Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seat sofa dimensions | 2200 x 900 x 900 mm | |
|---|---|---|
| Standard armchair dimensions | 950 x 900 x 900 mm | |
| Chaise lounge dimensions | 1700 x 850 x 900 mm | |
| Rectangular coffee table dimensions | 1300 x 700 x 450 mm | |
| Square side end table dimensions | 600 x 600 x 550 mm | |
| Seat height from floor | 420 mm | |
| Seat cushion depth | 550 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height above seat | 480 mm | |
| Armrest height above seat | 180 mm | |
| Coffee table lower shelf clearance | 200 mm | |
| Chrome support leg diameter for seating | 50 mm | |
| Table frame tube cross-section | 40 x 40 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set net weight range | 185 kg | |
|---|---|---|
| 3-seat sofa static seat load capacity | 450 kg | |
| Recommended maximum occupancy | 5 people | |
| Foam cushion indentation load deflection | 40 kg/m³ | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Frame static load cycle rating | 25000 use cycles | |
| Recommended warranty period for procurement | 2 years | |
| Total set maximum occupancy | 5 people | |
| Seat foam density | 40 kg/m³ | |
| Upholstery abrasion resistance | 35000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | Dark brown polyurethane (faux) leather, 1.0mm thickness, matte grain finish | |
|---|---|---|
| Seat core filling | 40 kg/m³ high-density polyurethane foam, wrapped with 20mm soft polyester fiber batting | |
| Backrest filling | 30 kg/m³ medium-density polyurethane foam with fiber wrap | |
| Seating internal frame | 25mm thick kiln-dried hardwood frame with reinforced corner blocks | |
| Seating support system | 4mm thick sinuous steel spring suspension with 50mm spacing across seat base | |
| Seating support legs | Polished chrome-plated steel tubular legs with two-tone black base caps, 1.2mm wall thickness | |
| Table frame construction | Polished chrome-plated square steel tube frames, 1.5mm wall thickness, welded corner joints | |
| Table surfaces | 10mm thick tempered black safety glass, polished flat edges, reflective glossy finish | |
| Table hardware | Stainless steel glass mounting clamps with rubber gaskets to prevent glass scratching | |
| Stitching details | Matching dark brown bonded nylon thread, contrast light stitch accent along panel seams | |
| Armrest structure | Padded arm frames integrated with main seat frame, covered in matching brown faux leather | |
| Upholstery stitching | Matching dark brown bonded nylon thread, 8 stitches per 30mm pitch, reinforced stress points at seat and arm junctions |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed position non-reclining seating with pre-angled backrests at 105 degrees for relaxed upright sitting | |
|---|---|---|
| Coffee table storage | Two-tier open glass shelving providing upper surface for drinks and decor, lower shelf for books, media and accessory storage | |
| Side table storage | Two-tier open glass shelving providing side placement for beverages, table lamps and small decor items adjacent to seating | |
| Floor protection | Non-marking black plastic foot caps on all seating and table legs to prevent scratching hard flooring surfaces | |
| Chaise function | Extended seat length to support full leg recline without separate ottoman, designed for relaxed lounging | |
| Upholstery maintenance | Smooth non-porous faux leather surface allows wipe-clean maintenance with damp cloth for spill removal | |
| Assembly requirement | Knock-down construction requiring leg attachment to seating pieces and frame assembly for glass tables, no specialized tools required | |
| Arrangement flexibility | Freestanding individual pieces allow modular rearrangement of sofa, armchair, chaise and tables to fit different living room layouts | |
| Seating comfort geometry | Fixed position non-reclining seating with pre-angled backrests set at 105 degrees for relaxed upright sitting, no visible recline or adjustment mechanisms | |
| Chaise lounger function | Extended 1700mm seat length to support full leg recline without separate ottoman, designed for single-user relaxed lounging | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 7 cartons | |
|---|---|---|
| Largest carton dimensions (3-seat sofa frame) | 2250 x 750 x 650 mm | |
| Total shipping gross weight | 210 kg | |
| Total shipping volume (CBM) | 2.6 cbm | |
| on-site assembly time | 60 minutes for two adults using standard household tools | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 45 sets | |
| Packaging protection | 5-layer corrugated cardboard cartons with 20mm EPS foam corner protection, plastic shrink wrap on upholstered components to prevent moisture damage | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Residential living rooms | Sized for medium to large open-plan living spaces, providing coordinated seating for family use and guest entertainment | |
|---|---|---|
| Office reception and executive lounge areas | Formal contemporary styling with durable easy-clean upholstery suitable for corporate visitor waiting areas and executive break spaces | |
| High-rise apartment lounge spaces | Low-profile streamlined design complements modern floor-to-ceiling window architecture shown in the product scene | |
| Hotel suite lounge areas | Coordinated matching set provides uniform upscale appearance for short-term rental and hotel guest room seating | |
| Recommended pairing | Works with low-pile area rugs under the coffee table, positioned to allow 450mm clearance around seating for easy movement between pieces | |
| Color availability for procurement | Available in dark brown (as shown), black and light grey upholstery options to match different interior color schemes | |
| Hotel suite and short-term rental lounge areas | Coordinated matching set provides uniform upscale appearance for hotel guest rooms and short-stay rentals, wipe-clean surfaces suit high-turnover hospitality use | |
| Recommended layout clearance | Position set to allow 450mm clearance around seating pieces for easy movement, place on low-pile area rug under coffee table to anchor the seating group; standard residential furniture layout requirement |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable European standard for strength, durability and safety of residential seating furniture, recommended for export acceptance | |
|---|---|---|
| EN 15372:2008 | Applicable European standard for stability, strength and durability of residential tables including glass-top designs | |
| EN 1022:2005 | Applicable standard for stability testing of domestic seating to prevent tip-over during normal use | |
| EN 12720:2009 | Applicable standard for assessment of furniture surface resistance to cold liquids for easy-clean performance of faux leather and glass surfaces |
Standards applicable to China-market projects
| GB 28007-2011 | Applicable standard for strength, durability and stability of upholstered furniture for general residential use, recommended for procurement acceptance testing | |
|---|---|---|
| GB/T 19995.2-2005 | Applicable performance standard for natural or artificial leather upholstery materials, testing for abrasion resistance, color fastness and tear strength | |
| GB 15763.2-2005 | Applicable safety standard for tempered glass used in furniture table tops, requiring impact resistance and breakage safety certification | |
| GB 18584-2001 | Applicable indoor air quality standard limiting formaldehyde and volatile organic compound emissions from furniture materials for indoor residential use |
This product must meet the following technical requirements: 1. GB 28007-2011: Applicable standard for strength, durability and stability of upholstered furniture for general residential use, recommended for procurement acceptance testing; 2. GB/T 19995.2-2005: Applicable performance standard for natural or artificial leather upholstery materials, testing for abrasion resistance, color fastness and tear strength; 3. GB 15763.2-2005: Applicable safety standard for tempered glass used in furniture table tops, requiring impact resistance and breakage safety certification; 4. GB 18584-2001: Applicable indoor air quality standard limiting formaldehyde and volatile organic compound emissions from furniture materials for indoor residential use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
