooth faux leather (PU leather) in black, tan and orange color options | |
|---|---|---|
| Seat and back padding | High-density polyurethane foam | |
| Seating internal frame | Solid kiln-dried hardwood + plywood composite | |
| Seating support legs | Polished chrome-plated tapered metal legs | |
| Coffee table table tops | Black tempered safety glass with polished edges | |
| Coffee table support frames | Polished chrome-plated square metal tube legs | |
| Coffee table lower shelf | Black frosted tempered glass | |
| Ottoman upholstery | Black faux leather matching sofa upholstery | |
| Ottoman base and feet | Small chrome-plated metal glide feet | |
| Seat support system | 3.2mm diameter no-sag sinuous spring support spaced 100mm apart under seat foam | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed modular reception set with 1 three-seat sofa, 4 single armchairs, 2 coffee tables and 2 ottomans | |
|---|---|---|
| Seat support | Fixed no-sag spring support under seat foam | |
| Coffee table storage | Integrated lower glass shelf for magazine, document and small item storage | |
| Floor protection | All seating and table legs include non-marking glide feet to prevent carpet and hard floor scratching | |
| Color customization | Available in black, warm tan and bright orange upholstery to match office decor | |
| Cleaning suitability | Smooth non-porous upholstery surface allows wipe-clean maintenance for high-traffic public areas | |
| Arrangement flexibility | Separate standalone units allow reconfiguration to fit different reception room layouts | |
| Temporary extra seating | 2 cube ottomans support 120kg static load for temporary guest seating during peak visitor periods, or use as footrests for seated guests | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total number of packages | 9 packages | |
|---|---|---|
| 3-seater sofa carton dimensions | 2050 x 900 x 650 mm | |
| Single armchair carton dimensions | 900 x 850 x 650 mm | |
| Coffee table carton dimensions | 1250 x 650 x 120 mm | |
| Ottoman carton dimensions | 500 x 500 x 450 mm | |
| Total shipment gross weight | 240 kg | |
| Total shipment volume | 2.8 CBM | |
| Assembly time | 60 minutes | |
| 40ft HQ container loading quantity | 42 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for visitor waiting spaces in office lobbies, providing formal, durable guest seating with coordinated table surfaces for drinks and reading materials | |
|---|---|---|
| Executive meeting lounge spaces | Appropriate for small informal meeting areas outside boardrooms, supporting casual discussions between staff and visiting clients | |
| High-traffic public service areas | Suitable for bank, government and service centre waiting zones, with wipe-clean upholstery that resists wear from frequent daily use | |
| Small office break rooms | Usable as casual lounge seating in staff break areas, with ottomans providing flexible footrest or extra temporary seating for peak use | |
| Recommended configuration | Pair with matching area carpets and side potted plants to create a polished, welcoming professional entrance space | |
| Customer waiting areas in retail/medical offices | Suitable for clinic, auto dealership and retail customer waiting spaces, with disinfectant-safe upholstery meeting public space hygiene requirements | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office seating safety recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture glass safety recommendation | EN 12150:2015 | |
| Upholstered furniture flammability recommendation | EN 1021:2014 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2 | |
| Formaldehyde emission recommendation | GB 18580 | |
| Furniture durability recommendation | GB/T 3324 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Tempered glass safety recommendation: GB 15763.2; 3. Formaldehyde emission recommendation: GB 18580; 4. Furniture durability recommendation: GB/T 3324; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
