Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 1900 x 800 x 750 mm | |
|---|---|---|
| Single armchair overall dimensions | 850 x 780 x 720 mm | |
| Seat height (all seating units) | 420 mm | |
| Seat depth (all seating units) | 550 mm | |
| Backrest height (all seating units) | 380 mm | |
| Armrest height (all seating units) | 620 mm | |
| Cantilever steel leg section | 30 x 30 mm square tube | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Coffee table wood top thickness | 25 mm | |
| Coffee table acrylic leg section | 50 x 50 mm clear acrylic square posts | |
| Coffee table lower shelf dimensions | 1100 x 500 mm | |
| Arm width (all seating units) | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Seating static load capacity per seat | 150 kg | |
|---|---|---|
| Total seating weight capacity (entire set) | 750 kg | |
| Seating foam density | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Foam indentation load deflection | 45 N | |
| Total net weight (full 4-piece set) | 165 kg | |
| Seating durability cycle rating | 50000 cycles | |
| Cantilever frame static load test | 500 kg per unit | |
| Total seating weight capacity (full set) | 750 kg | |
| Seat cushion foam density | 40 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 0.8mm thick beige polyurethane faux leather | |
|---|---|---|
| Seat cushion core | 120mm thick high-resilience polyurethane foam | |
| Back cushion core | 80mm thick medium-density polyurethane foam | |
| Internal seating frame | 20mm x 40mm rectangular steel tube, 1.2mm wall thickness | |
| Seating support legs | Polished chrome-plated cantilever steel frames | |
| Coffee table tabletop | 18mm MDF core with walnut wood veneer top and 2mm ABS edge banding | |
| Coffee table vertical supports | 50mm x 50mm clear cast acrylic posts | |
| Coffee table lower shelf | 10mm thick polished 304 stainless steel plate | |
| Decorative side table (adjacent) | 25mm square polished chrome frame with walnut veneer top | |
| Upholstery stitching | High-strength bonded nylon thread, matched beige color | |
| Floor glides | Injection-molded nylon non-marking glides | |
| Coffee/side table tabletop | 25mm MDF core with walnut wood veneer top and 2mm ABS edge banding |
Adjustment / rotation / tilt / mobility / storage features
| Cantilever seating flex | Sled base provides 10mm controlled vertical flex when seated | |
|---|---|---|
| Fixed non-reclining structure | All backrests fixed at 105-degree upright angle | |
| Coffee table dual-surface storage | Top surface for active beverage and reading material placement, lower steel shelf for magazine and accessory storage | |
| Modular seating arrangement | 3-seater sofa and two single armchairs can be arranged in U-shape, L-shape, or linear configurations | |
| Stain-resistant upholstery maintenance | Smooth faux leather surface can be wiped clean with mild detergent and soft cloth | |
| Floor protection | Nylon glides on all frame bases prevent scuffing and scratching on polished tile, hardwood, or vinyl commercial flooring | |
| Seat ergonomic support | Angled integrated armrests provide elbow support at natural seated height, mid-back contour supports lumbar region during waits | |
| Cantilever seating flex response | Sled base provides 12mm controlled vertical flex when seated | |
| Fixed backrest structure | All backrests fixed at 105-degree upright angle | |
| Floor protection performance | Nylon glides on all frame bases prevent scuffing and scratching on polished commercial flooring | |
| Ergonomic guest support | Angled integrated armrests provide elbow support at natural seated height, mid-back contour supports lumbar region during waits | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 5 cartons | |
|---|---|---|
| Largest carton dimensions (3-seater sofa) | 1950 x 850 x 650 mm | |
| Single armchair carton dimensions | 900 x 830 x 620 mm | |
| Coffee table flat-pack carton dimensions | 1250 x 650 x 150 mm | |
| Total gross shipping weight | 195 kg | |
| Total shipping volume (CBM) | 2.2 CBM | |
| On-site assembly time | 45 minutes | |
| 20ft GP container loading capacity | 18 sets | |
| 40ft HQ container loading capacity | 45 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | U-shaped configuration fits standard waiting lobbies, accommodates 5 waiting guests with central coffee table for reading materials and refreshments | |
|---|---|---|
| Auto dealership customer lounges | Durable commercial-grade upholstery resists frequent use, cantilever frames hold up to high daily foot traffic, polished finish matches showroom aesthetic | |
| Bank and financial service waiting zones | Fixed non-adjustable seating reduces maintenance and vandalism risk, easy-to-clean surface handles high-turnover visitor use, formal angular design conveys professional atmosphere | |
| Medical clinic waiting rooms | Stain-resistant upholstery allows quick sanitization between patients, wide armrests assist elderly or mobility-impaired guests when standing, no moving parts reduce breakdown risk | |
| Hotel lobby lounge areas | Modular units can be grouped into multiple seating clusters for large lobbies, chrome and acrylic details match contemporary hotel interior design, neutral beige coordinates with multiple accent color schemes | |
| Corporate office reception lobbies | U-shaped configuration fits standard 25sqm waiting areas, accommodates 5 waiting guests with central coffee table for reading materials and refreshments | |
| Mid-range hotel lobby lounge areas | Modular units can be grouped into multiple seating clusters for large lobbies, chrome and acrylic details match contemporary hotel interior design, neutral camel coordinates with multiple accent color schemes | |
| Premium co-working space welcome areas | Low-maintenance surface reduces janitorial workload, modular arrangement allows reconfiguration for small events, polished appearance creates professional first impression for visiting clients |
EU Market Access Requirements* EN Standards
| EN 13759:2012 Furniture - Seating - Test methods for the determination of strength and durability | Applicable for commercial reception seating, requires 50000 cycle durability test without structural failure | |
|---|---|---|
| EN 1022:2018 Furniture - Seating - Determination of stability | Applicable to cantilever seating units, requires no tipping when 600N horizontal force applied to backrest top edge | |
| EN 15372:2008 Furniture - Strength, durability and safety - Requirements for non-domestic tables | Applicable to coffee table and side table, requires 50kg vertical static load test on table top without structural failure |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 Lounge Seating | Applicable commercial lounge seating standard, requires 136kg static load test per seat, 102kg cyclic load test over 100000 cycles |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable to the coffee table wood veneer top and structural wood components, requires edge bonding strength ≥0.8MPa, formaldehyde emission ≤0.124mg/m³ for E1 grade | |
|---|---|---|
| GB/T 19001-2016 Quality management systems | Applicable for production quality control of upholstered seating, consistent dimensional tolerance ±2mm across all units in a set | |
| GB 20400-2006 Leather and fur - Limits of harmful matter | Applicable to faux leather upholstery, requires lead content ≤90mg/kg, cadmium content ≤75mg/kg, no detectable AZO colorants | |
| GB/T 27717-2011 General technical requirements for furniture for public waiting areas | Applicable to all upholstered seating units, requires stability under 600N horizontal backrest force, no sharp exposed edges |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable to the coffee table wood veneer top and structural wood components, requires edge bonding strength ≥0.8MPa, formaldehyde emission ≤0.124mg/m³ for E1 grade; 2. GB/T 19001-2016 Quality management systems: Applicable for production quality control of upholstered seating, consistent dimensional tolerance ±2mm across all units in a set; 3. GB 20400-2006 Leather and fur - Limits of harmful matter: Applicable to faux leather upholstery, requires lead content ≤90mg/kg, cadmium content ≤75mg/kg, no detectable AZO colorants; 4. GB/T 27717-2011 General technical requirements for furniture for public waiting areas: Applicable to all upholstered seating units, requires stability under 600N horizontal backrest force, no sharp exposed edges; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
