Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 1900 x 850 x 800 mm | |
|---|---|---|
| Single armchair overall dimensions | 850 x 800 x 800 mm | |
| Ottoman/stool overall dimensions | 450 x 450 x 400 mm | |
| Large tempered glass coffee table dimensions | 1200 x 600 x 450 mm | |
| Small tempered glass coffee table dimensions | 1200 x 600 x 450 mm | |
| Seat height from floor | 420 mm | |
| Seat depth for all seating units | 550 mm | |
| Armrest height from floor | 620 mm | |
| Backrest height above seat | 380 mm | |
| Chrome support leg height | 50 mm | |
| Coffee table lower shelf clearance | 200 mm | |
| Armrest width | 120 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seater sofa net weight | 75 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Recommended total seating capacity | 7 people | |
| Foam indentation load deflection | 40 kg/m³ | |
| PU upholstery abrasion resistance | 50000 double rubs | |
| Seam tensile strength | 120 N | |
| Backrest horizontal load resistance | 80 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back padding | 40 kg/m³ high-density polyurethane foam | |
|---|---|---|
| External upholstery | Semi-PU leather with matte finish | |
| Internal seating frame | 25mm thick kiln-dried solid hardwood frame with corner block bracing | |
| Sofa support legs | 1.5mm thick polished chrome-plated steel legs | |
| Coffee tabletops | 10mm thick black tempered glass | |
| Coffee table support frames | 1.2mm thick polished chrome-plated square steel tube | |
| Coffee table lower shelf | 8mm thick black tempered glass | |
| Ottoman internal structure | 15mm thick particleboard frame wrapped in high-density foam and matching PU upholstery | |
| Seam construction | 8 stitches per inch matching upholstery thread | |
| Foot pads | Non-marking plastic floor protection pads under all metal legs | |
| Seat support system | 80mm wide elastic webbing spaced 50mm apart under seat cushions | |
| Frame moisture content | 12% |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Modular fixed-position reception set including 1 three-seat sofa, 4 single armchairs, 2 glass coffee tables, 2 ottomans | |
|---|---|---|
| Coffee table storage | Open lower tempered glass shelf for magazine, document and small item storage | |
| Seating support | Fixed non-reclining, non-adjustable upright backrest designed for formal business interaction | |
| Ottoman use | Dual-function padded square units usable as footrests or temporary extra seating for guests | |
| Color customization | 3 standard upholstery color options: black, tan/camel, orange | |
| Floor protection | Fixed non-marking feet prevent scuffing and damage to commercial carpet or hard flooring | |
| Surface maintenance | Stain-resistant PU upholstery allows wiping clean with standard office cleaning products | |
| Color options | 3 standard upholstery color options: black, tan/camel, orange | |
| Anti-tip design | Fixed floor contact points on all seating units and tables ensure 10° tilt resistance without tipping | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping packages | 11 packages | |
|---|---|---|
| 3-seater sofa carton dimensions | 1950 x 900 x 650 mm | |
| Single armchair carton dimensions | 900 x 850 x 650 mm | |
| Coffee table carton dimensions | 1250 x 650 x 150 mm | |
| Ottoman carton dimensions | 500 x 500 x 450 mm | |
| Total shipment gross weight | 260 kg | |
| Total shipment CBM | 3.2 cbm | |
| On-site assembly time | 120 minutes | |
| 40ft HQ container loading quantity | 26 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Suitable for formal visitor waiting zones outside executive offices, with symmetrical layout supporting up to 7 guests for business meetings | |
|---|---|---|
| Office building lobby waiting zones | Durable contract-grade construction and easy-clean upholstery withstand daily high-traffic use in public building entry areas | |
| Conference room breakout spaces | Compact modular arrangement works for informal pre-meeting waiting or post-meeting discussion areas adjacent to formal conference rooms | |
| Banking and financial service client areas | Formal design and color options project a professional, trustworthy image for client-facing financial service spaces | |
| Recommended complementary configuration | Pair with matching office plants, commercial low-pile carpet and floor-to-ceiling window treatments for a complete polished reception space | |
| Color matching recommendation | Select all-black upholstery for traditional formal offices, or mix tan and orange accent chairs for creative industry and modern tech office environments | |
| Creative industry office reception zones | Mixable black, tan and orange color options allow custom accent chair configurations to match tech, design and media company brand identities | |
| Color matching guidance | Specify all-black upholstery for legal and government office environments, or mix 2 black, 2 orange, 2 tan seating units for modern startup and co-working spaces |
EU Market Access Requirements* EN Standards
| Office furniture strength recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture surface flammability recommendation | EN 1021:2014 | |
| Furniture surface resistance recommendation | EN 12720:2009+A1:2013 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Formaldehyde emission limit recommendation | GB 18584 | |
| Tempered glass safety recommendation | GB 15763.2 | |
| Furniture hardware durability recommendation | GB/T 3324 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Formaldehyde emission limit recommendation: GB 18584; 3. Tempered glass safety recommendation: GB 15763.2; 4. Furniture hardware durability recommendation: GB/T 3324; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
