Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 820 x 850 mm | |
|---|---|---|
| Seat width between armrests | 600 mm | |
| Seat depth (front to back) | 550 mm | |
| Seat height (top of cushion to floor) | 420 mm | |
| Backrest height (top of back to seat surface) | 400 mm | |
| Armrest height (top of arm to floor) | 620 mm | |
| Armrest width (top surface) | 150 mm | |
| Cushion thickness (seat) | 120 mm | |
| Support foot height | 50 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Net product weight | 35 kg | |
|---|---|---|
| Recommended static seat load capacity | 150 kg | |
| Foam density (seat cushion) | 45 kg/m³ | |
| Foam density (backrest cushion) | 35 kg/m³ | |
| Foam rebound rate | 40% | |
| Seam stitch pitch | 3 stitches per 10mm | |
| Faux leather abrasion resistance | 50000 cycles | |
| Recommended maximum occupancy | 1 person | |
| Seat cushion indentation load deflection | 180 N | |
| Frame deformation resistance after 10000 load cycles | 2 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery material | Matte smooth faux leather (PU leather) | |
|---|---|---|
| Seat cushion padding | High-density polyurethane foam | |
| Backrest padding | Medium-density polyurethane foam | |
| Internal support frame | 1.2mm thick square steel tube frame | |
| Armrest structure | Padded rigid frame with integrated upholstery | |
| Support feet | Polished chrome-plated zinc alloy feet | |
| Floor protection pads | Non-slip rubber pads attached to base of each foot | |
| Internal base support | 10mm thick particleboard base panel | |
| Seat support system | 70mm wide elastic webbing (8 straps per seat) | |
| Internal base panel | 15mm thick E1 grade particleboard load-bearing panel | |
| Seam thread | High-tenacity polyester upholstery thread | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Fixed upright single-seat seating for guest reception | |
|---|---|---|
| Cleaning functionality | Stain-resistant non-porous upholstery surface | |
| Mobility features | Small integrated leveling glides on feet | |
| Configurability | Modular pairing with matching single-seat sofas and coffee tables | |
| Color option availability | 2 standard upholstery color options | |
| Structural stability | Four-corner fixed support base | |
| Leveling functionality | 5mm adjustable height leveling glides integrated on support feet | |
| Upholstery maintenance | Fade-resistant surface coating | |
| Floor protection | Full-contact rubber glide pads | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons per unit | 1 piece | |
|---|---|---|
| Single unit shipping carton dimensions | 950 x 870 x 900 mm | |
| Gross shipping weight per unit | 40 kg | |
| Shipping volume per unit | 0.75 CBM | |
| On-site assembly time per unit | 10 minutes | |
| 20ft GP container loading quantity | 36 pieces | |
| 40ft HQ container loading quantity | 88 pieces | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Suitable for high-floor executive office visitor zones, with formal boxy silhouette that matches professional office aesthetics | |
|---|---|---|
| Open-plan office waiting zones | Suitable for visitor waiting areas outside meeting rooms, with stain-resistant upholstery that supports heavy daily foot traffic | |
| VIP meeting lounge spaces | Suitable for grouped arrangements with matching coffee tables for closed-door client meeting areas, available in two neutral colors to match existing office decor | |
| Public institutional waiting rooms | Suitable for bank, government or service center public waiting areas, with durable construction designed for constant daily use | |
| Small office visitor nooks | Suitable for placement in 2-seat or 4-seat groups in small office entryways, with compact 900mm width fitting limited floor space without overcrowding | |
| Temporary event seating | Suitable for corporate event or conference break areas, with fully assembled construction allowing fast deployment without on-site upholstery work |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Applicable European standard for non-domestic seating – strength, durability and safety requirements for public office reception seating | |
|---|---|---|
| EN 1021-1:2014 | Applicable standard for upholstered furniture ignitability assessment (smoldering cigarette source) for public area furniture | |
| EN 13722:2004 | Applicable standard for furniture – assessment of surface resistance to cold liquids for faux leather upholstered surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.41-2020 | Applicable standard for lounge and public office seating, specifying static load, impact and durability test requirements |
|---|
Standards applicable to China-market projects
| GB 18584-2001 | Applicable standard for indoor decorating and refurbishing materials – limit of harmful substances in wooden furniture, applicable to internal panel components | |
|---|---|---|
| GB/T 35607-2017 | Applicable green product evaluation standard for furniture, applicable for low-VOC material selection for indoor office use | |
| GB 28007-2011 | Upholstered furniture for public places, applicable for strength, durability and fire safety requirements for commercial reception seating |
This product must meet the following technical requirements: 1. GB 18584-2001: Applicable standard for indoor decorating and refurbishing materials – limit of harmful substances in wooden furniture, applicable to internal panel components; 2. GB/T 35607-2017: Applicable green product evaluation standard for furniture, applicable for low-VOC material selection for indoor office use; 3. GB 28007-2011: Upholstered furniture for public places, applicable for strength, durability and fire safety requirements for commercial reception seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
